1-3. Printed Wiring Board – MAIN Section –
• See page 3 for Circuit Boards Location.
•
: Uses unleaded solder.
Ref. No. Location
D205 C-3
D206 C-3
D301 E-4
D302 E-4
D304 D-2
D401 F-2
D402 F-2
D403 E-2
D501 E-2
D502 E-4
D602 C-2
IC202 B-3
IC203 B-3
IC301 D-4
Q501 D-2
Q502 D-2
Q503 D-2
Q504 D-2
Q505 E-4
• Semiconductor
Location
IC202
IC301
IC203
INPUT
CN402
WMSP75 : 3P
WMSP85 : 6P
SP1
WMSP85
WMSP75
WMSP85
WMSP85
WMSP75
WMSP75
5
4
1
8
5
4
1
8
(11)
11
POWER TRANS
()
12
A
B
C
D
E
F
G
345678
