– 38 –
KV-B14PD1
RM-883
RESISTORS
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : µH, UH : µH
When indicating parts by reference number,
please include the board name.
NOTE:
• Items marked " ∗ " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
* A-1298-586-A A BOARD, COMPLETE
********************
1-533-223-11 CLIP, FUSE
* 1-580-798-11 CONNECTOR PIN (DY) 6P
4-044-755-01 HOLDER, FBT
* 4-367-524-32 CASE, SHIELD (LID UPPER)
4-382-854-11 SCREW (M3X10), P, SW (+)
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
<CAPACITOR>
C001 1-102-119-00 CERAMIC 0.0015MF 10% 50V
C002 1-126-965-11 ELECT 22MF 20% 50V
C004 1-125-800-51 ELECT 2.2MF 20% 63V
C007 1-125-798-51 ELECT 0.47MF 20% 63V
C009 1-102-824-00 CERAMIC 470PF 5% 50V
C010 1-136-157-00 FILM 0.022MF 5% 50V
C011 1-126-967-11 ELECT 47MF 20% 16V
C015 1-101-884-00 CERAMIC 56PF 5% 50V
C016 1-101-884-00 CERAMIC 56PF 5% 50V
C017 1-102-973-00 CERAMIC 100PF 5% 50V
C018 1-102-973-00 CERAMIC 100PF 5% 50V
C021 1-102-074-00 CERAMIC 0.001MF 10% 50V
C022 1-102-074-00 CERAMIC 0.001MF 10% 50V
C023 1-102-074-00 CERAMIC 0.001MF 10% 50V
C024 1-102-074-00 CERAMIC 0.001MF 10% 50V
C025 1-102-074-00 CERAMIC 0.001MF 10% 50V
C026 1-102-074-00 CERAMIC 0.001MF 10% 50V
C027 1-102-074-00 CERAMIC 0.001MF 10% 50V
C032 1-136-153-00 FILM 0.01MF 5% 50V
C034 1-136-165-00 FILM 0.1MF 5% 50V
C042 1-102-973-00 CERAMIC 100PF 5% 50V
C044 1-102-973-00 CERAMIC 100PF 5% 50V
C046 1-102-973-00 CERAMIC 100PF 5% 50V
C048 1-136-165-00 FILM 0.1MF 5% 50V
C049 1-136-165-00 FILM 0.1MF 5% 50V
C050 1-126-960-11 ELECT 1MF 20% 50V
C051 1-102-973-00 CERAMIC 100PF 5% 50V
C052 1-136-165-00 FILM 0.1MF 5% 50V
C053 1-102-074-00 CERAMIC 0.001MF 10% 50V
C054 1-102-074-00 CERAMIC 0.001MF 10% 50V
C055 1-126-935-11 ELECT 470MF 20% 16V
C056 1-102-074-00 CERAMIC 0.001MF 10% 50V
C057 1-102-852-91 CERAMIC 47PF 5% 50V
C058 1-102-973-00 CERAMIC 100PF 5% 50V
C059 1-102-973-00 CERAMIC 100PF 5% 50V
C060 1-102-074-00 CERAMIC 0.001MF 10% 50V
C061 1-125-800-51 ELECT 2.2MF 20% 63V
C072 1-126-935-11 ELECT 470MF 20% 16V
C074 1-102-110-00 CERAMIC 220PF 10% 50V
C101 1-101-003-00 CERAMIC 0.0047MF 50V
C102 1-136-165-00 FILM 0.1MF 5% 50V
C105 1-125-804-51 ELECT 100MF 20% 16V
C106 1-125-797-51 ELECT 10MF 20% 50V
C108 1-125-807-51 ELECT 1000MF 20% 16V
C109 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C111 1-102-074-00 CERAMIC 0.001MF 10% 50V
C114 1-102-973-00 CERAMIC 100PF 5% 50V
C115 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C116 1-136-165-00 FILM 0.1MF 5% 50V
C117 1-102-973-00 CERAMIC 100PF 5% 50V
C118 1-126-965-11 ELECT 22MF 20% 50V
C119 1-136-153-00 FILM 0.01MF 5% 50V
C120 1-130-493-00 MYLAR 0.068MF 5% 50V
C121 1-130-493-00 MYLAR 0.068MF 5% 50V
C122 1-125-804-51 ELECT 100MF 20% 16V
C124 1-136-165-00 FILM 0.1MF 5% 50V
C125 1-136-165-00 FILM 0.1MF 5% 50V
C233 1-126-967-11 ELECT 47MF 20% 16V
C234 1-126-967-11 ELECT 47MF 20% 16V
C235 1-126-967-11 ELECT 47MF 20% 16V
C236 1-126-949-11 ELECT 220MF 20% 35V
C237 1-125-804-51 ELECT 100MF 20% 16V
C238 1-137-188-51 FILM 0.15MF 5% 50V
C239 1-126-933-11 ELECT 100MF 20% 16V
C240 1-137-188-51 FILM 0.15MF 5% 50V
C241 1-126-943-11 ELECT 2200MF 20% 25V
C242 1-136-153-00 FILM 0.01MF 5% 50V
C243 1-128-551-11 ELECT 22MF 20% 25V
C244 1-125-813-51 ELECT 1000MF 20% 25V
C246 1-126-965-11 ELECT 22MF 20% 50V
C247 1-124-478-11 ELECT 100MF 20% 25V
C252 1-125-800-51 ELECT 2.2MF 20% 63V
C253 1-125-804-51 ELECT 100MF 20% 16V
C254 1-136-159-00 FILM 0.033MF 5% 50V
C257 1-136-169-00 FILM 0.22MF 5% 50V
C258 1-136-169-00 FILM 0.22MF 5% 50V
C300 1-126-967-11 ELECT 47MF 20% 16V
C304 1-136-165-00 FILM 0.1MF 5% 50V
C305 1-136-165-00 FILM 0.1MF 5% 50V
C306 1-136-165-00 FILM 0.1MF 5% 50V
C307 1-136-165-00 FILM 0.1MF 5% 50V
C308 1-136-165-00 FILM 0.1MF 5% 50V
C309 1-136-165-00 FILM 0.1MF 5% 50V
C310 1-136-165-00 FILM 0.1MF 5% 50V
C311 1-102-951-00 CERAMIC 15PF 5% 50V
C312 1-102-951-00 CERAMIC 15PF 5% 50V
C313 1-125-804-51 ELECT 100MF 20% 16V
SECTION 8
ELECTRICAL PARTS LIST
A
