– 44 –
KV-B14PD1
RM-883
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
C
D703 8-719-911-19 DIODE 1SS119-25
D705 1-102-106-00 CERAMIC 100PF 10% 50V
D712 8-719-911-19 DIODE 1SS119-25
D713 8-719-911-19 DIODE 1SS119-25
D714 8-719-911-19 DIODE 1SS119-25
<JACK>
J701 ! 1-251-192-11 SOCKET, CRT
<TRANSISTOR>
Q701 8-729-200-17 TRANSISTOR 2SA1091-O
Q702 8-729-200-17 TRANSISTOR 2SA1091-O
Q703 8-729-200-17 TRANSISTOR 2SA1091-O
Q704 8-729-326-11 TRANSISTOR 2SC2611
Q705 8-729-326-11 TRANSISTOR 2SC2611
Q706 8-729-326-11 TRANSISTOR 2SC2611
<RESISTOR>
R701 1-260-133-51 CARBON 680K 5% 1/2W
R702 1-260-123-11 CARBON 100K 5% 1/2W
R703 1-260-135-51 CARBON 1M 5% 1/2W
R705 1-260-079-11 CARBON 22 5% 1/2W
R706 1-260-105-11 CARBON 3.3K 5% 1/2W
R707 1-260-105-11 CARBON 3.3K 5% 1/2W
R708 1-260-105-11 CARBON 3.3K 5% 1/2W
R709 1-215-899-11 METAL OXIDE 15K 5% 2W F
R711 1-215-899-11 METAL OXIDE 15K 5% 2W F
R713 1-215-899-11 METAL OXIDE 15K 5% 2W F
R714 1-247-807-31 CARBON 100 5% 1/4W
R717 1-215-409-00 METAL 330 1% 1/4W
R718 1-249-409-11 CARBON 220 5% 1/4W F
R719 1-247-807-31 CARBON 100 5% 1/4W
R720 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R722 1-215-411-00 METAL 390 1% 1/4W
R725 1-249-409-11 CARBON 220 5% 1/4W F
R726 1-215-479-00 METAL 270K 1% 1/4W
R727 1-215-487-00 METAL 560K 1% 1/4W
R728 1-215-479-00 METAL 270K 1% 1/4W
R730 1-247-807-31 CARBON 100 5% 1/4W
R731 1-249-409-11 CARBON 220 5% 1/4W F
R732 1-215-411-00 METAL 390 1% 1/4W
R733 1-249-397-11 CARBON 22 5% 1/4W
R734 1-249-397-11 CARBON 22 5% 1/4W
R735 1-249-397-11 CARBON 22 5% 1/4W
R749 1-249-424-11 CARBON 3.9K 5% 1/4W
R750 1-249-424-11 CARBON 3.9K 5% 1/4W
R751 1-249-424-11 CARBON 3.9K 5% 1/4W
<VARIABLE RESISTOR>
RV701 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
RV703 1-230-641-11 RES, ADJ, METAL GLAZE 2.2M
***********************************************************************
MISCELLANEOUS
*****************
! 1-426-145-13 COIL, DEGAUSSING
1-452-032-00 MAGNET,DISC
1-452-277-00 MAGNET, BMC
1-504-449-11 SPEAKER (9X5CM)
1-504-450-11 SPEAKER (8CM)
! 1-574-062-61 CORD, POWER (WITH CONNECTOR) 2.5A/250V
! 8-451-418-21 DEFLECTION YOKE (Y14NDA2)
! 8-735-562-05 PICTURE TUBE (A34JBU70X)
***********************************************************************
ACCESSORIES AND PACKING MATERIALS
***************************************
3-862-582-11 MANUAL, INSTRUCTION
* 4-055-504-01 BAG, PROTECTION
* 4-064-704-01 INDIVIDUAL CARTON
* 4-064-705-01 CUSHION (UPPER) (ASSY)
* 4-064-706-01 CUSHION (LOWER) (ASSY)
***********************************************************************
REMOTE COMMANDER
**********************
1-475-800-11 REMOTE COMMANDER (RM-883)
Sony Corporation
Display Company
TV Display Business Asia
English
98FM70034-1
Printed in Malaysia
1998. 6
9-965-692-01
