Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
63
HCD-CL1/CL3
THERMAL
C378 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C379 1-130-483-00 MYLAR 0.01uF 5% 50V
C380 1-126-964-11 ELECT 10uF 20% 50V
C381 1-126-965-11 ELECT 22uF 20% 50V
C382 1-137-427-11 MYLAR 120PF 5% 50V
C383 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C384 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
< IC >
IC302 8-759-143-54 IC uPC1330HA
IC304 8-759-656-83 IC NJM4580MD-TE
< COIL >
L301 1-410-780-11 INDUCTOR 27MH
L351 1-410-780-11 INDUCTOR 27MH
< TRANSISTOR >
Q301 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q302 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q303 8-729-142-46 TRANSISTOR 2SC2001TP-LK
Q304 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q305 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R336 1-216-846-11 METAL CHIP 120K 5% 1/16W
R337 1-216-813-11 METAL CHIP 220 5% 1/16W
R338 1-216-837-11 METAL CHIP 22K 5% 1/16W
R339 1-216-834-11 METAL CHIP 12K 5% 1/16W
R340 1-216-850-11 METAL CHIP 270K 5% 1/16W
R341 1-216-813-11 METAL CHIP 220 5% 1/16W
R342 1-216-834-11 METAL CHIP 12K 5% 1/16W
0 R343 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0 R344 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R345 1-216-836-11 METAL CHIP 18K 5% 1/16W
R346 1-216-836-11 METAL CHIP 18K 5% 1/16W
R347 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R348 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R349 1-216-821-11 METAL CHIP 1K 5% 1/16W
R386 1-216-846-11 METAL CHIP 120K 5% 1/16W
R387 1-216-813-11 METAL CHIP 220 5% 1/16W
R388 1-216-837-11 METAL CHIP 22K 5% 1/16W
R389 1-216-834-11 METAL CHIP 12K 5% 1/16W
R390 1-216-850-11 METAL CHIP 270K 5% 1/16W
R391 1-216-864-91 SHORT 0
R392 1-216-834-11 METAL CHIP 12K 5% 1/16W
R393 1-216-837-11 METAL CHIP 22K 5% 1/16W
R394 1-216-813-11 METAL CHIP 220 5% 1/16W
R396 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R397 1-216-821-11 METAL CHIP 1K 5% 1/16W
R398 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
< VARIABLE RESISTOR >
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
1-680-270-11 THERMAL BOARD
**************
< CONNECTOR >
CN803 1-568-951-11 PIN, CONNECTOR 2P
< THERMISTOR(POSITIVE) >
THP842 1-807-796-11 THERMISTOR
************************************************************
1-680-256-11 TRANS BOARD
************
1-533-217-11 HOLDER, FUSE
< CAPACITOR >
C901 1-136-165-00 FILM 0.1uF 5% 50V
(CL1)
C901 1-130-777-00 MYLAR 0.1uF 5% 100V
(CL3)
C902 1-136-165-00 FILM 0.1uF 5% 50V
(CL1)
C902 1-130-777-00 MYLAR 0.1uF 5% 100V
(CL3)
C931 1-164-159-11 CERAMIC 0.1uF 50V
(CL3)
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
(CL1:US,AEP,UK,AUS,MX,KR/CL3)
* CN902 1-564-523-11 PLUG, CONNECTOR 8P
* CN903 1-568-941-11 PIN, CONNECTOR 3P (CL3)
* CN904 1-564-518-11 PLUG, CONNECTOR 3P (CL3)
< DIODE >
D901 8-719-028-23 DIODE D3SBA20-4101 (CL1)
D901 8-719-510-68 DIODE D5SBA204101 (CL3)
< FUSE >
0 F901 1-533-451-11 FUSE, GLASS TUBE (DIA.5) 3.15A/125V(CL1:US)
0 F901 1-533-466-11 FUSE, GLASS TUBE (DIA.5) 1.25A/250V
(CL1:AEP,UK)
0 F901 1-533-469-11 FUSE, GLASS TUBE (DIA.5) 2.5A/250V
(CL1:E,MX,TW/CL3:AEP,UK)
0 F901 1-533-471-11 FUSE, GLASS TUBE (DIA.5) 4A/250V(CL3:MX)
0 F902 1-533-466-11 FUSE, GLASS TUBE (DIA.5) 1.25A/250V
(CL1:E,TW,KR/CL3:KR)
0 F903 1-533-465-11 FUSE, GLASS TUBE (DIA.5) 1A/250V
(CL1:AUS,E,TW)
< TRANSISTOR >
Q931 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL3)
Q932 8-729-140-04 TRANSISTOR 2SB1116-TP-LK (CL3)
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
TC TRANS
