Insert In/out
Scribble Editable via keyboard
Faders and Pan • Modes:
Program Stereo pan and gain
Program Surround pan and gain
Short channels [9-16] Stereo pan and gain
Short channels [9-16] Surround pan and gain
AUX Send Trim
• Stereo and Surround, Program and short channel modes:
Channel-to-bus enable buttons
Solo and Cut buttons
Fader gain: [-1024 dB → +10 dB], Normalized 0 dB
Stereo Pan: [100% Left → 100% Right], Normalized to Centre
Surround Pan:
ITU-R BS.775-1 [L, C, R & LS, RS] speaker configuration
[100% Left → 100% Right], Normalized to Centre
[100% Front → 100% Back], Normalized to Front
[0% → 100%] Divergence, Normalized 100%
[0% → 200%] LFE bus send, Normalized 100%
• AUX send mode:
4 sets of controls, 1 for each of AUX send 1+2, 3+4, 5+6 and 7+8. Each control
comprising:
Pre/Post Stereo gain/Post Surround gain switch
Cut button
L/R pan: Left pans to [1, 3, 5 or 7] Right to [2, 4, 6 or 8]
Gain control [-1024 dB → +10 dB]
Table 3-3 Equalization
EQ Type Specifications
HF
parametric
Gain: [–20 dB → +20 dB], Normalized 0 dB
Frequency: [2 kHz → 40 kHz], Normalized 2 kHz
Q: [0.5 → 16.0], Normalized 0.5
HMF
parametric
Gain: [–20 dB → +20 dB], Normalized 0 dB
Frequency: [900 Hz → 18 kHz], Normalized 900 Hz
Q: [0.5 → 16.0], Normalized 0.5
MF
parametric
Gain: [–20 dB → +20 dB], Normalized 0 dB
Frequency: [100 Hz → 6 kHz], Normalized 100 Hz
Q: [0.5 → 16.0], Normalized 0.5
Table 3-2 Channel Strip Controls
Item Specifications
