Sony RMT-D166P - MV-044; 8-2. ELECTRICAL PARTS LIST (continued)

8-10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MV-044
R247 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R248 1-216-845-91 RES, CHIP 100K (1608) 1/10W 5%
R253 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R258 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R260 1-216-801-91 RES, CHIP 22 (1608) 1/10W 5%
R261 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R263 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R264 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R265 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R266 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R267 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R268 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R272 1-469-836-21 INDUCTOR, 0UH %-3.3
FERRITE BEAD
(NS575P(MX2/E32/U2/CA2/PX3))
R272 1-216-864-91 CONDUCTOR, CHIP (1608) 0
(NS575P(AU2/ME2/EA4/IR2/ME5/
SP6/TW1/HK2/KR2/CH/AR2/BR4))
(NS585P(ME2/CH)/NS355(BR4)/
NS525P(CH)/NS507P(CH))
R276 1-218-841-91 RES, CHIP 560 (1608) 1/10W 0.5%
R279 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R280 1-216-826-91 RES, CHIP 2.7K (1608) 1/10W 5%
R284 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R285 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R286 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R287 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R288 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R289 1-202-930-91 RES, CHIP 750K (1608) 1/10W 5%
R298 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R521 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R527 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R528 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R529 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R530 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R532 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R533 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R534 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R535 1-211-990-91 RES, CHIP 75 (1608) 1/10W 0.5%
R547 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R548 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R549 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R554 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R556 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R557 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R575 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R582 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R598 1-216-295-71 CONDUCTOR, CHIP (2012) 0
R601 1-208-798-91 RES, CHIP 4.7K (2012) 1/10W 0.5%
R602 1-208-798-91 RES, CHIP 4.7K (2012) 1/10W 0.5%
R603 1-208-798-91 RES, CHIP 4.7K (2012) 1/10W 0.5%
R604 1-208-798-91 RES, CHIP 4.7K (2012) 1/10W 0.5%
R605 1-208-800-91 RES, CHIP 5.6K (2012) 1/10W 0.5%
R606 1-208-800-91 RES, CHIP 5.6K (2012) 1/10W 0.5%
R607 1-216-825-91 RES, CHIP 2.2K (1608) 1/10W 5%
R608 1-216-825-91 RES, CHIP 2.2K (1608) 1/10W 5%
R609 1-216-825-91 RES, CHIP 2.2K (1608) 1/10W 5%
R610 1-216-825-91 RES, CHIP 2.2K (1608) 1/10W 5%
R611 1-208-800-91 RES, CHIP 5.6K (2012) 1/10W 0.5%
R612 1-208-800-91 RES, CHIP 5.6K (2012) 1/10W 0.5%
R613 1-216-829-91 RES, CHIP 4.7K (1608) 1/10W 5%
R616 1-216-830-91 RES, CHIP 5.6K (1608) 1/10W 5%
R617 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R618 1-216-845-91 RES, CHIP 100K (1608) 1/10W 5%
R619 1-216-849-91 RES, CHIP 220K (1608) 1/10W 5%
R620 1-216-817-91 RES, CHIP 470 (1608) 1/10W 5%
R621 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R622 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R624 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R625 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R626 1-216-817-91 RES, CHIP 470 (1608) 1/10W 5%
R627 1-216-817-91 RES, CHIP 470 (1608) 1/10W 5%
R628 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R629 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R630 1-216-841-91 RES, CHIP 47K (1608) 1/10W 5%
R634 1-216-829-91 RES, CHIP 4.7K (1608) 1/10W 5%
R635 1-216-829-91 RES, CHIP 4.7K (1608) 1/10W 5%
R638 1-216-845-91 RES, CHIP 100K (1608) 1/10W 5%
R640 1-216-817-91 RES, CHIP 470 (1608) 1/10W 5%
R641 1-216-817-91 RES, CHIP 470 (1608) 1/10W 5%
R642 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R643 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R649 1-216-813-91 RES, CHIP 220 (1608) 1/10W 5%
R651 1-216-807-91 RES, CHIP 68 (1608) 1/10W 5%
R652 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R653 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R654 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R656 1-216-821-91 RES, CHIP 1.0K (1608) 1/10W 5%
R668 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R684 1-216-830-91 RES, CHIP 5.6K (1608) 1/10W 5%
R775 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R776 1-216-827-91 RES, CHIP 3.3K (1608) 1/10W 5%
R777 1-216-827-91 RES, CHIP 3.3K (1608) 1/10W 5%
R787 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R1015 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
R1018 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R1021 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R1026 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R1027 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R1031 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R2019 1-216-809-91 RES, CHIP 100 (1608) 1/10W 5%
(EXCEPT NS355(BR4))
R2027 1-216-864-91 CONDUCTOR, CHIP (1608) 0
R2028 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
R2030 1-216-833-91 RES, CHIP 10K (1608) 1/10W 5%
(EXCEPT NS355(BR4))
R2031 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R2032 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R2033 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R2034 1-216-805-91 RES, CHIP 47 (1608) 1/10W 5%
R2035 1-216-864-91 CONDUCTOR, CHIP (1608) 0 (NS355(BR4))
R2036 1-216-295-71 CONDUCTOR, CHIP (2012) 0
<RES, NETWORK>
RB204 1-234-371-21 RES, NETWORK 47X4 (1005) 1/32W 5% 47
RB205 1-234-371-21 RES, NETWORK 47X4 (1005) 1/32W 5% 47
RB206 1-234-371-21 RES, NETWORK 47X4 (1005) 1/32W 5% 47
<SWITCH>
S501 1-762-636-11 SWITCH, SLIDE (EXCEPT NS355(BR4)
