89
Additional Information
Rear panel
A AERIAL IN/OUT jacks (13)
B LINE 3/DECODER jack (23, 25, 26)
C DIGITAL OUT (COAXIAL) jack (16)
D COMPONENT VIDEO OUT (P
B
/C
B
, P
R
/
C
R
, Y) jacks (14)
E LINE 2 OUT (AUDIO L/R, VIDEO) jacks
(14, 16)
F LINE 4 IN (AUDIO L/R, VIDEO) jacks
(24)
G Mains lead (18)
H DIGITAL OUT (OPTICAL) jack (16)
I LINE 2 OUT (S VIDEO) jack (14)
J VIDEO OUT SELECT switch (14)
K LINE 1 – TV jack (14)
AERIAL
IN
OUT
LINE 3 / DECODER
DIGITAL OUT
LINE 1
-
TV
COAXIAL
PCM/DTS/
MPEG/
DOLBY DIGITAL
PCM/DTS/MPEG/
DOLBY DIGITAL
COMPONENT
VIDEO OUT
P
B
/C
B
P
R
/C
R
Y
LINE 2 OUT
L
AUDIO
VIDEO
R
LINE 4 IN
L
AUDIO
VIDEO
R
S VIDEO
LINE 2 OUT
DIGITAL OUT
VIDEO OUT
SELECT
RGB
COMPO-
NENT
OPTICAL
90
Glossary
Album (page 53)
A unit in which to store MP3 audio tracks on a
DATA CD. (Album is an exclusive definition for
this recorder.)
Chapter (page 52)
Sections of a picture or a music feature that are
smaller than titles. A title is composed of several
chapters. Depending on the disc, no chapters may
be recorded.
Copy protection signals (page 38)
Copy restriction set by copyright owners, etc.
These signals are included in some software or TV
programmes and restrict recording on this
recorder.
Dolby Digital (page 74)
Digital audio compression technology developed
by Dolby Laboratories. This technology conforms
to multi-channel surround sound. The rear channel
is stereo and there is a discrete subwoofer channel
in this format. Dolby Digital provides the same
discrete channels of high quality digital audio
found in “Dolby Digital” theater surround sound
systems.
Good channel separation is realized because all of
the channel data is recorded discretely, and little
deterioration occurs because all channel data
processing is digital.
DTS (page 74)
Digital audio compression technology by Digital
Theater Systems, Inc. This technology conforms
to multi-channel surround sound. The rear channel
is stereo and there is a discrete subwoofer channel
in this format. DTS provides the same discrete
channels of high quality digital audio.
Good channel separation is realized because all of
the channel data is recorded discretely, and little
deterioration occurs because all channel data
processing is digital.
DVD+R (page 8)
A DVD+R (read “plus R”) is a recordable disc that
is the same size as a DVD VIDEO. Contents can
be recorded only once to a DVD+R, and will have
the same format as a DVD VIDEO.
DVD-R (page 8)
A DVD-R is a recordable disc that is the same size
as a DVD VIDEO. Contents can be recorded only
once to a DVD-R, and will have the same format
as a DVD VIDEO.
DVD+RW (page 8)
A DVD+RW (read “plus RW”) is a recordable and
rewritable disc. DVD+RWs use a recording
format that is comparable to the DVD VIDEO
format.
DVD-RW (page 8)
A DVD-RW is a recordable and rewritable disc
that is the same size as a DVD VIDEO. The DVD-
RW has two different modes: VR mode and Video
mode. DVDs created in Video mode have the
same format as a DVD VIDEO, while discs
created in VR (Video Recording) mode allow the
contents to be programmed or edited.
DVD VIDEO (page 10)
A disc that contains up to eight hours of moving
pictures on a disc the same diameter as a CD.
The data capacity of a single-layer and single-
sided DVD is 4.7 GB (Giga Byte), which is 7
times that of a CD. The data capacity of a double-
layer and single-sided DVD is 8.5 GB, a single-
layer and double-sided DVD is 9.4 GB, and
double-layer and double-sided DVD is 17 GB.
The picture data uses the MPEG 2 format, which
is a worldwide standard of digital compression
technology. The picture data is compressed to
about 1/40 (average) of its original size. The DVD
also uses a variable rate coding technology that
changes the data to be allocated according to the
status of the picture. Audio information is
recorded in a multi-channel format, such as Dolby
Digital, allowing you to enjoy a more real audio
presence.
Furthermore, various advanced functions such as
the multi-angle, multilingual, and Parental
Control functions are provided on the DVD.
91
Additional Information
File (page 57)
A JPEG image recorded on a DATA CD. (File is
an exclusive definition for this recorder.) A single
file consist of a single image.
Folder (page 57)
A unit in which to store JPEG image files on a
DATA CD. (Folder is an exclusive definition for
this recorder.)
Interlace format (page 73)
Interlace format shows every other line of an
image as a single “field” and is the standard
method for displaying images on television. The
even number field shows the even numbered lines
of an image, and the odd numbered field shows the
odd numbered lines of an image.
MPEG Audio (page 75)
International standard coding system used to
compress audio digital signals authorized by ISO/
IEC. MPEG 2, used on DVDs, conforms to up to
7.1-channel surround.
Original (page 59)
Titles actually recorded on a DVD-RW (VR
mode). Erasing original titles frees up disc space.
Playlist (page 59)
Playback information created from the actual
recordings on a DVD-RW (VR mode). A Playlist
leaves the original titles as they are, and contains
only the information needed to control playback.
A Playlist title takes up very little disc space.
Progressive format (page 73)
Compared to the Interlace format that alternately
shows every other line of an image (field) to create
one frame, the Progressive format shows the entire
image at once as a single frame. This means that
while the Interlace format can show 25-30 frames/
50-60 fields in one second, the Progressive format
can show 50/60 frames in one second. The overall
picture quality increases and still images, text, and
horizontal lines appear sharper.
Title (page 52)
The longest section of a picture or music feature
on a DVD, movie, etc., in video software, or the
entire album in audio software.
Track (page 52)
Sections of a picture or a music feature on a
VIDEO CD, CD, or DATA CD (the length of a
song). (Track is an exclusive definition for this
recorder.)
92
Language Code List
For details, see page 74.
The language spellings conform to the ISO 639: 1988 (E/F) standard.
