– 43 –
KV-B14PD1
RM-883
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
R898 1-247-839-31 CARBON 2.2K 5% 1/4W
R902 1-247-847-31 CARBON 4.7K 5% 1/4W
R904 1-247-847-31 CARBON 4.7K 5% 1/4W
R905 1-220-958-81 METAL 1K 5% 1/2W
R906 1-220-958-81 METAL 1K 5% 1/2W
R907 1-220-960-81 METAL 1.8K 5% 1/2W
R908 1-220-960-81 METAL 1.8K 5% 1/2W
R909 1-220-963-81 METAL 3.3K 5% 1/2W
R910 1-220-963-81 METAL 3.3K 5% 1/2W
R911 1-249-428-11 CARBON 8.2K 5% 1/4W
R913 1-247-823-31 CARBON 470 5% 1/4W
R914 1-247-823-31 CARBON 470 5% 1/4W
R915 1-249-428-11 CARBON 8.2K 5% 1/4W
R1201 1-249-404-00 CARBON 82 5% 1/4W
R1202 1-220-958-81 METAL 1K 5% 1/2W
R1203 1-249-437-11 CARBON 47K 5% 1/4W
R1205 1-249-404-00 CARBON 82 5% 1/4W
R1206 1-249-437-11 CARBON 47K 5% 1/4W
R1211 1-220-946-81 METAL 68 5% 1/2W
R1212 1-220-958-81 METAL 1K 5% 1/2W
R1215 1-247-895-00 CARBON 470K 5% 1/4W
R1216 1-247-895-00 CARBON 470K 5% 1/4W
R1217 1-247-823-31 CARBON 470 5% 1/4W
R1219 1-247-855-31 CARBON 10K 5% 1/4W
R1220 1-220-958-81 METAL 1K 5% 1/2W
R1221 1-247-855-31 CARBON 10K 5% 1/4W
R1227 1-220-964-81 METAL 39K 5% 1/2W
R1228 1-220-958-81 METAL 1K 5% 1/2W
R1229 1-247-823-31 CARBON 470 5% 1/4W
R1230 1-247-855-31 CARBON 10K 5% 1/4W
R1231 1-220-958-81 METAL 1K 5% 1/2W
R1232 1-249-424-11 CARBON 3.9K 5% 1/4W
R1233 1-220-961-81 METAL 2.2K 5% 1/2W
R1235 1-220-964-81 METAL 39K 5% 1/2W
R1239 1-249-389-11 CARBON 4.7 5% 1/4W F
R1240 1-247-807-31 CARBON 100 5% 1/4W
R1241 1-220-958-81 METAL 1K 5% 1/2W
R1243 1-247-807-31 CARBON 100 5% 1/4W
R1246 1-249-411-11 CARBON 330 5% 1/4W
R1247 1-247-823-31 CARBON 470 5% 1/4W
R1248 1-220-958-81 METAL 1K 5% 1/2W
R1249 1-247-823-31 CARBON 470 5% 1/4W
R1250 1-247-901-11 CARBON 820K 5% 1/4W
R1251 1-247-901-11 CARBON 820K 5% 1/4W
R1252 1-220-961-81 METAL 2.2K 5% 1/2W
R1253 1-249-418-11 CARBON 1.2K 5% 1/4W
R1255 1-247-855-31 CARBON 10K 5% 1/4W
R1513 1-247-855-31 CARBON 10K 5% 1/4W
R1514 1-247-847-31 CARBON 4.7K 5% 1/4W
R1515 1-247-807-31 CARBON 100 5% 1/4W
<SWITCH>
S601 ! 1-571-433-31 SWITCH, PUSH (AC POWER)
S801 1-572-707-11 SWITCH, LEVER
S901 1-570-577-41 SWITCH, PUSH
S902 1-570-577-41 SWITCH, PUSH
S903 1-570-577-41 SWITCH, PUSH
S904 1-570-577-41 SWITCH, PUSH
S905 1-570-577-41 SWITCH, PUSH
<SPARK GAP>
SG801 1-519-422-11 GAP, SPARK
<SURFACE WAVE FILTER>
SWF401 1-577-169-12 SAWF
<TRANSFORMER>
T601 ! 1-431-824-11 TRANSFORMER, CONVERTER (SRT)
T605 ! 1-424-682-11 TRANSFORMER, LINE FILTER
T801 1-437-195-11 TRANSFORMER, HORIZONTAL DRIVE
T851 ! 1-453-194-11 TRANSFORMER ASSY, FLYBACK
(NCX-1723//M3A)
<THERMISTOR>
THP601!1-806-165-12 THERMISTOR (POSITIVE)
<TUNER>
TU101 ! 8-598-323-30 TUNER, VSS BT-AG401
<CRYSTAL>
X101 1-577-082-11 VIBRATOR, CERAMIC
X300 1-411-752-11 COIL
X358 1-567-505-11 OSCILLATOR, CRYSTAL
X443 1-567-504-11 OSCILLATOR, CRYSTAL
***********************************************************************
* A-1331-803-A C BOARD, COMPLETE
*********************
<CAPACITOR>
C702 1-136-601-11 FILM 0.01MF 10% 630V
C705 1-102-116-00 CERAMIC 680PF 10% 50V
C706 1-102-116-00 CERAMIC 680PF 10% 50V
C707 1-102-117-00 CERAMIC 820PF 10% 50V
C708 1-102-114-00 CERAMIC 470PF 10% 50V
C712 1-102-114-00 CERAMIC 470PF 10% 50V
C713 1-102-115-00 CERAMIC 560PF 10% 50V
C716 1-102-106-00 CERAMIC 100PF 10% 50V
<CONNECTOR>
CN701 1-695-915-11 TAB (CONTACT)
CN703 * 1-564-509-11 PLUG, CONNECTOR 6P
CN704 * 1-508-766-00 PIN, CONNECTOR (5MM PITCH) 4P
<DIODE>
D701 8-719-911-19 DIODE 1SS119-25
D702 8-719-911-19 DIODE 1SS119-25
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
CA
