Sony RM-883 - Page 27

– 41 –
KV-B14PD1
RM-883
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
<JACK>
J251 1-770-786-11 JACK
J1201 1-770-660-11 JACK BLOCK, PIN 4P
J1202 1-695-238-11 JACK BLOCK, PIN 2P
<COIL>
L001 1-408-397-00 INDUCTOR 1UH
L002 1-410-509-51 INDUCTOR 10UH
L003 1-408-605-31 INDUCTOR 15UH
L101 1-410-470-11 INDUCTOR 10UH
L301 1-408-598-31 INDUCTOR 3.9UH
L401 1-410-498-11 INDUCTOR 1.2UH
L402 1-410-510-11 INDUCTOR 12UH
L406 1-410-507-11 INDUCTOR 6.8UH
L410 1-410-501-51 INDUCTOR 2.2UH
L802 1-412-527-11 INDUCTOR 15UH
L805 1-460-046-11 COIL, HORIZONTAL LINEARITY
L807 1-459-348-51 COIL, VAR, FERRITE (HWC)
L808 1-412-553-11 INDUCTOR 3.3MMH
L821 1-406-677-11 INDUCTOR 0UH
L850 1-408-947-00 INDUCTOR 2.2MMH
<TRANSISTOR>
Q030 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q108 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q109 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q110 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q202 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q207 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q208 8-729-030-02 TRANSISTOR DTC144ESA
Q209 8-729-029-92 TRANSISTOR DTC143ESA
Q210 8-729-029-92 TRANSISTOR DTC143ESA
Q301 8-729-029-66 TRANSISTOR DTC114ESA
Q303 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q402 8-729-922-66 TRANSISTOR 2SC2410SN
Q406 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q408 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q409 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q414 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q561 8-729-200-17 TRANSISTOR 2SA1091-R
Q801 8-729-140-50 TRANSISTOR 2SC3209LK
Q802 8-729-810-49 TRANSISTOR 2SD1877S-SONY-CA
Q902 8-729-030-02 TRANSISTOR DTC144ESA
Q903 8-729-030-02 TRANSISTOR DTC144ESA
Q1201 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1202 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1203 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1204 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q1207 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1208 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1209 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1513 8-729-119-78 TRANSISTOR 2SC2785-HFE
<RESISTOR>
R007 1-247-855-31 CARBON 10K 5% 1/4W
R008 1-220-958-81 METAL 1K 5% 1/2W
R010 1-220-958-81 METAL 1K 5% 1/2W
R012 1-249-401-11 CARBON 47 5% 1/4W
R013 1-220-958-81 METAL 1K 5% 1/2W
R015 1-220-958-81 METAL 1K 5% 1/2W
R016 1-220-958-81 METAL 1K 5% 1/2W
R017 1-220-961-81 METAL 2.2K 5% 1/2W
R018 1-249-409-11 CARBON 220 5% 1/4W
R019 1-247-883-00 CARBON 150K 5% 1/4W
R021 1-247-847-31 CARBON 4.7K 5% 1/4W
R026 1-220-961-81 METAL 2.2K 5% 1/2W
R027 1-247-847-31 CARBON 4.7K 5% 1/4W
R028 1-247-807-31 CARBON 100 5% 1/4W
R029 1-247-847-31 CARBON 4.7K 5% 1/4W
R031 1-220-958-81 METAL 1K 5% 1/2W
R033 1-220-958-81 METAL 1K 5% 1/2W
R035 1-220-958-81 METAL 1K 5% 1/2W
R036 1-220-958-81 METAL 1K 5% 1/2W
R038 1-249-409-11 CARBON 220 5% 1/4W
R040 1-249-409-11 CARBON 220 5% 1/4W
R041 1-247-807-31 CARBON 100 5% 1/4W
R042 1-249-412-11 CARBON 390 5% 1/4W
R045 1-220-961-81 METAL 2.2K 5% 1/2W
R047 1-247-807-31 CARBON 100 5% 1/4W
R048 1-247-807-31 CARBON 100 5% 1/4W
R054 1-247-855-31 CARBON 10K 5% 1/4W
R057 1-220-958-81 METAL 1K 5% 1/2W
R060 1-249-411-11 CARBON 330 5% 1/4W
R061 1-220-961-81 METAL 2.2K 5% 1/2W
R062 1-220-961-81 METAL 2.2K 5% 1/2W
R063 1-220-961-81 METAL 2.2K 5% 1/2W
R065 1-249-409-11 CARBON 220 5% 1/4W
R066 1-249-409-11 CARBON 220 5% 1/4W
R068 1-247-807-31 CARBON 100 5% 1/4W
R071 1-249-411-11 CARBON 330 5% 1/4W
R076 1-247-807-31 CARBON 100 5% 1/4W
R077 1-247-807-31 CARBON 100 5% 1/4W
R090 1-247-855-31 CARBON 10K 5% 1/4W
R101 1-247-847-31 CARBON 4.7K 5% 1/4W
R102 1-220-958-81 METAL 1K 5% 1/2W
R113 1-249-433-11 CARBON 22K 5% 1/4W
R114 1-247-823-31 CARBON 470 5% 1/4W
R115 1-249-433-11 CARBON 22K 5% 1/4W
R116 1-249-433-11 CARBON 22K 5% 1/4W
R117 1-249-433-11 CARBON 22K 5% 1/4W
R118 1-249-433-11 CARBON 22K 5% 1/4W
R119 1-220-960-81 METAL 1.8K 5% 1/2W
R120 1-247-891-00 CARBON 330K 5% 1/4W
R131 1-216-464-11 METAL OXIDE 18K 5% 2W F
R180 1-249-409-11 CARBON 220 5% 1/4W
R181 1-249-409-11 CARBON 220 5% 1/4W
R182 1-249-409-11 CARBON 220 5% 1/4W
R240 1-249-409-11 CARBON 220 5% 1/4W
R241 1-136-165-00 FILM 0.1MF 5% 50V
R242 1-249-410-11 CARBON 270 5% 1/4W
R243 1-247-855-31 CARBON 10K 5% 1/4W
R244 1-247-855-31 CARBON 10K 5% 1/4W
R245 1-249-426-11 CARBON 5.6K 5% 1/4W
R246 1-249-427-11 CARBON 6.8K 5% 1/4W
R247 1-247-839-31 CARBON 2.2K 5% 1/4W
R248 1-247-855-31 CARBON 10K 5% 1/4W
A
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
