– 42 –
KV-B14PD1
RM-883
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
R249 1-220-958-81 METAL 1K 5% 1/2W
R250 1-220-958-81 METAL 1K 5% 1/2W
R251 1-220-958-81 METAL 1K 5% 1/2W
R252 1-249-409-11 CARBON 220 5% 1/4W
R253 1-247-855-31 CARBON 10K 5% 1/4W
R254 1-249-389-11 CARBON 4.7 5% 1/4W
R255 1-249-389-11 CARBON 4.7 5% 1/4W
R256 1-249-409-11 CARBON 220 5% 1/4W
R264 1-249-415-11 CARBON 680 5% 1/4W
R265 1-220-958-81 METAL 1K 5% 1/2W
R266 1-249-437-11 CARBON 47K 5% 1/4W
R303 1-247-807-31 CARBON 100 5% 1/4W
R304 1-247-807-31 CARBON 100 5% 1/4W
R305 1-249-409-11 CARBON 220 5% 1/4W
R306 1-249-409-11 CARBON 220 5% 1/4W
R307 1-249-409-11 CARBON 220 5% 1/4W
R308 1-249-409-11 CARBON 220 5% 1/4W
R309 1-249-409-11 CARBON 220 5% 1/4W
R310 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-249-430-11 CARBON 12K 5% 1/4W
R312 1-247-807-31 CARBON 100 5% 1/4W
R313 1-220-959-81 METAL 1.5K 5% 1/2W
R318 1-249-441-11 CARBON 100K 5% 1/4W
R319 1-259-877-11 CARBON 1.2M 5% 1/4W
R320 1-249-434-11 CARBON 27K 5% 1/4W
R321 1-215-459-00 METAL 39K 1% 1/4W
R322 1-249-434-11 CARBON 27K 5% 1/4W
R326 1-249-412-11 CARBON 390 5% 1/4W
R330 1-220-958-81 METAL 1K 5% 1/2W
R331 1-247-899-11 CARBON 680K 5% 1/4W
R332 1-249-409-11 CARBON 220 5% 1/4W
R333 1-220-964-81 METAL 39K 5% 1/2W
R335 1-247-855-31 CARBON 10K 5% 1/4W
R336 1-220-961-81 METAL 2.2K 5% 1/2W
R339 1-215-408-00 METAL 300 1% 1/4W
R340 1-249-410-11 CARBON 270 5% 1/4W
R341 1-220-958-81 METAL 1K 5% 1/2W
R351 1-249-393-11 CARBON 10 5% 1/4W
R355 1-249-393-11 CARBON 10 5% 1/4W
R356 1-220-958-81 METAL 1K 5% 1/2W
R360 1-259-884-11 CARBON 4.7M 5% 1/4W
R403 1-220-946-81 METAL 68 5% 1/2W
R406 1-247-847-31 CARBON 4.7K 5% 1/4W
R407 1-249-424-11 CARBON 3.9K 5% 1/4W
R408 1-220-960-81 METAL 1.8K 5% 1/2W
R409 1-247-807-31 CARBON 100 5% 1/4W
R414 1-247-823-31 CARBON 470 5% 1/4W
R416 1-249-409-11 CARBON 220 5% 1/4W
R419 1-220-958-81 METAL 1K 5% 1/2W
R420 1-249-412-11 CARBON 390 5% 1/4W
R421 1-249-409-11 CARBON 220 5% 1/4W
R424 1-220-961-81 METAL 2.2K 5% 1/2W
R425 1-249-412-11 CARBON 390 5% 1/4W
R426 1-249-407-11 CARBON 150 5% 1/4W
R429 1-249-412-11 CARBON 390 5% 1/4W
R433 1-249-433-11 CARBON 22K 5% 1/4W
R434 1-247-823-31 CARBON 470 5% 1/4W
R438 1-247-823-31 CARBON 470 5% 1/4W
R440 1-249-407-11 CARBON 150 5% 1/4W
R521 1-249-417-11 CARBON 1K 5% 1/4W
