Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-WMSP1
J103 1-793-446-11 JACK, PIN 1P (LINE)
(US,MX,SP,CND,AEP,UK,AUS)
< TRANSISTOR >
Q301 8-729-029-86 TRANSISTOR DTC124ESA
Q302 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q303 8-729-178-42 TRANSISTOR 2SC2784-F
Q304 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q401 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R110 1-249-441-11 CARBON 100K 5% 1/4W
R111 1-249-429-11 CARBON 10K 5% 1/4W
R112 1-249-441-11 CARBON 100K 5% 1/4W
R113 1-249-429-11 CARBON 10K 5% 1/4W
R114 1-247-887-00 CARBON 220K 5% 1/4W
R115 1-249-441-11 CARBON 100K 5% 1/4W
R116 1-249-429-11 CARBON 10K 5% 1/4W
R117 1-247-895-00 CARBON 470K 5% 1/4W
R208 1-249-441-11 CARBON 100K 5% 1/4W
R211 1-249-429-11 CARBON 10K 5% 1/4W
R212 1-249-433-11 CARBON 22K 5% 1/4W
R213 1-249-433-11 CARBON 22K 5% 1/4W
R216 1-247-887-00 CARBON 220K 5% 1/4W
R301 1-249-425-11 CARBON 4.7K 5% 1/4W F
R302 1-249-433-11 CARBON 22K 5% 1/4W
R303 1-249-411-11 CARBON 330 5% 1/4W
R304 1-249-433-11 CARBON 22K 5% 1/4W
R305 1-249-435-11 CARBON 33K 5% 1/4W
R307 1-249-385-11 CARBON 2.2 5% 1/6W F
R308 1-215-868-00 METAL OXIDE 680 5% 1W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R310 1-249-433-11 CARBON 22K 5% 1/4W
R311 1-249-441-11 CARBON 100K 5% 1/4W
R312 1-249-441-11 CARBON 100K 5% 1/4W
R313 1-249-437-11 CARBON 47K 5% 1/4W
R314 1-249-430-11 CARBON 12K 5% 1/4W
R401 1-215-892-11 METAL OXIDE 1K 5% 2W
R402 1-215-892-11 METAL OXIDE 1K 5% 2W
R405 1-249-429-11 CARBON 10K 5% 1/4W
R406 1-215-894-11 METAL OXIDE 2.2K 5% 2W
< RELAY >
RY301 1-515-920-11 RELAY (24V)
< SWITCH >
0 S2 1-762-753-11 SWITCH, VOLTAGE SELECTION (E)
< TRANSFORMER >
0 T1 1-435-879-11 TRANSFORMER, POWER (US,MX,CND)
0 T1 1-435-880-11 TRANSFORMER, POWER (SP,AEP,UK)
0 T1 1-435-881-11 TRANSFORMER, POWER (E,AUS)
**************************************************************
1-680-717-13 POWER IC BOARD
***************
< CAPACITOR >
C302 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN303 1-785-088-11 PIN, CONNECTOR 6P
< IC >
IC301 8-759-299-54 IC LM3886TF
< RESISTOR >
R306 1-249-435-11 CARBON 33K 5% 1/4W
**************************************************************
1-680-715-13 SWITCH BOARD
**************
< CAPACITOR >
0 C1 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
< CONNECTOR >
CN3 1-564-321-00 PIN, CONNECTOR 2P
< SWITCH >
0 S1 1-554-920-11 SWITCH, PUSH (AC POWER)(1 KEY)(POWER)
**************************************************************
MISCELLANEOUS
***************
0 58 1-696-845-31 CORD, POWER (AUS)
0 58 1-777-071-11 CORD, POWER (SP,AEP,UK)
0 58 1-783-525-11 CORD, POWER (TRACKING)(E)
0 58 1-783-820-11 CORD, POWER (US,MX,CND)
0 F1 1-532-500-31 FUSE (T680mAL/250V)(SP,AEP,UK)
0 F1 1-532-502-31 FUSE (T1.25AL/250V)(E)
0 F1 1-533-614-11 FUSE, GLASS CYLINDERICAL (1.6A/125V)
(US,MX,CND)
0 F2 1-532-499-31 FUSE (T400mAL/250V)(E,AUS)
0 T1 1-435-879-11 TRANSFORMER, POWER (US,MX,CND)
0 T1 1-435-880-11 TRANSFORMER, POWER (SP,AEP,UK)
0 T1 1-435-881-11 TRANSFORMER, POWER (E,AUS)
SP101 1-529-995-11 SPEAKER (20CM)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
4-914-518-11 SCREW (4X14),(+)(B) TAPPING (SILVER)(CND)
SWITCH
MAIN POWER IC
The components identified by mark 0 or
dotted line with mark 0 are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.
