7-14
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-366
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number speci-
fied.
R409 1-216-035-00 METAL CHIP 270 5% 1/10W
R410 1-216-184-00 RES, CHIP 270 5% 1/8W
(EXCEPT CA30/GA35/SA33)
R411 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R412 1-216-075-00 METAL CHIP 12K 5% 1/10W
R413 1-249-410-11 CARBON 270 5% 1/4W
(GF85/SP100)
R414 1-216-085-00 METAL CHIP 33K 5% 1/10W
(GF85/SP100)
R415 1-216-035-00 METAL CHIP 270 5% 1/10W
(GF85/SP100)
R416 1-247-837-91 CARBON 1.8K 5% 1/4W
(EXCEPT GA65)
R416 1-249-420-11 CARBON 1.8K 5% 1/4W
(GA65)
R417 1-216-184-00 RES, CHIP 270 5% 1/8W
(GF85/SP100)
R418 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R419 1-216-184-00 RES, CHIP 270 5% 1/8W
(CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
R420 1-249-421-11 CARBON 2.2K 5% 1/4W
R421 1-216-184-00 RES, CHIP 270 5% 1/8W
(EXCEPT CA30/GA35/SA33)
R422 1-216-073-00 METAL CHIP 10K 5% 1/10W
R423 1-216-073-00 METAL CHIP 10K 5% 1/10W
R424 1-216-222-00 RES, CHIP 10K 5% 1/8W
0 R601 1-260-364-11 CARBON 1M 5% 1/2W
R602 1-249-441-11 CARBON 100K 5% 1/4W
R603 1-249-441-11 CARBON 100K 5% 1/4W
R604 1-247-883-00 CARBON 150K 5% 1/4W
R605 1-249-439-11 CARBON 68K 5% 1/4W
R606 1-216-017-91 RES, CHIP 47 5% 1/10W
R607 1-216-093-91 RES, CHIP 68K 5% 1/10W
R608 1-249-411-11 CARBON 330 5% 1/4W
R609 1-215-927-41 METAL OXIDE 47K 5% 3W
R610 1-215-889-00 METAL OXIDE 330 5% 2W F
R611 1-216-047-91 RES, CHIP 820 5% 1/10W
R612 1-216-341-11 METAL OXIDE 0.22 5% 1W F
R613 1-216-073-00 METAL CHIP 10K 5% 1/10W
R614 1-249-415-11 CARBON 680 5% 1/4W
R615 1-216-047-91 RES, CHIP 820 5% 1/10W
R616 1-216-049-00 METAL CHIP 1K 5% 1/10W
R617 1-216-166-00 RES, CHIP 47 5% 1/8W
R618 1-249-408-11 CARBON 180 5% 1/4W
R619 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R620 1-260-091-11 CARBON 220 5% 1/2W
R621 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R622 1-247-807-31 CARBON 100 5% 1/4W
R901 1-249-412-11 CARBON 390 5% 1/4W
R902 1-216-023-00 METAL CHIP 82 5% 1/10W
(EXCEPT CA30/GA35/SA33)
R903 1-247-804-11 CARBON 75 5% 1/4W
R904 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(EXCEPT CA30/GA35: PL, TW/
GA55PL/GF85: PL, TW/SA33)
R904 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(CA30/GA35: PL, TW/
GA55PL/GF85: PL, TW/SA33)
R905 1-216-049-00 METAL CHIP 1K 5% 1/10W
R906 1-216-089-00 METAL CHIP 47K 5% 1/10W
R907 1-216-089-00 METAL CHIP 47K 5% 1/10W
R908 1-216-041-00 METAL CHIP 470 5% 1/10W
(GF85/SP100)
R908 1-216-295-00 METAL CHIP 0 5% 1/10W
(EXCEPT GF85/SP100)
R909 1-216-041-00 METAL CHIP 470 5% 1/10W
(GF85/SP100)
< MODULATOR >
0 RFU901 1-473-226-13 MODULATOR, RF (RFU-2043)
(EXCEPT CA30/GA35: PL, TW/
GA55PL/GA65/GF85: PL, TW/SA33)
0 RFU901 1-473-240-11 MODULATOR, RF (RFU-1048)
(CA30/GA35: PL, TW/GA55PL/
GF85: PL, TW/SA33)
0 RFU901 1-473-637-31 MODULATOR, RF (RFU-2025) (GA65)
< VARIABLE RESISTOR >
RV101 1-223-239-11 RES, ADJ, CARBON 10K
RV102 1-223-239-11 RES, ADJ, CARBON 10K (GF85/SP100)
< SWITCH >
S101 1-571-958-11 SWITCH, PUSH (1 KEY) (REC PROOF)
(EXCEPT GA65)
S101 1-762-108-11 SWITCH, PUSH (1 KEY) (REC PROOF) (GA65)
S102 1-771-155-11 SWITCH, ROTARY (CAM ENCODER)
S401 1-762-196-21 SWITCH, TACT (? /1)
S402 1-762-196-21 SWITCH, TACT (x STOP)
S403 1-762-196-21 SWITCH, TACT (G PLAY)
S404 1-762-196-21 SWITCH, TACT (M FF)
S405 1-762-196-21 SWITCH, TACT (X PAUSE)
S406 1-762-196-21 SWITCH, TACT (z REC)
(EXCEPT CA30/GA35/SA33)
S407 1-762-196-21 SWITCH, TACT (m REW)
S408 1-762-196-21 SWITCH, TACT (SYNCHRO REC)
(EXCEPT CA30/GA35/SA33)
S410 1-571-588-21 SWITCH, SLIDE (CONNECT LINE-1)
(EXCEPT CA30/GA35/SA33)
< TRANSFORMER >
T371 1-433-494-11 BIAS OSCILLATION TRANSFORMER
(EXCEPT CA30/GA35/SA33)
0 T601 1-435-137-11 TRANSFORMER (RCC), CONVETER
< VARISTOR >
0 VDR601 1-801-267-31 VARISTOR TNR10V431K660
< VIBRATOR >
X101 1-767-855-11 VIBRATOR, CRYSTAL (10MHz)
X201 1-760-708-11 VIBRATOR, CRYSSTAL (4. 433619MHz)
(EXCEPT CA30/GA35: PL, TW/
GA55PL/GF85: PL, TW/SA33)
* X202 1-760-709-11 VIBRATOR, CRYSTAL (3. 579545MHz)
(EXCEPT GA35: ME, PS, SG, TH)
