7-5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D102 8-719-085-16 DIODE EU01W
D121 9-885-078-36 DIODE UF5402-M11
D123 9-885-032-86 DIODE 1N5822
D124 9-885-078-35 DIODE SB360-24A
D125 9-885-032-86 DIODE 1N5822
D127 8-719-085-16 DIODE EU01W
D128 8-719-085-16 DIODE EU01W
D129 9-885-078-39 DIODE 1N4148
D130 9-885-032-85 DIODE RL104F
D131 9-885-032-86 DIODE 1N5822
D132 9-885-078-39 DIODE 1N4148
D134 9-885-078-39 DIODE 1N4148
ZD103 9-885-078-40 DIODE UZ-22BSB
ZD151 9-885-078-42 DIODE GDZJ3.3B
ZD152 9-885-078-41 DIODE UZ-33BSB
< FUSE >
0 F101 1-532-503-32 FUSE (1.6A/250V)
< IC >
IC101 9-885-078-65 IC FSDM0565RBL
IC102 8-749-018-95 IC LTV-817B
IC106 9-885-073-56 IC KA431AZ
IC151 9-885-078-66 IC G9133
IC153 9-885-078-64 IC KIA78R12PI-CU
IC154 9-885-078-67 IC KIA278R05PI-CU
IC156 9-885-078-64 IC KIA78R12PI-CU
IC158 9-885-078-68 IC KIA278R12PI-CU
IC160 9-885-078-69 IC PQ070VK02LZH
< CONNECTOR >
PW101 9-885-078-78 CONNECTOR GP390
< TRANSISTOR >
Q120 9-885-039-70 TRANSISTOR KSB1151-Y
Q121 9-885-078-47 TRANSISTOR KRC103M
Q122 9-885-078-47 TRANSISTOR KRC103M
Q123 9-885-073-65 TRANSISTOR KTA1268-BL
Q124 8-729-040-76 TRANSISTOR KTA1273-Y-AT
< VARISTOR >
0 V101 9-885-078-79 VARISTOR SVC681D-10A
SMPS
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
