SLV-LX80S
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-6
8-2. ELECTRICAL PARTS LIST
A-6713-988-A DM-098 BOARD COMPLETE
**********************
<CONNECTOR>
CN471 1-770-514-31 CONNECTOR, FFC/FPC 5P
<CHIP CONDUCTOR>
JR461 1-216-295-00 SHORT 0
<RESISTOR>
R465 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R467 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R468 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R474 1-216-295-00 SHORT 0
R475 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
<SWITCH>
S481 1-762-196-21 SWITCH, TACT zREC
S482 1-762-196-21 SWITCH, TACT mREW
S483 1-762-196-21 SWITCH, TACT xSTOP
S484 1-762-196-21 SWITCH, TACT HPLAY
S485 1-762-196-21 SWITCH, TACT AEJECT
A-6713-935-A FJ-033 BOARD COMPLETE
*********************
<CONNECTOR>
CN501 1-691-064-31 HOUSING, CONNECTOR 5P
S501 1-762-196-21 SWITCH, TACT CHANNEL/TRACKING +
S502 1-762-196-21 SWITCH, TACT CHANNEL/TRACKING -
S503 1-762-196-21 SWITCH, TACT RF CHANNEL
S504 1-762-196-21 SWITCH, TACT (?/1) POWER
A-6713-872-A GK-12 BOARD COMPLETE (SLV-LF1AS)
********************
<CAPACITOR>
C003 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C006 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C007 1-164-699-11 CERAMIC CHIP 0.0033uF 5% 50V
C008 1-164-699-11 CERAMIC CHIP 0.0033uF 5% 50V
C009 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C010 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C011 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C012 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C013 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C014 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C015 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C016 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C017 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C018 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C022 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C023 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CN001 1-691-183-11 CONNECTOR (BOARD TO BOARD) 13P
< IC >
IC001 8-759-579-30 IC TDA9873H/V1, 518
< JUMPER RESISTOR >
JS002 1-216-295-00 METAL CHIP 0 5% 1/10W
JS003 1-216-295-00 METAL CHIP 0 5% 1/10W
< RESISTOR >
R001 1-216-295-00 METAL CHIP 0 5% 1/10W
R002 1-216-295-00 METAL CHIP 0 5% 1/10W
R004 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R005 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R006 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R007 1-216-045-00 METAL CHIP 680 5% 1/10W
R008 1-216-041-00 METAL CHIP 470 5% 1/10W
R009 1-216-041-00 METAL CHIP 470 5% 1/10W
R010 1-208-803-11 METAL CHIP 7.5K 0.5% 1/10W
R011 1-216-295-00 METAL CHIP 0 5% 1/10W
R012 1-216-298-00 METAL CHIP 2.2 5% 1/10W
< VARIABLE RESISTOR >
RV001 1-241-783-11 RES, ADJ, CARBON 2.2K
DM-98 FJ-33
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark or
dotted line with mark
are critical for safety.
Replace only with part number specified.
GK-12
