7-7
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
7-2. ELECTRICAL PARTS LIST
The components identified by
mark 0 or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FR-167 MA-366
* A-6794-720-A FR-167 BOARD, COMPLETE (GF85PL)
* A-6794-721-A FR-167 BOARD, COMPLETE
(GA55: ME, PS, SG, TH/SP70)
* A-6794-722-A FR-167 BOARD, COMPLETE
(GA35: ME, PS, SG, TH)
* A-6794-723-A FR-167 BOARD, COMPLETE
(GF85: PS, TH/SP100)
* A-6794-727-A FR-167 BOARD, COMPLETE (GA55PL)
* A-6794-728-A FR-167 BOARD, COMPLETE (GA65)
* A-6794-729-A FR-167 BOARD, COMPLETE (GA35PL)
* A-6794-731-A FR-167 BOARD, COMPLETE
(CA30/GA35TW/SA33)
* A-6794-732-A FR-167 BOARD, COMPLETE (GF85TW)
**********************
(Ref. No. 1,000 Series)
< CAPACITOR >
C501 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN501 1-784-449-11 CONNECTOR, FFC/FPC 7P
< DIODE >
D501 8-719-051-17 DIODE SLR-342DC3F
(RESOLUTION CONTROL II)
< IC >
IC501 8-749-011-05 IC GP1U28X
< RESISTOR >
R501 1-216-206-00 RES, CHIP 2.2K 5% 1/8W
R502 1-249-424-11 CARBON 3.9K 5% 1/4W
R503 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R504 1-216-075-00 METAL CHIP 12K 5% 1/10W
R506 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R507 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R508 1-249-424-11 CARBON 3.9K 5% 1/4W
R509 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R510 1-216-295-00 METAL CHIP 0 5% 1/10W
(GA35: ME, PS, SG, TH)
R511 1-249-424-11 CARBON 3.9K 5% 1/4W
R512 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R513 1-216-075-00 METAL CHIP 12K 5% 1/10W
(GF85: PS, TH/SP100)
R514 1-216-295-00 METAL CHIP 0 5% 1/10W
(EXCEPT CA30/GA35/GA55PL/
GF85: PL, TW/SA33)
R521 1-216-178-00 RES, CHIP 150 5% 1/8W
< SWITCH >
S501 1-762-196-21 SWITCH, TACT (RESOLUTION CONTROL II)
S502 1-762-196-21 SWITCH, TACT (RESOLUTION CONTROL II)
S503 1-762-196-21 SWITCH, TACT (RESOLUTION CONTROL II)
S504 1-762-196-21 SWITCH, TACT (RESOLUTION CONTROL II)
S505 1-762-196-21 SWITCH, TACT (A EJECT)
S506 1-762-196-21 SWITCH, TACT (STD PICT)
S511 1-572-908-11 SWITCH, SLIDE (NTSC PB)
(GA35: ME, PS, SG, TH)
S511 1-572-907-11 SWITCH, SLIDE (NTSC PB)
(EXCEPT CA30/GA35/GA55PL/
GF85: PL, TW/SA33)
S512 1-572-907-11 SWITCH, SLIDE (COLOR SYSTEM)
(EXCEPT CA30/GA35: PL, TW/
GF85: PL, TW/SA33)
S513 1-572-908-11 SWITCH, SLIDE (TAPE SPEED)
(GA55/GA65/GF85: PL, TW/SP70)
* A-6713-545-A MA-366 BOARD, COMPLETE (GF85PL)
* A-6713-546-A MA-366 BOARD, COMPLETE
(GA55: ME, PS, SG, TH/SP70)
* A-6713-547-A MA-366 BOARD, COMPLETE
(GA35: ME, PS, SG, TH)
* A-6713-548-A MA-366 BOARD, COMPLETE
(GF85: PS, TH/SP100)
* A-6713-551-A MA-366 BOARD, COMPLETE (GA55PL)
* A-6713-552-A MA-366 BOARD, COMPLETE (GA65)
* A-6713-553-A MA-366 BOARD, COMPLETE (GA35PL)
* A-6713-554-A MA-366 BOARD, COMPLETE
(CA30/GA35TW/SA33)
* A-6713-555-A MA-366 BOARD, COMPLETE (GA85TW)
***********************
(Ref. No. 1,000 Series)
1-960-158-11 HARNESS (AU-059) (GF85/SP100)
* 3-960-273-01 SPACER, TOP END
* 3-960-274-01 SPACER, LED
3-970-608-21 SUMITITE (B3), +BV
To Next Page
