Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
62
HCD-CL1/CL3
R742 1-249-406-11 CARBON 120 5% 1/4W F
R744 1-249-406-11 CARBON 120 5% 1/4W F
R746 1-249-406-11 CARBON 120 5% 1/4W F
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-247-807-31 CARBON 100 5% 1/4W
R749 1-247-807-31 CARBON 100 5% 1/4W
R793 1-247-807-31 CARBON 100 5% 1/4W
R794 1-247-807-31 CARBON 100 5% 1/4W
R795 1-247-807-31 CARBON 100 5% 1/4W
R796 1-249-425-11 CARBON 4.7K 5% 1/4W F
R797 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S701 1-762-875-21 SWITCH, KEYBOARD (POWER)
S706 1-473-392-11 ENCODER, ROTARY (VOLUME)
S707 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S711 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S712 1-762-875-21 SWITCH, KEYBOARD (REC)
S713 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S714 1-762-875-21 SWITCH, KEYBOARD (DBFB)
S715 1-762-875-21 SWITCH, KEYBOARD (STOP)
S716 1-762-875-21 SWITCH, KEYBOARD (CD PLAY)
S717 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S718 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S719 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE/DIRECTION)
S720 1-762-875-21 SWITCH, KEYBOARD (REPEAT STEREO/MONO)
S721 1-762-875-21 SWITCH, KEYBOARD (DIMMER)
S722 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S723 1-762-875-21 SWITCH, KEYBOARD (TAPE PLAY)
S724 1-762-875-21 SWITCH, KEYBOARD (MD/VIDEO)
S741 1-762-875-21 SWITCH, KEYBOARD (CD1)
S742 1-762-875-21 SWITCH, KEYBOARD (CD1 EJECT)
S743 1-762-875-21 SWITCH, KEYBOARD (CD2)
S744 1-762-875-21 SWITCH, KEYBOARD (CD2 EJECT)
S745 1-762-875-21 SWITCH, KEYBOARD (CD3)
S746 1-762-875-21 SWITCH, KEYBOARD (CD3 EJECT)
S747 1-762-875-21 SWITCH, KEYBOARD (LEFT)
S748 1-762-875-21 SWITCH, KEYBOARD (UP)
S749 1-762-875-21 SWITCH, KEYBOARD (RIGHT)
S750 1-762-875-21 SWITCH, KEYBOARD (DOWN)
************************************************************
1-679-982-11 RING SWITCH BOARD
*****************
< RESISTOR >
R791 1-249-427-11 CARBON 6.8K 5% 1/4W F
R792 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S791 1-786-084-11 SWITCH, DETECTION
************************************************************
1-680-257-11 SUB POWER BOARD
****************
< CAPACITOR >
0C911 1-113-925-11 CERAMIC 0.01uF 20% 250V
C912 1-126-768-11 ELECT 2200uF 20% 16V
C913 1-124-584-00 ELECT 100uF 20% 10V
< CONNECTOR >
CN911 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
0D911 8-719-911-19 DIODE 1SS133T-72
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-024-99 DIODE 11ES2-NTA2B
D915 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC911 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q911 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R911 1-249-429-11 CARBON 10K 5% 1/4W
R912 1-249-441-11 CARBON 100K 5% 1/4W
R913 1-249-401-11 CARBON 47 5% 1/4W F
< RELAY >
0RY911 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T911 1-435-849-11 TRANSFORMER, POWER (CL1:US)
0T911 1-435-850-11 TRANSFORMER, POWER
(CL1:AEP,UK/CL3:AEP,UK)
0T911 1-435-851-11 TRANSFORMER, POWER
(CL1:AUS,E,MX,TW,KR/CL3:MX,KR)
************************************************************
A-4476-076-A TC BOARD, COMPLETE
******************
< CAPACITOR >
C129 1-126-964-11 ELECT 10uF 20% 50V
C326 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C327 1-104-665-11 ELECT 100uF 20% 10V
C328 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C329 1-130-483-00 MYLAR 0.01uF 5% 50V
C330 1-126-964-11 ELECT 10uF 20% 50V
C331 1-126-965-11 ELECT 22uF 20% 50V
C332 1-137-427-11 MYLAR 120PF 5% 50V
C333 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C334 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C335 1-137-150-11 MYLAR 0.01uF 5% 100V
C336 1-126-961-11 ELECT 2.2uF 20% 50V
C337 1-130-485-00 MYLAR 0.015uF 5% 50V
C338 1-130-481-00 MYLAR 0.0068uF 5% 50V
C339 1-130-481-00 MYLAR 0.0068uF 5% 50V
C340 1-130-486-00 MYLAR 0.018uF 10% 50V
C341 1-126-960-11 ELECT 1uF 20% 50V
C342 1-104-664-11 ELECT 47uF 20% 16V
C376 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C377 1-104-665-11 ELECT 100uF 20% 10V
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
RING SWITCH SUB POWERPANEL TC
