Sony SRF-18 - Page 15

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SRF-18
1515
< JUMPER RESISTOR >
JC101 1-216-864-11 SHORT CHIP 0
JC102 1-216-864-11 SHORT CHIP 0
JC501 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-428-309-11 COIL, AIR-CORE
L102 1-409-991-11 COIL, AIR-CORE
L103 1-460-527-11 COIL, OSCILLATION (AM)
L104 1-460-526-11 COIL, OSCILLATION (VCO)
L105 1-460-469-11 BAR ANTENNA COIL (AM)
L106 1-460-515-11 COIL, AIR-CORE
L201 1-410-294-41 INDUCTOR 38uH
< TRANSISTOR >
Q231 6-552-408-01 TRANSISTOR DSC500100L
Q251 6-552-408-01 TRANSISTOR DSC500100L
Q331 6-552-408-01 TRANSISTOR DSC500100L
Q351 6-552-408-01 TRANSISTOR DSC500100L
Q431 6-552-408-01 TRANSISTOR DSC500100L
Q451 6-552-408-01 TRANSISTOR DSC500100L
< RESISTOR >
R101 1-216-813-11 METAL CHIP 220 5% 1/10W
R102 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R103 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R104 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R105 1-216-797-11 METAL CHIP 10 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R108 1-216-815-11 METAL CHIP 330 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R131 1-216-839-11 METAL CHIP 33K 5% 1/10W
R151 1-216-839-11 METAL CHIP 33K 5% 1/10W
R201 1-216-809-11 METAL CHIP 100 5% 1/10W
R202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-864-11 SHORT CHIP 0
R231 1-216-805-11 METAL CHIP 47 5% 1/10W
R232 1-216-841-11 METAL CHIP 47K 5% 1/10W
R233 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R234 1-216-811-11 METAL CHIP 150 5% 1/10W
R235 1-216-864-11 SHORT CHIP 0
R251 1-216-805-11 METAL CHIP 47 5% 1/10W
R252 1-216-841-11 METAL CHIP 47K 5% 1/10W
R253 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R254 1-216-811-11 METAL CHIP 150 5% 1/10W
R255 1-216-864-11 SHORT CHIP 0
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R331 1-216-835-11 METAL CHIP 15K 5% 1/10W
R332 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R333 1-216-843-11 METAL CHIP 68K 5% 1/10W
R334 1-216-801-11 METAL CHIP 22 5% 1/10W
R335 1-216-864-11 SHORT CHIP 0
R351 1-216-835-11 METAL CHIP 15K 5% 1/10W
R352 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R353 1-216-843-11 METAL CHIP 68K 5% 1/10W
R354 1-216-801-11 METAL CHIP 22 5% 1/10W
R355 1-216-864-11 SHORT CHIP 0
R401 1-216-809-11 METAL CHIP 100 5% 1/10W
R431 1-216-849-11 METAL CHIP 220K 5% 1/10W
R432 1-216-849-11 METAL CHIP 220K 5% 1/10W
R434 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R435 1-216-845-11 METAL CHIP 100K 5% 1/10W
R436 1-216-797-11 METAL CHIP 10 5% 1/10W
R451 1-216-849-11 METAL CHIP 220K 5% 1/10W
R452 1-216-849-11 METAL CHIP 220K 5% 1/10W
R454 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R455 1-216-845-11 METAL CHIP 100K 5% 1/10W
R456 1-216-797-11 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV201 1-227-617-11 RES, VAR, CARBON 50K (VOL)
< SWITCH >
S101 1-572-552-41 SWITCH, SLIDE (FM, AM)
S501 1-786-936-21 SWITCH, SLIDE (POWER)
< THERMISTOR >
TH501 1-805-671-11 THERMISTOR (POSITIVE)
*************************************************************
MISCELLANEOUS
**************
ANT1 1-501-247-61 ANTENNA, TELESCOPIC (FM)
SP1 X-2584-348-1 CABINET (FRONT) SUB ASSY
(Including SPEAKER (3.6 cm)) (for BLACK)
SP1 X-2584-349-1 CABINET (FRONT) SUB ASSY
(Including SPEAKER (3.6 cm)) (for WHITE)
SP1 X-2584-350-1 CABINET (FRONT) SUB ASSY
(Including SPEAKER (3.6 cm)) (for PINK)
*************************************************************
ACCESSORIES
************
1-839-478-21 CORD (WITH PLUG) (Audio connecting cable
(stereo mini plug y stereo mini plug))
4-297-963-21 MANUAL, INSTRUCTION (ENGLISH, SPANISH,
TRADITIONAL CHINESE, KOREAN)
MAIN
Ver. 1.1
