Outline: Activate Audio Input Test
(Window1 ) Select Audio Input Test Category
Operation㧦
[LEFT] [RIGHT] Select Category
[DOWN][ENT] Activate the selected Category. [RET] Return to Service Top Menu.
(Window 2) Select Input Device
After “Audio Input Test” selects in window 1, the device to test is chosen.
Operation: [UP][DOWN] Select Device
[ENT] Activate and Start Test/Stop
[RET] Return to test category selection.
>Device Test :Device List
Digital Input1 㧦CXD9998 is inputted from DIR1
Digital Input2 㧦CXD9998 is inputted from DIR2
Analog Input 㧦CXD9998 is inputted from ADC >Audio Input Test:
8555 is inputted from DIR/analog and outputs LineOut(8ch) L and R.
Check tone sound by s
peaker connected with LineOut(8ch) L and R.
(Input; LPCM 48kHz 2ch) Front Panel Display:
Digital Audio Input Test Select: D-DI1
Digital Audio Input Test Select: D-DI2
Analog Audio Input Test Select: D-AIN
