Sony RMT-D166P - MV-044; 8-2. ELECTRICAL PARTS LIST (continued)

8-8
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MV-044
C628 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C629 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C644 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C771 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C776 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C778 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C779 1-115-467-91 CAP, CHIP CERAMIC 0.22UF B 10.00% 10V
(1608)
C780 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C782 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C783 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
C784 1-104-660-91 CAP, ELECT 47UF 20.00% 16V
C789 1-115-467-91 CAP, CHIP CERAMIC 0.22UF B 10.00% 10V
(1608)
C790 1-162-970-91 CAP, CERAMIC 10000PF B 10.00% 25V 0.01U
(1608)
<CONNECTOR>
CN101 1-815-381-11 CONNECTOR, FPC/FFC 5P
CN103 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN104 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN201 1-818-274-11 CONNECTOR, BOARD TO BOARD 13P
CN204 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN205 1-568-953-11 PIN, CONNECTOR 4P
CN771 1-568-937-11 PIN, CONNECTOR 10P
<DIODE>
D508 8-719-071-15 DIODE HZM6.8ZWA1TL
D509 8-719-071-15 DIODE HZM6.8ZWA1TL
D601 8-719-914-47 DIODE DAN202K-T-146
D602 8-719-914-45 DIODE DAP202K-T-146
D604 8-719-988-61 DIODE 1SS355TE-17
<FERRITE>
FB176 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB201 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB202 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB203 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB204 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB205 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB206 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB215 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB249 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB251 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB252 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB255 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB290 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB291 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB292 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB293 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB294 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB295 1-469-118-21 FERRITE, EMI (SMD) (1608) 0UH %-3.3
FB525 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB555 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB1022 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB1023 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB1024 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB2036 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
FB2037 1-469-670-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
(NS575P(MX2/E32/U2/CA2/PX3))
FB2041 1-469-324-21 FERRITE, EMI (SMD) (2012) 0UH %-3.3
<FILTER>
FL207 1-234-177-21 FILTER, CHIP EMI 0UH %-3.3 0UH
(NS575P(U2/CA2/CH)/NS507P(CH)/
NS255P(CH)/NS585P(CH))
FL208 1-234-177-21 FILTER, CHIP EMI 0UH %-3.3 0UH
(NS575P(U2/CA2/CH)/NS507P(CH)/
NS255P(CH)/NS585P(CH))
FL209 1-233-893-21 FILTER, CHIP EMI
FL299 1-234-177-21 FILTER, CHIP EMI 0UH %-3.3
(NS575P(MX2/E32/U2/CA2/PX3))
<IC>
IC101 6-704-524-01 IC FAN8036L
IC102 6-704-471-01 IC CXD9780R
IC151 6-704-470-01 IC TK11233CMCL-G
IC201 6-704-472-01 IC CXD9781R
IC202 6-704-261-01 IC TK11225CMCL-G
IC204 6-804-726-01 IC MR27V1602F-1EGTN
(NS355:BR/NS501P/NS575P:US,CND,PX,E,MX,AR,BR)
IC204 6-804-728-01 IC MR27V1602F-1EJTN
(NS575P:AUS,ME,EA,IR/NS585P:ME2)
IC204 6-804-727-01 IC MR27V1602F-1EHTN
(NS507P:CH/NS525P:CH/NS575P:KR,HK,SP,TW,CH/NS585P:CH)
IC205 6-705-866-01 IC BR24L16FJ-WE2
IC206 6-705-929-01 IC K4S641632H-UC75T
IC207 6-705-515-01 IC AK4385VT-E2
IC208 6-702-302-01 IC TK11133CSCL-G
IC502 6-701-820-01 IC LA73053-TLM-E
IC503 8-759-662-86 IC NJM79M05DL1A(TE2)
IC601 8-759-249-16 IC NJM4558M-TE2
IC603 8-759-711-59 IC NJM78L05UA-TE1
IC605 6-600-009-01 IC TOTX179
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2/CH/
AR2/BR4) (NS507P(CH)/NS585P(ME2/CH)/NS525P(CH))
IC774 6-702-302-01 IC TK11133CSCL-G
<JACK>
J501 1-828-495-11 JACK BLOCK, PIN (NS575P(MX2/E32/ME2/ME5)
