Sony RMT-D166P - MV-044; 8-2. ELECTRICAL PARTS LIST (continued)

8-11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MV-044
<CRYSTAL>
X202 1-813-219-11 QUARTZ CRYSTAL UNIT
(NS575P(MX2/E32/U2/CA2/PX3/AR2/BR4)/NS355(BR4))
X202 1-813-218-21 VIBRATOR, CRYSTAL
(NS575P(AU2/ME2/EA4/IR2/ME5/SP6/TW1/HK2/KR2/CH)
(NS585P(ME2)/NS507P(CH)/NS525P(CH))
1-478-538-11 POWER BLOCK (SRV1487UC) (U2/CA2/MX2)
*************************************
<DIODE>
D101 9-885-052-71 DOIDE 600V 1A
D102 9-885-052-71 DOIDE 600V 1A
D103 9-885-052-71 DOIDE 600V 1A
<IC>
IC101 9-885-052-72 IPD
<PHOTO COUPLER>
PC101 9-885-052-73 PHOTO COUPLER
<ALUMINUM ELECTRIC CAPACITOR>
C107 9-885-052-76 ALUMINUM 82UF 200V
ELECTRIC CAPACITOR
<FUSE>
F101 9-885-052-78 FUSE 125V 2A
<CHIP FUSE>
P311 9-885-052-80 CHIP FUSE 2A
P312 9-885-052-81 CHIP FUSE 2A
1-478-539-12 POWER BLOCK (SRV1501WW) (GA)
******************************
<DIODE>
D101 9-885-052-71 DOIDE 600V 1A
D102 9-885-052-71 DOIDE 600V 1A
D103 9-885-052-71 DOIDE 600V 1A
<IC>
IC101 9-885-052-82 IPD
<PHOTO COUPLER>
PC101 9-885-052-73 PHOTO COUPLER
<ALUMINUM ELECTRIC CAPACITOR>
C107 9-885-052-77 ALUMINUM 120UF 400V
ELECTRIC CAPACITOR
<FUSE>
P101 9-885-052-79 FUSE 250V 2A
<CHIP FUSE>
P311 9-885-052-80 CHIP FUSE 2A
P312 9-885-052-81 CHIP FUSE 2A
ACCESSORIES
*************
1-478-545-11 REMOTE COMMANDER (RMT-D165A)
1-478-545-31 REMOTE COMMANDER (RMT-D165P)
1-478-545-41 REMOTE COMMANDER (RMT-D166P)
1-828-450-11 CORD, POWER
(DVP-NS575P/NS585P: E32/IR2/ME2/ME5/PX3/SP6)
1-828-451-11 CORD, POWER (DVP-NS501P/NS575P: CA2/MX2/U2)
1-828-452-11 CORD, POWER (DVP-NS575P: AU2)
1-828-454-11 CORD, POWER (DVP-NS575P: EA4/HK2)
1-828-455-11 CORD, POWER
(DVP-NS575P/NS585P: E32/IR2/ME2/ME5/PX3/SP6)
1-828-846-11 CORD, POWER (DVP-NS575P: EA4/HK2)
1-828-456-11 CORD, POWER (DVP-NS501P/NS575P: CA2/MX2/U2)
1-828-457-11 CORD, POWER (DVP-NS575P: AU2)
1-828-845-11 CORD, POWER (DVP-NS575P: TW1)
1-828-871-11 CORD, POWER (DVP-NS575P: KR2)
2-050-982-11 INSTRUCTION MANUAL (DVP-NS501P: U2)
3-088-491-12 INSTRUCTION MANUAL (DVP-NS575P: E32/MX2)
3-088-492-12 INSTRUCTION MANUAL
(DVP-NS501P/NS575P: CA2/PX3/U2)
3-088-492-22 INSTRUCTION MANUAL (DVP-NS575P: CA2)
3-088-493-12 INSTRUCTION MANUAL (DVP-NS575P: AU2)
3-088-493-22 INSTRUCTION MANUAL (DVP-NS575P: HK2)
3-088-493-32 INSTRUCTION MANUAL (DVP-NS575P: TW1)
3-088-493-42 INSTRUCTION MANUAL (DVP-NS575P: KR1)
3-088-493-52 INSTRUCTION MANUAL (DVP-NS575P: ME5)
3-088-493-62 INSTRUCTION MANUAL (DVP-NS575P: HK2/SP6/ME5)
3-088-495-12 INSTRUCTION MANUAL
(DVP-NS575P/NS585P: EA4/IR2/ME2)
3-088-495-22 INSTRUCTION MANUAL (DVP-NS575P/NS585P: EA4/ME2)
3-088-495-32 INSTRUCTION MANUAL (DVP-NS575P/NS585P: IR2/ME2)
Note :
The components identified by
mark
or dotted line with mark
are critical for safety.
Replace only with part number
specified.
