SECTION 3
ELECTRICAL PARTS LIST
SA-WMSP75/WMSP85
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Abbreviation
AUS: Australian model
E2 : 120V AC Area in E model
CND : Canadian model
MX : Malaysia model
SP : Singapore model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
CONTROL
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
CONTROL BOARD
**************
< CAPACITOR >
C801 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CNP801 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< VARIABLE RESISTOR >
RV801 1-227-511-11 RES, VAR, CARBON 20K (LEVEL)
************************************************************
INPUT (CONTROL) BOARD
*********************
< CAPACITOR >
C101 1-128-813-11 CERAMIC 220PF 5% 50V
C201 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
* CN101 1-506-944-11 PIN, CONNECTOR 2P
< JACK >
J101 1-815-025-11 JACK, PIN 1P (INPUT)
< RESISTOR >
R110 1-249-441-11 CARBON 100K 5% 1/4W
R202 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
A-4731-189-A MAIN BOARD, COMPLETE (WMSP75)
*********************
A-4731-195-A MAIN BOARD, COMPLETE (WMSP85)
*********************
< CAPACITOR >
C203 1-136-165-00 FILM 0.1uF 5% 50V
C204 1-136-165-00 FILM 0.1uF 5% 50V
C205 1-126-964-11 ELECT 10uF 20.00% 50V
C206 1-126-964-11 ELECT 10uF 20.00% 50V
C207 1-131-679-31 FILM 0.01uF 5% 50V
C208 1-131-696-11 FILM 0.22uF 5% 50V
C209 1-128-813-11 CERAMIC 220PF 5% 50V
C210 1-126-964-11 ELECT 10uF 20.00% 50V
C211 1-128-813-11 CERAMIC 220PF 5% 50V
C301 1-128-813-11 CERAMIC 220PF 5% 50V
C302 1-126-964-11 ELECT 10uF 20.00% 50V
C303 1-104-665-11 ELECT 100uF 20.00% 10V
C304 1-126-968-11 ELECT 100uF 20.00% 50V
C305 1-126-968-11 ELECT 100uF 20.00% 50V
C306 1-126-964-11 ELECT 10uF 20.00% 50V
C307 1-126-967-11 ELECT 47uF 20.00% 50V
C308 1-126-964-11 ELECT 10uF 20.00% 50V
C309 1-136-165-00 FILM 0.1uF 5% 50V
C310 1-136-165-00 FILM 0.1uF 5% 50V
C311 1-162-199-31 CERAMIC 10PF 5% 50V
C312 1-128-813-11 CERAMIC 220PF 5% 50V
C313 1-128-813-11 CERAMIC 220PF 5% 50V
C401 1-136-165-00 FILM 0.1uF 5% 50V
C402 1-136-165-00 FILM 0.1uF 5% 50V
C403 1-126-974-11 ELECT 3300uF 20.00% 50V
(WMSP75)
C403 1-104-482-11 ELECT 4700uF 20.00% 63V
(WMSP85)
C404 1-126-974-11 ELECT 3300uF 20.00% 50V
(WMSP75 )
C404 1-104-482-11 ELECT 4700uF 20.00% 63V
(WMSP85)
C405 1-104-665-11 ELECT 100uF 20.00% 25V
(WMSP75)
C405 1-126-968-11 ELECT 100uF 20.00% 50V
(WMSP85)
C406 1-104-665-11 ELECT 100uF 20.00% 25V
(WMSP75)
C406 1-126-968-11 ELECT 100uF 20.00% 50V
(WMSP85)
C407 1-126-971-11 ELECT 470uF 20.00% 50V
(WMSP85)
C408 1-126-971-11 ELECT 470uF 20.00% 50V
(WMSP85)
C409 1-136-165-00 FILM 0.1uF 5% 50V
(WMSP85)
C410 1-136-165-00 FILM 0.1uF 5% 50V
(WMSP85)
C501 1-126-964-11 ELECT 10uF 20.00% 50V
C502 1-126-949-11 ELECT 220uF 20.00% 35V
MAIN
INPUT(CONTROL)
