Sony SLV-E177EG - Page 68

8-13
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-314
L262 1-414-940-21 INDUCTOR 100uH
L263 1-414-940-21 INDUCTOR 100uH
L301 1-414-940-21 INDUCTOR 100uH
L321 1-414-940-21 INDUCTOR 100uH
L510 1-414-940-21 INDUCTOR 100uH
L530 1-414-940-21 INDUCTOR 100uH
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CP, VC)
L540 1-414-934-21 INDUCTOR 10uH
(E230CP/E285/E295/E430: B, CP, VC/E530)
L580 1-414-940-21 INDUCTOR 100uH
(E230CP/E285/E295/E430: B, CP, VC/E530)
L600 1-414-939-21 INDUCTOR 68uH
L601 1-414-934-21 INDUCTOR 10uH
L661 1-414-940-21 INDUCTOR 100uH
L662 1-414-936-21 INDUCTOR 22uH
(E177/E180/E285B/E380/E430B/E477/E480/E530B)
L663 1-414-940-21 INDUCTOR 100uH
L701 1-414-930-21 INDUCTOR 2.2uH
L750 1-414-930-21 INDUCTOR 2.2uH
L751 1-414-930-21 INDUCTOR 2.2uH
(EXCEPT E180EE/E380EE/E480EE)
L970 1-414-933-11 INDUCTOR 6.8uH(E285B/E430B/E530B)
L971 1-414-945-11 INDUCTOR 27uH (E285B/E430B/E530B)
L972 1-414-938-21 INDUCTOR 47uH (E285B/E430B/E530B)
L973 1-414-938-21 INDUCTOR 47uH (E285B/E430B/E530B)
L975 1-414-934-21 INDUCTOR 10uH (E285B/E430B/E530B)
< FLUORECENT INDICATOR >
ND420 1-517-724-11 TUBE, FLUORESCENT INDICATOR
< PHOTO INTERRUPTER >
PH100 8-749-013-23 PHOTO INTERRUPTER GP3S120
PH101 8-749-013-23 PHOTO INTERRUPTER GP3S120
< IC LINK >
! PS100 1-533-586-31 LINK, IC 491.315 (315mA)
! PS131 1-533-586-31 LINK, IC 491.315 (315mA)
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CO, VC)
! PS600 1-533-593-11 LINK, IC 491002 (2A)
! PS601 1-533-589-21 LINK, IC 491.750 (750mA)
< TRANSISTOR >
Q100 8-729-043-84 TRANSISTOR PT380F3
Q101 8-729-043-84 TRANSISTOR PT380F3
Q102 8-729-281-53 TRANSISTOR 2SC1815-GR
Q161 8-729-804-41 TRANSISTOR 2SB1122-S
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CP, VC)
Q162 8-729-421-19 TRANSISTOR UN2213
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CP, VC)
Q163 8-729-421-19 TRANSISTOR UN2213
Q201 8-729-422-27 TRANSISTOR 2SD601A-Q
Q202 8-729-422-27 TRANSISTOR 2SD601A-Q
Q208 8-729-422-27 TRANSISTOR 2SD601A-Q
Q209 8-729-216-22 TRANSISTOR 2SA1162
Q210 8-729-422-27 TRANSISTOR 2SD601A-Q
Q211 8-729-422-27 TRANSISTOR 2SD601A-Q
Q260 8-729-422-27 TRANSISTOR 2SD601A-Q
Q301 8-729-281-53 TRANSISTOR 2SC1815-GR
Q321 8-729-802-91 TRANSISTOR 2SD879
Q501 8-729-424-08 TRANSISTOR UN2111
(EXCEPT E180EE/E380EE/E480EE)
Q502 8-729-421-19 TRANSISTOR UN2213
(EXCEPT E180EE/E380EE/E480EE)
Q503 8-729-422-27 TRANSISTOR 2SD601A-Q
Q510 8-729-216-22 TRANSISTOR 2SA1162
Q540 8-729-216-22 TRANSISTOR 2SA1162
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CP, VC)
Q580 8-729-422-27 TRANSISTOR 2SD601A-Q
(E230CP/E285/E295/E430: B, CP, VC/E530)
Q581 8-729-421-19 TRANSISTOR UN2213
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CP, VC)
Q582 8-729-421-19 TRANSISTOR UN2213
(E230CP/E285/E295/E430: B, CP, VC/E530)
Q583 8-729-421-19 TRANSISTOR UN2213
(E230CP/E285/E295: CP, VC1, VC2/
E430: B, CP, VC/E530B, CP, VC)
! Q600 8-729-140-93 TRANSISTOR 2SB733-34
Q601 8-729-422-27 TRANSISTOR 2SD601A-Q
Q602 8-729-018-99 TRANSISTOR 2SD2394-F
Q603 8-729-140-96 TRANSISTOR KSC1008
(EXCEPT E180EE/E380EE/E480EE)
Q604 8-729-424-08 TRANSISTOR UN2111
(EXCEPT E180EE/E380EE/E480EE)
Q605 8-729-421-19 TRANSISTOR UN2213
(EXCEPT E180EE/E380EE/E480EE)
Q606 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q660 8-729-216-22 TRANSISTOR 2SA1162
Q661 8-729-216-22 TRANSISTOR 2SA1162
Q662 8-729-216-22 TRANSISTOR 2SA1162
Q750 8-729-012-31 TRANSISTOR 2SC4040-TL2-Q
Q751 8-729-421-19 TRANSISTOR UN2213
(EXCEPT E180EE/E380EE/E480EE)
Q752 8-729-216-22 TRANSISTOR 2SA1162
(EXCEPT E180EE/E380EE/E480EE)
Q850 8-729-216-22 TRANSISTOR 2SA1162
(E230: VP1, VP2/E285/E295: UX, VC1, VC2/
E430: B, VC, VP/E530: B, UX, VC)
Q970 8-729-216-22 TRANSISTOR 2SA1162
(E285B/E430B/E530B)
Q972 8-729-424-08 TRANSISTOR UN2111
(E285B/E430B/E530B)
Q973 8-729-422-27 TRANSISTOR 2SD601A-Q
(E285B/E430B/E530B)
Q974 8-729-422-27 TRANSISTOR 2SD601A-Q
(E285B/E430B/E530B)
Q975 8-729-424-08 TRANSISTOR UN2111
(E285B/E430B/E530B)
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
