Sony SA-WP780 - SECTION 3 ELECTRICAL PARTS LIST

11
SA-WP780
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
AR : Argentine model
AUS: Australian model
CND : Canadian model
E51 : Chilean and Peruvian models
RU : Russian model
SP : Singapore model
SP6 : Singapore and Malaysia models
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
INPUT CONTROL BOARD
********************
< CAPACITOR >
C801 1-128-813-11 CERAMIC 220PF 5% 50V
< JACK >
J101 1-815-025-11 JACK, PIN 1P
< RESISTOR >
R801 1-247-879-91 CARBON 100K 5% 1/4W
< VARIABLE RESISTOR >
RV801 1-227-511-11 RES, VAR, CARBON 20K
*************************************************************
LED BOARD
*********
< CAPACITOR >
C601 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CNP901 1-564-505-11 PLUG, CONNECTOR 2P
< DIODE >
D901 6-501-077-01 DIODE LNH301MPU0A1
*************************************************************
A-1156-567-A MAIN BOARD, COMPLETE
(EXCEPT E51, SP, AR)
A-1175-815-A MAIN BOARD, COMPLETE (E51)
A-1237-500-A MAIN BOARD, COMPLETE (SP)
A-1237-502-A MAIN BOARD, COMPLETE (AR)
*********************
< CAPACITOR >
C120 1-126-933-11 ELECT 100uF 20% 16V
C121 1-126-933-11 ELECT 100uF 20% 16V
C122 1-127-888-11 CERAMIC 0.1uF 10% 50V
C123 1-127-888-11 CERAMIC 0.1uF 10% 50V
C127 1-126-947-11 ELECT 47uF 20% 25V
C128 1-126-947-11 ELECT 47uF 20% 25V
C201 1-126-964-11 ELECT 10uF 20% 50V
C203 1-137-190-91 FILM 0.22uF 5% 50V
C204 1-137-190-91 FILM 0.22uF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-136-157-00 FILM 0.022uF 5% 50V
C208 1-136-175-00 FILM 0.68uF 5% 50V
C209 1-128-813-11 CERAMIC 220PF 5% 50V
C210 1-127-888-11 CERAMIC 0.1uF 10% 50V
C211 1-128-813-11 CERAMIC 220PF 5% 50V
C212 1-127-888-11 CERAMIC 0.1uF 10% 50V
C301 1-128-813-11 CERAMIC 220PF 5% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-104-658-91 ELECT 100uF 20% 10V
C304 1-128-813-11 CERAMIC 220PF 5% 50V
C305 1-128-825-11 CERAMIC 2200PF 5% 50V
C306 1-102-973-00 CERAMIC 100PF 5% 50V
C307 1-128-560-11 ELECT 22uF 20% 100V
C308 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C309 1-126-947-11 ELECT 47uF 20% 35V
C310 1-128-560-11 ELECT 22uF 20% 100V
C313 1-101-880-00 CERAMIC 47PF 5% 50V
C318 1-127-880-11 CERAMIC 0.022uF 10% 50V
C319 1-101-810-00 CERAMIC 100PF 5% 500V
C320 1-101-810-00 CERAMIC 100PF 5% 500V
C321 1-128-825-11 CERAMIC 2200PF 5% 50V
C322 1-128-813-11 CERAMIC 220PF 5% 50V
C401 1-130-777-00 MYLAR 0.1uF 5% 100V
C402 1-130-777-00 MYLAR 0.1uF 5% 100V
C403 1-127-813-11 ELECT 3300uF 20% 71V
(EXCEPT E51)
C403 1-127-814-11 ELECT 3300uF 20% 80V
(E51)
C404 1-127-813-11 ELECT 3300uF 20% 71V
(EXCEPT E51)
C404 1-127-814-11 ELECT 3300uF 20% 80V
(E51)
C407 1-126-971-11 ELECT 470uF 20% 50V
C408 1-126-971-11 ELECT 470uF 20% 50V
C409 1-127-888-11 CERAMIC 0.1uF 10% 50V
C410 1-127-888-11 CERAMIC 0.1uF 10% 50V
C504 1-126-965-91 ELECT 22uF 20% 50V
C505 1-127-880-11 CERAMIC 0.022uF 10% 50V
C506 1-104-658-91 ELECT 100uF 20% 10V
C507 1-127-880-11 CERAMIC 0.022uF 10% 50V
C508 1-126-963-11 ELECT 4.7uF 20% 50V
C509 1-126-967-11 ELECT 47uF 20% 50V
C510 1-126-967-11 ELECT 47uF 20% 50V
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
LED MAIN
INPUT CONTROL
Ver. 1.3
