Using a Wi-Fi Adapter
30
Preparations
inserting the cable of the external microphone
into the cable clamp (page 42), which is located
under the AUDIO IN CH-1/CH-2 connectors,
should solve the problem.
Two types of Wi-Fi connections are available. In
“ad-hoc mode”, you can make a peer-to-peer Wi-
Fi connection between a computer and
camcorder. In “infrastructure mode”, you can
make Wi-Fi connections between a computer and
multiple camcorders via a wireless LAN access
point (building a LAN).
To make a network setting
Change settings under OTHERS >Network in the
setup menu as required.
a) The IP address determined by DHCP server is
displayed here.
When you have changed a setting
Set the Set item to [Execute]. When a
confirmation message appears, use the up/down/
left/right buttons or the jog dial to select
“Execute” and press the SEL/SET button or the
jog dial.
To make a connection in ad hoc mode
1 Refer to “Settings on the Computer”
under “Making a Wi-Fi Connection to
Your Computer (Ad hoc Mode)” in the
Operating Instructions supplied with
the CBK-WA01 to make settings on the
computer.
2 Start a connection on the computer.
3 Set OTHERS >Wi-Fi >Wi-Fi to
[Enable] in the setup menu.
4 Set OTHERS >Wi-Fi >Scan Networks
to [Execute] and press the SEL/SET
button or the jog dial.
The camcorder starts scanning for a network
connection.
When networks are detected, the
NETWORK SCAN list appears.
5 Turn the up/down/left/right buttons or
the jog dial to select a network and press
the SEL/SET button or the jog dial.
The OTHERS menu appears again.
6 Confirm that the settings for the Wi-Fi
item conform to the network setting on
the computer.
SSID (network name): Selected network
name
Network Type (connection mode): Adhoc
CH (channel): 1
Authentication (network authentication):
Depending the settings on the computer,
Open, Shared or WPA
Encryption (data encryption): Depending
the settings on the computer, Disable, WEP,
TKIP or AES
WEP Key Index (key index): 1 when
Encryption is set to [WEP]
Input Select (key input format): Depending
the network key (or security key), ASCII5,
ASCII13, HEX10 or HEX26 when
Encryption is set to [WEP], ASCII8-63 or
HEX64 Encryption is set to [TKIP] or [AES]
7 Set the Key item to the network key (or
security key) set on the computer and
press the SEL/SET button or the jog
dial.
8 Set the Set item to [Execute] and press
the SEL/SET button or the jog dial.
The message “Wi-Fi Setting Executing…”
appears and the camcorder starts connection.
Making a Wi-Fi Connection
Item Setting
DHCP Setting that specifies whether to
acquire the IP address automatically
from a DHCP server
Enabled: Acquire automatically.
Disabled: Do not acquire
automatically (factory default setting).
IP Address
IP address
a)
(factory default setting:
192.168.1.10)
Subnet Mask Subnet mask (factory default setting:
255.255.255.0)
Default
Gateway
Default gateway (factory default
setting: 0.0.0.0)
User Name User name for log-in (factory default
setting: admin)
Password Password for log-in (factory default
setting: model name “pmw-150”)
