Setup Menu List
95
Menu Configuration and Detailed Settings
MAC Address Display the MAC address.
Net Config Reset
Execute / Cancel
Reset the “Network” settings to the preset values.
Select “Execute” to reset.
Wi-Fi
Setting for Wi-Fi
connection
Note
The CBK-WA01
Wi-Fi Adapter is
required.
Scan Networks
Execute / Cancel
Scan the available network connections when “Wi-Fi” is set
to “Enable.”
SSID (Network connection name
display)
Reset
Reset the network connection name to the default settings.
Network Type
Infra / Adhoc
Select the connection mode.
Infra: Infrastructure mode
Adhoc: Ad hoc mode
Ch
1 to 11
Set the wireless channel when “Network Type” is “Adhoc.”
Authentication
When “Network Type” is “Infra”
Open / Shared / WPA / WPA2
When “Network Type” is “Adhoc”
Open / Shared
Select the network authentication.
Open: Open system authentication
Shared: Shared key authentication
WPA: WPA (Wi-Fi Protected Access) authentication
WPA2: WPA2 (Wi-Fi Protected Access 2) authentication
Encryption
When “Authentication” is “Open”
or “Shared”
Disable / WEP
When “Authentication” is “WPA”
or “WPA2”
Disable / TKIP / AES
Select the type of data encryption.
Disable: Do not apply data encryption.
WEP: Apply WEP (Wired Equivalent Privacy)
TKIP: Apply TKIP (Temporal Key Integrity Protocol)
AES: Apply AES (Advanced Encryption Standard)
WEP Key Index
1 / 2 / 3 / 4
Select the key index when “Encryption” is “WEP.”
Input Select
When “Encryption” is “WEP”
ASCII5 / ASCII13 / HEX10 /
HEX26
When “Encryption” is “TKIP” or
”AES”
ASCII8-63 / HEX64
Select the input format depending on the network key (or
security key).
ASCII5: Five characters ASCII format
ASCII13: 13 characters ASCII format
HEX10: 10 hexadecimal digits
HEX26: 26 hexadecimal digits
ASCII8-63: 8 to 63 characters ASCII 8-bit format
HEX64: 64 hexadecimal digits (characters)
Key (network key) Set the network key (or security key).
Set
Execute / Cancel
Confirm the “Wi-Fi” settings when “Wi-Fi” is set to “Enable.”
Select “Execute” to confirm.
Wi-Fi Status
x x x Connecting (display
only)
Display “Connecting” while connection is being attempted.
Display black squares to show the connection status by the
number of squares during communication.
Wireless Mode
802.11b / 802.11g / 802.11n
Display an IEEE802.11 standard.
Wi-Fi
Enable / Disable
Select whether to enable or disable Wi-Fi connection.
Wi-Fi Remote
On / Off
Select “On” when using the Wi-Fi remote commander.
Note
Unselectable when “Wi-Fi” is set to “Disable.”
OTHERS
Menu items Subitems and setting values Contents
