Sony SRF-18 - Disassembly Procedure; Disassembly Flow Chart

SRF-18
2
SECTION 1
DISASSEMBLY
• This set can be disassembled in the order shown below.
1-1. DISASSEMBLY FLOW
1-2. FRONT CABINET BLOCK
(Page 3)
1-3. MAIN BOARD BLOCK
(Page 4)
SET
1-4. MAIN BOARD
(Page 5)
1-5. KNOB (TUNE)
(Page 6)
1-6. GEAR (VC)
(Page 6)
