8-17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MA-314
R859 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(E230: VP1, VP2/E285/E295: UX, VC1, VC2/
E430: B, VC, VP/E530: B, UX, VC)
R860 1-216-123-11 METAL CHIP 1.2M 5% 1/10W
(E230: VP1, VP2/E285/E295: UX, VC1, VC2/
E430: B, VC, VP/E530: B, UX, VC)
R861 1-216-117-00 METAL CHIP 680K 5% 1/10W
(E230: VP1, VP2/E285/E295: UX, VC1, VC2/
E430: B, VC, VP/E530: B, UX, VC)
R862 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(E230: VP1, VP2/E285/E295: UX, VC1, VC2/
E430: B, VC, VP/E530: B, UX, VC)
R968 1-247-883-91 METAL CHIP 150K 5% 1/10W
(E285B/E430B/E530B)
R969 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(E285B/E430B/E530B)
R970 1-216-085-00 METAL CHIP 33K 5% 1/10W
(E285B/E430B/E530B)
R971 1-216-085-00 METAL CHIP 33K 5% 1/10W
(E285B/E430B/E530B)
R973 1-216-081-00 METAL CHIP 22K 5% 1/10W
(E285B/E430B/E530B)
R974 1-216-081-00 METAL CHIP 22K 5% 1/10W
(E285B/E430B/E530B)
R975 1-216-295-91 SHORT 0 (E285B/E430B/E530B)
R976 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
(E285B/E430B/E530B)
R977 1-216-089-91 RES, CHIP 47K 5% 1/10W
(E285B/E430B/E530B)
R978 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(E285B/E430B/E530B)
R979 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E285B/E430B/E530B)
R980 1-216-097-91 RES, CHIP 100K 5% 1/10W
(E285B/E430B/E530B)
R981 1-216-083-00 METAL CHIP 27K 5% 1/10W
(E285B/E430B/E530B)
R982 1-216-089-91 RES, CHIP 47K 5% 1/10W
(E285B/E430B/E530B)
R983 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
(E285B/E430B/E530B)
R985 1-216-041-00 METAL CHIP 470 5% 1/10W
(E285B/E430B/E530B)
R986 1-216-089-91 RES, CHIP 47K 5% 1/10W
(E285B/E430B/E530B)
R988 1-216-083-00 METAL CHIP 27K 5% 1/10W
(E285B/E430B/E530B)
R989 1-216-049-91 RES, CHIP 1K 5% 1/10W
(E285B/E430B/E530B)
R990 1-216-295-91 SHORT 0 (E285B/E430B/E530B)
R993 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(E285B/E430B/E530B)
R994 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
(E285B/E430B/E530B)
R995 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E285B/E430B/E530B)
R996 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
(E285B/E430B/E530B)
R997 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E285B/E430B/E530B)
R998 1-216-073-00 METAL CHIP 10K 5% 1/10W
(E285B/E430B/E530B)
R999 1-216-295-91 SHORT 0 (E285B/E430B/E530B)
< SWITCH >
S100 1-771-155-11 SWITCH, ROTARY (CAM ENCODER)
S101 1-762-108-11 SWITCH, PUSH (1 KEY) (REC PRF)
S160 1-571-588-31 SWITCH, SLIDE (NTSC PB)
(EXCEPT E130/E230)
S401 1-571-532-32 SWITCH, TACTIL (ON/STANDBY)
S402 1-571-532-32 SWITCH, TACTIL (EJECT)
S403 1-571-532-32 SWITCH, TACTIL (REC)
S404 1-571-532-32 SWITCH, TACTIL (PAUSE)
S405 1-571-532-32 SWITCH, TACTIL (PROGRAM+)
S406 1-571-532-32 SWITCH, TACTIL (PROGRAM–)
S407 1-571-532-32 SWITCH, TACTIL (RF CHANNEL)
< TRANSFORMER >
T321 1-431-097-11 TRANSFORMER, BIAS OSCILLATION
< TUNER >
TU700 1-693-404-11 TUNER, MOD/IF (BTF-3MC403)
(E130/E230: AE, CP, VP1, VP2/
E285VC/E295: CP, VC1, VC2/
E430: AE, CP, VC, VP/E530: CP, VC)
TU700 1-693-403-11 TUNER, MOD/IF (BTF-3MC444)
(E285B/E430B/E530B)
TU700 1-693-360-12 TUNER, MOD/IF SOLID TYPE
(E177/E180EG/E380EG/E477/E480EG)
TU700 1-693-359-12 TUNER, MOD/IF SOLID TYPE
(E180EE/E380EE/E480EE)
TU700 1-693-402-11 TUNER, MOD/IF (BTF-3MU603)
(E230UY/E295UX/E530UX)
TU700 1-693-401-11 TUNER, MOD/IF (BTF-3MC433) (230EY)
< VIBRATOR >
X161 1-760-494-11 VIBRATOR, CRYSTAL (16MHz)
X162 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X201 1-579-608-11 VIBRATOR, CRYSTAL (4.43MHz)
X660 1-577-289-11 VIBRATOR, CRYSTAL (17.734475MHz)
MISCELLANEOUS
***************
6 1-762-844-21 SWITCH, ROTARY (E380/E530)
! 55 1-777-854-21 CORD, POWER
704 1-500-144-11 HEAD, FE
769 1-759-183-11 DRUM ASSY, DZH-78A-R
(E130/E177/E180/E230: AE, CP, VP2/
E285: B/E380)
769 1-759-522-11 DRUM ASSY, DZH-93A-R
(E430/E477/E480/E530)
769 1-759-523-11 DRUM ASSY, DZH-92A-R
(E230: EY, UY, VP1/E285: VC/E295)
M902 1-698-971-11 MOTOR, DC (CAPSTAN)
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
To Next Page
