BDP-BX39/S390
7-9
Diag Menu (Wireless LAN Test) <only Wireless Model>
Outline:
Activate Wireless LAN Tests
(Window 1)Select Wireless LAN Test Category
Operation:
[LEFT] [RIGHT] Select Category
[DOWN][ENT] Activate the selected Category.
[RET] Return to Service Top Menu.
(Window 2) Select Wireless LAN Test
Operation:
[1] Show Wireless LAN module Information
[2] Connect Access Point
[3] Start display RSSI value.
[4] Start Ping Test
[UP][DOWN] Select Test
[ENT] Activate and Start Test
[RET] Return to test category selection.
> Show WLAN HwInfo
See Window 2)
Serial : Serial Number
Hard : Hardware Version
Mac ： Mac Address
> Connect to Access Point (See Window 3)
Connect Access Point only with the following AP settings.
Authentication method: NO-ENCRYPT
WEP key： abcdef1234
SSID： SONY-Test-R
PMK： ABCDE12345
IP: 192.168.1.10
Net mask: 255.255.255.0
Broadcast： 192.168.1.255
・When connect to AP, Status is “Connected!”
When cannot connect to AP, Status is “can’t Connect!”
> Start Display RSSI Value (See Window 4)
Display RSSI value.
> Start Ping Test (See Window 5)
Ping Test.
IP address use the value of “192.168.1.10”.
(Window 1)
* Diag
Category: Wireless LAN Test
HELP: [(NUM)][RET]
(Window 2)
* Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
Serial: 200912313165535
Hard : 0x04
Mac : 00:01:36:23:FD:CF
HELP: [(NUM)][RET]
(Window 3)
* Diag
Category: WirelessLAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
CERT : NO-ENCRYPT
WEPKEY : abcdef1234
PMK : ABCDE12345
SSID : SONY-Test-R
IPADDR : 192.168.1.10
NETMASK: 255.255.255.0
BCADDR : 192.168.1.255
Status : Connected!
HELP: [(NUM)][RET]
(Window 4)
* Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Stop Display RSSI Value
[4] Start Ping Test
RSSI Value : 60
HELP: [(NUM)][RET]
(Window 5)
* Diag
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Stop Display RSSI Value
[4] Start Ping Test
Ping To : 192.168.1.10
PING 192.168.1.10 OK!
HELP: [(NUM)][RET]
