13
SA-WP780
Ref. No. Part No. Description Remark
POWER TRANS BOARD
******************
< CONNECTOR >
* CN1 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE (E51)
FH902 1-533-217-41 HOLDER, FUSE (E51)
FH903 1-533-217-41 HOLDER, FUSE
FH904 1-533-217-41 HOLDER, FUSE
FH905 1-533-217-41 HOLDER, FUSE (E51)
FH906 1-533-217-41 HOLDER, FUSE (E51)
< SWITCH >
0 S2 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR) (E51)
*************************************************************
SWITCH BOARD
*************
< CAPACITOR >
0 C901 1-117-703-11 CERAMIC 0.0047uF 99% 250V
< CONNECTOR >
* CN3 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN20 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< SWITCH >
0 S901 1-572-267-51 SWITCH, PUSH (AC POWER) (1 KEY)
*************************************************************
MISCELLANEOUS
**************
0 3 1-696-848-81 CORD, POWER (AUS)
0 3 1-777-071-23 CORD, POWER (AEP, UK, RU, E51, SP, SP6)
0 3 1-783-820-11 CORD, POWER (US, CND)
0 3 1-783-941-12 CORD, POWER (AR)
0 F900 1-532-463-33 FUSE T1AL/250V (E51)
0 F901 1-532-463-33 FUSE T1AL/250V
(AEP, UK, RU, SP, SP6, AUS, AR)
0 F901 1-533-690-12 FUSE, GLASS CYLINDRICAL 3.15A/125V(DIA.5)
(US, CND, E51)
0 F902 1-532-463-33 FUSE T1AL/250V (E51)
Q307 6-702-391-01 IC MP1620-OPY-MK
Q308 6-702-390-01 IC MN2488-OPY-MK
SP1 1-826-412-11 LOUDSPEAKER (20cm)
0 T1 1-443-883-11 TRANSFORMER, POWER (E51)
0 T1 1-443-885-21 TRANSFORMER, POWER (US, CND)
0 T1 1-443-886-21 TRANSFORMER, POWER
(AEP, UK, RU, SP, SP6, AUS, AR)
POWER TRANS SWITCH
Ver. 1.3
