Sony SRF-18 - Main Board Removal

SRF-18
5
1-4. MAIN BOARD
2 knob (band)
qa MAIN board
9 holder (DC)
0 battery terminal (-)
3 pointer
convex part
convex part
chassis block
chassis block
Knob (tune) is turned until it stops
in the direction of an arrow.
ditch
ditch
6 chassis block
8 screw (1.7)
5 screw (1.7)
1 two claws
4 screw (B)
(1.4 u 6)
7 Remove the solder.
3RLQWHULQVWDOODWLRQ
OK NG
guide line
guide line
pointer
pointer
