Sony RMT-D166P - MV-044; 8-2. ELECTRICAL PARTS LIST (continued)

8-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MV-044
C225 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C227 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C229 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C231 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C232 1-125-889-91 CAP, CHIP CERAMIC 2.2UF (2012) 10% 0V
C235 1-162-964-91 CAP,CHIP CERAMIC 1000PF B 10.00% 50V 0.001U
(1608)
C236 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C237 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C239 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C240 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C241 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C243 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C244 1-162-915-91 CAP, CERAMIC 10PF CH 0.50PF 50V
(NS575P(MX2/E32/U2/CA2/PX3/AR2/BR4)/NS355(BR4))
C244 1-162-916-91 CAP, CERAMIC 12PF CH 5.00% 50V
(1608)
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2)/
NS585P(ME2))
C245 1-162-916-91 CAP, CERAMIC 12PF CH 5.00% 50V
(1608)
(NS575P(MX2/E32/U2/CA2/PX3/AR2/BR4)/NS355(BR4))
C245 1-162-915-91 CAP, CERAMIC 10PF CH (1608) 0.50PF 50V
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2)/
NS585P(ME2))
C246 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C247 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C248 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C249 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C250 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C251 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C252 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C255 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C256 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C257 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C258 1-162-964-91 CAP,CHIP CERAMIC 1000PF B 10.00% 50V 0.001U
(1608)
C259 1-115-467-91 CAP, CHIP CERAMIC 0.22UF B 10.00% 10V
(1608)
C260 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C262 1-115-467-91 CAP, CHIP CERAMIC 0.22UF B 10.00% 10V
(1608)
C263 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C264 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C265 1-126-964-91 CAP, ELECT 10UF 20.00% 50V
C266 1-115-467-91 CAP, CHIP CERAMIC 0.22UF B 10.00% 10V
(1608)
C267 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
(EXCEPT NS355(BR4))
C268 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C269 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C270 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C273 1-162-927-91 CAP, CERAMIC 100PF CH 5.00% 50V
(1608)
C276 1-125-889-91 CAP, CHIP CERAMIC 2.2UF 10% 10V
(2012)
C280 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C281 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C296 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
(NS575P(MX2/E32/U2/CA2/PX3))
C297 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
(NS575P(MX2/E32/U2/CA2/PX3))
C298 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
(NS575P(MX2/E32/U2/CA2/PX3))
C299 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
(NS575P(MX2/E32/U2/CA2/PX3))
C501 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C502 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C507 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C509 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C510 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C511 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C512 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C513 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C514 1-107-826-91 CAP, CHIP CERAMIC 100000PF B 10.00% 16V 0.1U
C601 1-164-739-91 CAP, CERAMIC 560PF CH 5.00% 50V
(1608)
C602 1-164-739-91 CAP, CERAMIC 560PF CH 5.00% 50V
(1608)
C603 1-164-218-91 CAP,CERAMIC 180PF CH 5.00% 50V
(1608)
C604 1-164-218-91 CAP,CERAMIC 180PF CH 5.00% 50V
(1608)
C605 1-164-218-91 CAP,CERAMIC 180PF CH 5.00% 50V
(1608)
C606 1-164-218-91 CAP,CERAMIC 180PF CH 5.00% 50V
(1608)
C607 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C608 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C609 1-126-960-91 CAP, ELECT 1.0UF 20.00% 50V
C610 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C611 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C613 1-126-934-91 CAP, ELECT 220UF 20.00% 16V
C615 1-164-230-91 CAP,CERAMIC 220PF CH 5.00% 50V
(1608)
C616 1-164-230-91 CAP,CERAMIC 220PF CH 5.00% 50V
(1608)
C622 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C625 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2/CH/
AR2/BR4) (NS585P(ME2/CH)/NS507P(CH)/525P(CH))
C627 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2/CH/
AR2/BR4) (NS585P(ME2/CH)/NS507P(CH)/525P(CH))