R555 1-247-855-31 CARBON 10K 5% 1/4W
R556 1-249-417-11 CARBON 1K 5% 1/4W
R557 1-249-420-11 CARBON 1.8K 5% 1/4W
R561 1-247-839-31 CARBON 2.2K 5% 1/4W
R562 1-249-418-11 CARBON 1.2K 5% 1/4W F
R563 1-260-126-11 CARBON 180K 5% 1/2W
R564 1-249-438-11 CARBON 56K 5% 1/4W
R565 1-249-438-11 CARBON 56K 5% 1/4W
R566 1-247-847-31 CARBON 4.7K 5% 1/4W
R569 1-260-354-71 CARBON 150K 5% 1/2W
R571 1-249-409-11 CARBON 220 5% 1/4W
R610 1-215-924-00 METAL OXIDE 15K 5% 3W F
R611 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R612 1-249-377-11 CARBON 0.47 5% 1/4W F
R613 1-219-134-11 FUSIBLE 0.1 10% 1/4W
R614 1-215-877-11 METAL OXIDE 22K 5% 1W F
R615 1-249-389-11 CARBON 4.7 5% 1/4W F
R616 ! 1-247-289-11 CARBON 8.2M 5% 1W
R617 1-215-924-00 METAL OXIDE 15K 5% 3W F
R618 1-249-377-11 CARBON 0.47 5% 1/4W F
R619 1-219-134-11 FUSIBLE 0.1 10% 1/4W
R620 1-202-962-11 CEMENTED 3.3 5% 10W
R622 1-207-615-00 METAL 0.33 10% 2W
R623 1-247-807-31 CARBON 100 5% 1/4W
R624 1-216-446-00 METAL OXIDE 18 5% 2W F
R625 1-249-424-11 CARBON 3.9K 5% 1/4W
R626 1-249-420-11 CARBON 1.8K 5% 1/4W
R627 1-249-417-11 CARBON 1K 5% 1/4W
R628 1-249-417-11 CARBON 1K 5% 1/4W
R629 1-249-401-11 CARBON 47 5% 1/4W
R636 1-215-924-00 METAL OXIDE 15K 5% 3W F
R801 1-215-921-11 METAL OXIDE 4.7K 5% 3W F
R803 1-247-839-31 CARBON 2.2K 5% 1/4W
R804 1-249-417-11 CARBON 1K 5% 1/4W
R805 1-249-433-11 CARBON 22K 5% 1/4W
R809 1-247-763-11 CARBON 8.2K 5% 1/2W F
R811 1-216-350-11 METAL OXIDE 1.2 5% 1W F
R816 1-249-437-11 CARBON 47K 5% 1/4W
R820 1-249-419-11 CARBON 1.5K 5% 1/4W
R821 1-216-475-11 METAL OXIDE 120 5% 3W F
R822 1-216-429-00 METAL OXIDE 270 5% 1W F
R823 1-215-869-11 METAL OXIDE 1K 5% 1W F
R824 1-215-889-00 METAL OXIDE 330 5% 2W F
R825 1-249-392-11 CARBON 8.2 5% 1/4W F
R829 1-215-421-00 METAL 1K 1% 1/4W
R831 1-215-887-00 METAL OXIDE 150 5% 2W F
R834 1-247-847-31 CARBON 4.7K 5% 1/4W
R851 1-249-382-11 CARBON 1.2 5% 1/4W F
R852 1-249-923-11 CARBON 1K 5% 1/4W F
R853 1-249-377-11 CARBON 0.47 5% 1/4W F
R854 1-249-377-11 CARBON 0.47 5% 1/4W F
R855 1-260-107-11 CARBON 4.7K 5% 1/2W
R856 1-247-855-31 CARBON 10K 5% 1/4W
R857 1-249-440-11 CARBON 82K 5% 1/4W
R858 1-216-370-11 METAL OXIDE 1.2 5% 2W F
R860 1-247-887-00 CARBON 220K 5% 1/4W
R883 1-215-466-00 METAL 75K 1% 1/4W
R895 1-216-349-00 METAL OXIDE 1 5% 1W F
A
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
