Sony SA-WMSP1 User Manual

7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-WMSP1
SECTION 4
ELECTRICAL PARTS LIST
1-680-714-13 CONTROL BOARD
***************
< CAPACITOR >
C205 1-126-963-11 ELECT 4.7uF 20.00% 50V
C208 1-104-664-11 ELECT 47uF 20.00% 25V
C209 1-104-664-11 ELECT 47uF 20.00% 25V
C210 1-126-965-11 ELECT 22uF 20.00% 50V
C214 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C215 1-136-153-00 FILM 0.01uF 5% 50V
C216 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C217 1-102-110-00 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN201 1-785-093-11 PIN, CONNECTOR 8P
< IC >
IC202 8-759-634-50 IC M5218AL
< VARIABLE RESISTOR >
RV202 1-227-364-11 RES, VAR, CARBON 20K (LEVEL)
**************************************************************
1-680-716-13 LED BOARD
**********
< CONNECTOR >
* CN203 1-564-517-11 PLUG, CONNECTOR 2P
< DIODE >
D201 8-719-058-03 DIODE SEL5423E-TP15 (POWER)
**************************************************************
1-680-713-13 MAIN BOARD
***********
< CAPACITOR >
0 C2 1-113-924-11 CERAMIC 0.0047uF 20.00% 250V
C101 1-126-964-11 ELECT 10uF 20.00% 50V
C103 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C104 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C301 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C303 1-126-933-11 ELECT 100uF 20.00% 16V
C304 1-136-153-00 FILM 0.01uF 5% 50V
C305 1-126-967-11 ELECT 47uF 20.00% 50V
C306 1-126-967-11 ELECT 47uF 20.00% 50V
C307 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C308 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C309 1-126-934-11 ELECT 220uF 20.00% 10V
C310 1-126-949-11 ELECT 220uF 20.00% 35V
C311 1-126-963-11 ELECT 4.7uF 20.00% 50V
C312 1-126-964-11 ELECT 10uF 20.00% 50V
C320 1-102-110-00 CERAMIC 220PF 10% 50V
C401 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C402 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C403 1-126-974-11 ELECT 3300uF 20.00% 50V
C404 1-126-974-11 ELECT 3300uF 20.00% 50V
C405 1-104-665-11 ELECT 100uF 20.00% 25V
C406 1-104-665-11 ELECT 100uF 20.00% 25V
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR 2P
* CN2 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN101 1-785-093-11 PIN, CONNECTOR 8P
* CN301 1-565-792-11 PIN, CONNECTOR 2P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77
D401 8-719-500-56 DIODE D3SBA20
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-947-61 DIODE MTZJ-T-72-15B
D404 8-719-947-61 DIODE MTZJ-T-72-15B
< FUSE >
0 F1 1-532-500-31 FUSE (T680mAL/250V)(SP,AEP,UK)
0 F1 1-532-502-31 FUSE (T1.25AL/250V)(E)
0 F1 1-533-614-11 FUSE, GLASS CYLINDERICAL (1.6A/125V)
(US,MX,CND)
0 F2 1-532-499-31 FUSE (T400mAL/250V)(E,AUS)
< IC >
IC101 8-759-634-50 IC M5218AL
< JACK >
J103 1-770-377-31 JACK, PIN 1P(E)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
SP : Singapore model
MX : Mexican model
AUS : Australia model
When indicating parts by reference number,
please include the board name.
CONTROL
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
LED
