Sony RMT-D166P - MV-044; 8-2. ELECTRICAL PARTS LIST (continued)

8-9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MV-044
J501 1-818-223-11 JACK BLOCK, PIN
(NS355(BR4)/NS525P(CH)/NS507P(CH)
(NS575P(AU2/ME2/EA4/IR2/U2/CA2/CH/AR2/BR4))
(NS585P(CH))
JS002 1-216-295-71 CONDUCTOR, CHIP (2012) 0
JS003 1-216-295-71 CONDUCTOR, CHIP (2012) 0
<WIRE CLIP>
LP101 1-780-019-11 WIRE CLIP
(NS525P(CH)/NS507P(CH)
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2/CH))
(NS585P(ME2/CH))
LP601 1-780-019-11 WIRE CLIP
(NS525P(CH)/NS507P(CH)
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2/CH)
(NS585P(ME2/CH)
LP701 1-780-019-11 WIRE CLIP
LP702 1-780-019-11 WIRE CLIP (NS575P(MX2/E32/U2/CA2/PX3))
<IC LINK>
PS771 1-576-509-21 RINK, IC 1A
PS772 1-576-509-21 RINK, IC 1A
<TRANSISTOR>
Q168 8-729-424-63 TRANSISTOR UN2212-TX
Q170 6-550-008-01 TRANSISTOR UM6K1N-TN
Q171 6-550-653-01 TRANSISTOR QST8TR
Q504 8-729-024-89 TRANSISTOR MUN2213T1
Q505 8-729-024-83 TRANSISTOR MUN2111T1
Q601 8-729-010-10 TRANSISTOR MSB710-RT1
Q602 8-729-024-89 TRANSISTOR MUN2213T1
Q603 8-729-010-25 TRANSISTOR MSD601-RT1
Q604 8-729-424-72 TRANSISTOR UN2217-QRS-TX
Q605 8-729-010-05 TRANSISTOR MSB709-RT1
Q607 6-550-137-01 TRANSISTOR2SD1938(F)-ST(TX).SO
Q608 6-550-137-01 TRANSISTOR2SD1938(F)-ST(TX).SO
Q611 8-729-010-25 TRANSISTOR MSD601-RT1
Q616 8-729-010-05 TRANSISTOR MSB709-RT1
Q772 8-729-048-28 TRANSISTOR 2SD1766-T100-QR
Q773 8-729-424-11 TRANSISTOR UN2111-TX
<RESISTOR>
R101 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R102 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R103 1-216-839-91 RES, CHIP 33K (1608) 1/10W 5%
R104 1-216-839-91 RES, CHIP 33K (1608) 1/10W 5%
R107 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R109 1-216-834-91 RES, CHIP 12K (1608) 1/10W 5%
R110 1-216-822-91 RES, CHIP 1.2K (1608) 1/10W 5%
R111 1-216-835-91 RES, CHIP 15K (1608) 1/10W 5%
R112 1-216-826-91 RES, CHIP 2.7K (1608) 1/10W 5%
R114 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R117 1-216-834-91 RES, CHIP 12K (1608) 1/10W 5%
R119 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R120 1-218-895-91 RES, CHIP 100K (1608) 1/10W 0.5%
R121 1-218-895-91 RES, CHIP 100K (1608) 1/10W 0.5%
R122 1-218-889-91 RES, CHIP 56K (1608) 1/10W 0.5%
R123 1-218-889-91 RES, CHIP 56K (1608) 1/10W 0.5%
R124 1-216-831-91 RES, CHIP 6.8K (1608) 1/10W 5%
R126 1-216-838-91 RES, CHIP 27K (1608) 1/10W 5%
R127 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R128 1-216-839-91 RES, CHIP 33K (1608) 1/10W 5%
R129 1-218-893-91 RES, CHIP 82K (1608) 1/10W 0.5%
R130 1-218-877-91 RES, CHIP 18K (1608) 1/10W 0.5%
R131 1-218-883-91 RES, CHIP 33K (1608) 1/10W 0.5%
R132 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R133 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R134 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R136 1-218-875-91 RES, CHIP 15K (1608) 1/10W 0.5%
R155 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R156 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R157 1-216-829-91 RES, CHIP 4.7K (1608) 1/10W 5%
R158 1-216-829-91 RES, CHIP 4.7K (1608) 1/10W 5%
R159 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R160 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R172 1-216-845-91 RES, CHIP 100K (1608) 1/10W 5%
R173 1-216-845-91 RES, CHIP 100K (1608) 1/10W 5%
R175 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R178 1-211-977-91 RES, CHIP 22 (1608) 1/10W 0.5%
R179 1-216-801-91 RES, CHIP 22 (1608) 1/10W 5%
R180 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R181 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R182 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R183 1-211-977-91 RES, CHIP 22 (1608) 1/10W 0.5%
R184 1-211-977-91 RES, CHIP 22 (1608) 1/10W 0.5%
R185 1-216-857-91 RES, CHIP 1.0M (1608) 1/10W 5%
R186 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R187 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R188 1-216-801-91 RES, CHIP 22 (1608) 1/10W 5%
R189 1-216-801-91 RES, CHIP 22 (1608) 1/10W 5%
R190 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R191 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R192 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R194 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R195 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R197 1-216-829-91 RES, CHIP 4.7K (1608) 1/10W 5%
R198 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R199 1-216-835-91 RES, CHIP 15K (1608) 1/10W 5%
R201 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R208 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R213 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R216 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R220 1-216-832-91 RES, CHIP 8.2K (1608) 1/10W 5%
R221 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R222 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R223 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R224 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R225 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R226 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R227 1-216-845-91 RES, CHIP 100K (1608) 1/10W 5%
R229 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R244 1-216-836-91 RES, CHIP 18K (1608) 1/10W 5%
Note :
The components identified by
mark
or dotted line with mark
are critical for safety.
Replace only with part number
specified.
