Outline: Activate Wireless LAN Tests
(Window 1)Select Wireless LAN Test Category Operation: [LEFT] [RIGHT] Select Category
[DOWN][ENT] Activate the selected Category. [RET] Return to Service Top Menu.
(Window 2) Select Wireless LAN Test
Operation: [1] Show Wireless LAN module Information
[2] Connect Access Point
[3] Start display RSSI value.
[4] Start Ping Test
[UP][DOWN] Select Test
[ENT] Activate and Start Test
[RET] Return to test category selection.
> Show WLAN HwInfo 㧔
See Window 2)
Serial : Serial Number
Hard : Hardware Version Mac 㧦 Mac Address
> Connect to Access Point (See Window 3)
Connect Access Point only with the following AP settings.
Authentication method: NO-ENCRYPT
WEP key㧦 abcdef1234
SSID㧦 SONY-Test-R
PMK㧦 ABCDE12345 IP: 192.168.1.10 Net mask: 255.255.255.0 Broadcast㧦 192.168.1.255
࡮When connect to AP, Status is “Connected!”
When cannot connect to AP, Status is “can’t Connect!”
> Start Display RSSI Value (See Window 4)
Display RSSI value.
> Start Ping Test (See Window 5)
Ping Test.
IP address use the value of “192.168.
1.10”.
