SDM-S71 (E) 1-3
8 Two screws
(+PWH 3x6)
4 CN5
7 CN2
9 Inverter mount
6 CN3
2 Inverter shield
1 Two screws
(+P 3x4)
5 CN4
3 CN1
1-3. INVERTER MOUNT REMOVAL
