Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
8-2. ELECTRICAL PARTS LIST
DS-78 ETXNY 165E1D FI-14
* A-6794-518-A DS-78 BOARD, COMPLETE (E380)
* A-6794-517-A DS-78 BOARD, COMPLETE (E530)
* A-6794-505-A DS-78 BOARD, COMPLETE
(EXCEPT E380/E530)
**********************
(Ref.No. 1,000 Series)
< CONNECTOR >
CN450 1-784-484-11 CONNECTOR, FFC/FPC 5P (E380/E530)
< DIODE >
D450 8-719-946-30 LED SLR34DC3 (JOG) (E530)
< JUMPER RESISTOR >
JR702 1-216-296-91 SHORT 0
JR704 1-216-296-91 SHORT 0 (E530)
JR706 1-216-296-91 SHORT 0 (E380/E530)
JR707 1-216-295-91 SHORT 0
JR708 1-216-296-91 SHORT 0 (E380/E530)
JR709 1-216-296-91 SHORT 0 (E380/E530)
< RESISTOR >
R450 1-216-041-00 METAL CHIP 470 5% 1/10W
(E530)
R451 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R452 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S450 1-571-977-11 SWITCH, TACTIL (FF) (E380/E530)
S451 1-571-977-11 SWITCH, TACTIL (FF) (EXCEPT E380/E530)
S452 1-571-977-11 SWITCH, TACTIL (PLAY) (EXCEPT E380/E530)
S453 1-571-977-11 SWITCH, TACTIL (STOP) (EXCEPT E380/E530)
S454 1-571-977-11 SWITCH, TACTIL (REW) (EXCEPT E380/E530)
S455 1-571-977-11 SWITCH, TACTIL (REW) (E380/E530)
S456 1-571-977-11 SWITCH, TACTIL (JOG) (E530)
1-468-271-11 ETXNY 165E1D BLOCK (Ref.No. 2,000 Series)
*******************
< CAPACITOR >
C003 9-980-236-01 ELECT 47uF 400V
C102 1-126-964-11 ELECT 10uF 50V
C107 1-126-965-11 ELECT 22uF 50V
C201 1-126-968-11 ELECT 100uF 50V
C302 1-126-968-11 ELECT 100uF 50V
C402 1-126-925-11 ELECT 470uF 10V
C501 1-126-960-11 ELECT 1uF 50V
< DIODE >
D001 8-719-066-97 DIODE 1N4007
D002 8-719-066-97 DIODE 1N4007
D003 8-719-066-97 DIODE 1N4007
D004 8-719-066-97 DIODE 1N4007
< TRANSISTOR >
Q102 8-729-423-29 TRANSISTOR 2SC3311A-QTA
* A-6794-507-A FI-14 BOARD, COMPLETE (E295/E380EE/E530)
*********************
(Ref.No. 1,000 Series)
< CAPACITOR >
C481 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C493 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN480 1-568-942-11 PIN, CONNECTOR 4P
< DIODE >
D480 8-719-109-97 DIODE RD6.8ES-B2
D481 8-719-108-12 DIODE RD9.1E-W
D491 8-719-108-12 DIODE RD9.1E-W
< JACK >
J481 1-774-510-11 JACK, PIN 2P (LINE 2 IN)
< RESISTOR >
R480 1-216-022-00 METAL CHIP 75 5% 1/10W
R491 1-216-041-00 METAL CHIP 470 5% 1/10W
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
