Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
85
SCD-XB770
D916 8-719-210-39 DIODE EC10QS-04
D917 8-719-210-33 DIODE EC10DS2
D918 8-719-210-33 DIODE EC10DS2
D919 8-719-210-33 DIODE EC10DS2
D920 8-719-210-33 DIODE EC10DS2
D921 8-719-977-81 DIODE DTZ33B
D922 8-719-069-60 DIODE UDZSTE-179.1B
D923 8-719-210-39 DIODE EC10QS-04
< TERMINAL >
EB901 1-537-738-21 TERMINAL, EARTH
< IC >
IC901 8-759-604-86 IC M5F7807L
IC902 8-759-604-90 IC M5F7907L
IC903 8-759-231-53 IC TA7805S
IC904 8-759-445-59 IC BA033T
IC905 8-759-394-35 IC BA12T
IC906 8-759-450-47 IC BA05T
< NOISE FILTER/IC LINK >
L904 1-424-122-11 FILTER, NOISE
L905 1-424-122-11 FILTER, NOISE
L906 1-537-738-21 LINK, IC
L907 1-537-738-21 LINK, IC
L908 1-424-122-11 FILTER, NOISE
< TRANSISTOR >
Q921 8-729-041-38 TRANSISTOR 2SB1241TV2Q
< RESISTOR/FERRITE >
R921 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R922 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R923 1-216-174-00 RES-CHIP 100 5% 1/8W
R924 1-216-174-00 RES-CHIP 100 5% 1/8W
R925 1-216-840-11 METAL CHIP 39K 5% 1/16W
R926 1-216-851-11 METAL CHIP 330K 5% 1/16W
R927 1-414-234-22 FERRITE 0uH
0 R954 1-212-869-00 FUSIBLE 33 5% 1/4W F
R956 1-216-196-00 RES-CHIP 820 5% 1/8W
R957 1-216-803-11 METAL CHIP 33 5% 1/16W
**************************************************************
A-4725-600-A RF BOARD, COMPLETE
*******************
< CAPACITOR >
C001 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C002 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C004 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C006 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C007 1-117-370-11 CERAMIC CHIP 10uF 10V
C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C009 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C010 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C011 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C012 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C013 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C015 1-117-370-11 CERAMIC CHIP 10uF 10V
C016 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C017 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C018 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C020 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C021 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C022 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C024 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C025 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C027 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C028 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C029 1-117-370-11 CERAMIC CHIP 10uF 10V
C030 1-128-993-21 ELECT CHIP 22uF 20% 10V
C031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C037 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C038 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C039 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C040 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C041 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C042 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C043 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C044 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C045 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C046 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C048 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C050 1-128-993-21 ELECT CHIP 22uF 20% 10V
C051 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C052 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C055 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C060 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C064 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C090 1-115-156-11 CERAMIC CHIP 1uF 10V
C094 1-128-993-21 ELECT CHIP 22uF 20% 10V
C095 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN002 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
CN003 1-794-707-11 CONNECTOR, FFC/FPC 25P
CN005 1-815-346-11 CONNECTOR, FFC/FPC 30P
< DIODE >
D001 8-719-016-74 DIODE 1SS352
D002 8-719-016-74 DIODE 1SS352
< IC >
IC001 8-752-403-50 IC CXD1881R
IC004 8-759-058-45 IC NJM3403AV
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER RF
To Next Page
