– 39 –
KV-B14PD1
RM-883
REF. NO. PART NO. DESCRIPTION REMARKREF. NO. PART NO. DESCRIPTION REMARK
C314 1-102-121-00 CERAMIC 0.0022MF 10% 50V
C315 1-125-798-51 ELECT 0.47MF 20% 63V
C316 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C317 1-125-800-51 ELECT 2.2MF 20% 63V
C319 1-136-165-00 FILM 0.1MF 5% 50V
C320 1-136-165-00 FILM 0.1MF 5% 50V
C321 1-136-165-00 FILM 0.1MF 5% 50V
C323 1-101-880-00 CERAMIC 47PF 5% 50V
C324 1-125-800-51 ELECT 2.2MF 20% 63V
C325 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C326 1-102-949-00 CERAMIC 12PF 5% 50V
C327 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C328 1-136-165-00 FILM 0.1MF 5% 50V
C329 1-130-478-00 MYLAR 0.0039MF 5% 50V
C330 1-136-165-00 FILM 0.1MF 5% 50V
C331 1-125-797-51 ELECT 10MF 20% 50V
C332 1-136-165-00 FILM 0.1MF 5% 50V
C333 1-136-165-00 FILM 0.1MF 5% 50V
C334 1-102-123-00 CERAMIC 0.0033MF 10% 50V
C335 1-102-973-00 CERAMIC 100PF 5% 50V
C336 1-125-797-51 ELECT 10MF 20% 50V
C337 1-125-804-51 ELECT 100MF 20% 16V
C339 1-101-361-00 CERAMIC 150PF 5% 50V
C340 1-102-074-00 CERAMIC 0.001MF 10% 50V
C341 1-102-973-00 CERAMIC 100PF 5% 50V
C342 1-136-165-00 FILM 0.1MF 5% 50V
C344 1-125-797-51 ELECT 10MF 20% 50V
C349 1-126-963-11 ELECT 4.7MF 20% 50V
C359 1-125-804-51 ELECT 100MF 20% 16V
C361 1-102-074-00 CERAMIC 0.001MF 10% 50V
C367 1-136-165-00 FILM 0.1MF 5% 50V
C368 1-136-165-00 FILM 0.1MF 5% 50V
C369 1-136-165-00 FILM 0.1MF 5% 50V
C370 1-136-165-00 FILM 0.1MF 5% 50V
C374 1-126-967-11 ELECT 47MF 20% 50V
C375 1-126-967-11 ELECT 47MF 20% 50V
C402 1-136-153-00 FILM 0.01MF 5% 50V
C403 1-126-965-11 ELECT 22MF 20% 50V
C405 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C406 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C407 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C408 1-102-125-00 CERAMIC 0.0047MF 10% 50V
C410 1-102-961-00 CERAMIC 27PF 5% 50V
C411 1-101-888-00 CERAMIC 68PF 5% 50V
C423 1-102-820-00 CERAMIC 330PF 5% 50V
C501 1-102-228-00 CERAMIC 470PF 10% 500V
C523 1-126-933-11 ELECT 100MF 20% 16V
C548 1-106-220-00 MYLAR 0.1MF 10% 100V
C551 1-126-948-11 ELECT 100MF 20% 35V
C552 1-126-948-11 ELECT 100MF 20% 35V
C553 1-102-127-00 CERAMIC 0.0068MF 10% 50V
C554 1-102-244-00 CERAMIC 220PF 10% 500V
C555 1-101-804-00 CERAMIC 10PF 5% 500V
C562 1-126-933-11 ELECT 100MF 20% 16V
C603 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C604 1-117-751-11 ELECT(BLOCK) 220MF 20% 450V
