– 2 –
SAFETY CHECK-OUT
1. Check the area of your repair for unsoldered or poorly-sol-
dered connections. Check the entire board surface for solder
splashes and bridges.
2. Check the interboard wiring to ensure that no wires are
“pinched” or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transis-
tors, that were installed during a previous repair. Point them
out to the customer and recommend their replacement.
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
4. Look for parts which, though functioning, show obvious signs
of deterioration. Point them out to the customer and recom-
mend their replacement.
5. Check the B+ voltage to see it is at the values specified.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED
LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
LINE 1 OUT
VIDEO OUT, phono jack (1)
Output signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
AUDIO OUT (MONO), phono jack (1)
(EXCEPT GF85/SP100)
AUDIO OUT, phono jack (2)
(GF85/SP100)
Standard output: 327 mVrms
Load impedance: 47 kilohms
Output impedance: less than 10 kilohms
General
Power requirements
110 – 240 V AC, 50/60 Hz
(EXCEPT CA30/GA35TW/GF85TW/SA33)
110 V AC, 60 Hz
(CA30/GA35TW/GF85TW/SA33)
Power consumption
10 W (CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
12 W
(EXCEPT CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
Operating temperature
5 °C to 40 °C
Storage temperature
–20 °C to 60 °C
Dimensions
Approx. 355 × 96 × 293 mm (w/h/d)
Including projecting parts and controls
Mass
Approx. 3.8 kg
Supplied accessories
Remote commander (1)
R6 (Size AA) batteries (2)
Aerial cable (1)
(EXCEPT CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
Audio /video cable (3-phono to 3- phono) (1)
(GF85/SP100)
75-ohm coaxial cable with F type connectors (1)
(CA30/GA35: PL, TW/GA55PL/GF85: PL,TW/
SA33)
Design and specifications are subject to change
without notice.
• Feature Difference
SLV- CA30TW GA35ME GA35PL GA55ME GA55PL GF85PL GF85PS GF85TW SP100R
GA35TW GA35PS GA55PS GF85TH
SA33TW GA35SG GA55SG
GA35TH GA55TH
SP70R
Feature
HEAD/CH 2/2 2/2 2/2 4/4 4/4 6/6 6/6 6/6 4/4
NTSC (3.58) (REC/PB) ×/a ×/××/aa/aa/aa/aa/aa/aa/a
(4.43) (REC/PB) ×/××/a ×/× a/a ×/××/× a/a ×/× a/a
MESECAM (REC/PB) ×/a ×/a ×/aa/aa/a ×/× a/a ×/× a/a
REC (NTSC) (SP/EP) ×/××/××/× a/aa/aa/aa/× a/aa/×
(PAL) (SP/LP) ×/××/××/× a/aa/a ×/× a/××/× a/×
PLAY (NTSC) (SP/EP) a/aa/aa/aa/aa/aa/aa/× a/aa/×
(PAL) (SP/LP) a/aa/aa/aa/aa/a ×/× a/××/× a/×
RCA LINE IN/OUT ×/a (2P) ×/a (2P) ×/a (2P) a (2P)/ a (2P)/ a (3P)/ a (3P)/ a (3P)/ a (3P)/
a (2P) a (2P) a (3P) a (3P) a (3P) a (3P)
MODULATOR
SYSTEM
13ch G/K 3/4ch G/K 3/4ch 3/4ch G/K 13ch G/K
REMOTE
COMMANDER
RMT-V286C RMT-V286A RMT-V286A RMT-V286 RMT-V286 RMT-V286 RMT-V286 RMT-V286B RMT-V286