C605 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C606 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C607 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C608 1-104-332-11 CERAMIC 470PF 10% 2KV
C609 1-124-347-00 ELECT 100MF 20% 160V
C610 1-126-943-11 ELECT 2200MF 20% 25V
C611 ! 1-164-497-51 CERAMIC 470PF 10% 400V
C612 1-102-228-00 CERAMIC 470PF 10% 500V
C613 1-102-824-00 CERAMIC 470PF 5% 50V
C614 1-126-943-11 ELECT 2200MF 20% 25V
C616 1-102-228-00 CERAMIC 470PF 10% 500V
C618 1-102-114-00 CERAMIC 470PF 10% 50V
C621 ! 1-104-705-51 FILM 0.1MF 20% 250V
C622 1-107-368-11 MYLAR 0.047MF 99% 200V
C623 1-126-934-11 ELECT 220MF 20% 16V
C624 1-126-935-11 ELECT 470MF 20% 16V
C625 1-102-074-00 CERAMIC 0.001MF 10% 50V
C627 1-162-116-00 CERAMIC 680PF 10% 2KV
C628 1-102-824-00 CERAMIC 470PF 5% 50V
C630 ! 1-164-497-51 CERAMIC 470PF 10% 400V
C631 1-161-830-00 CERAMIC 0.0047MF 99% 500V
C632 ! 1-164-497-51 CERAMIC 470PF 10% 400V
C633 1-161-754-00 CERAMIC 0.001MF 10% 3KV
C634 1-102-114-00 CERAMIC 470PF 10% 50V
C801 1-123-024-21 ELECT 33MF 160V
C802 1-107-364-11 MYLAR 0.01MF 10% 200V
C804 1-102-074-00 CERAMIC 0.001MF 10% 50V
C805 1-102-244-00 CERAMIC 220PF 10% 500V
C806 1-126-960-11 ELECT 1MF 20% 50V
C809 1-162-115-00 CERAMIC 330PF 10% 2KV
C810 1-106-365-00 MYLAR 0.0082MF 99% 200V
C811 1-101-821-00 CERAMIC 0.0022MF 500V
C812 1-136-075-00 FILM 0.008MF 3% 2KV
C816 1-107-636-11 ELECT 10MF 20% 160V
C820 1-162-116-00 CERAMIC 680PF 10% 2KV
C821 1-106-381-12 MYLAR 0.039MF 10% 200V
C822 1-136-121-00 FILM 0.27MF 5% 200V
C823 1-136-153-00 FILM 0.01MF 5% 50V
C825 1-107-364-11 MYLAR 0.01MF 10% 200V
C850 1-126-941-11 ELECT 470MF 20% 25V
C852 1-104-574-11 CERAMIC 0.0047MF 10% 2KV
C853 1-162-318-11 CERAMIC 0.001MF 10% 500V
C854 1-126-941-11 ELECT 470MF 20% 25V
C856 1-162-318-11 CERAMIC 0.001MF 10% 500V
C857 1-130-493-00 MYLAR 0.068MF 5% 50V
C860 1-102-228-00 CERAMIC 470PF 10% 500V
C861 1-107-654-11 ELECT 33MF 20% 250V
C876 1-107-369-11 MYLAR 0.068MF 10% 100V
C898 1-106-379-12 MYLAR 0.033MF 10% 100V
C901 1-102-824-00 CERAMIC 470PF 5% 50V
C902 1-102-824-00 CERAMIC 470PF 5% 50V
C1201 1-125-804-51 ELECT 100MF 20% 16V
C1202 1-136-177-00 FILM 1MF 5% 50V
C1204 1-125-804-51 ELECT 100MF 20% 16V
C1205 1-136-177-00 FILM 1MF 5% 50V
C1210 1-125-804-51 ELECT 100MF 20% 16V
C1213 1-126-960-11 ELECT 1MF 20% 50V
C1214 1-125-797-51 ELECT 10MF 20% 50V
C1217 1-125-804-51 ELECT 100MF 20% 16V
C1218 1-102-976-00 CERAMIC 180PF 5% 50V
C1221 1-136-169-00 FILM 0.22MF 5% 50V
C1226 1-125-806-51 ELECT 220MF 20% 16V
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
