3
STR-DA3ES/DA5ES/VA555ES
GENERAL
Power requirements 120 V AC, 60 Hz
Power consumption
Models of area code U
STR-DA5ES: 420 W
STR-DA3ES: 410 W
Models of area code CA
STR-DA5ES: 470 W
STR-DA3ES: 450 W
Power consumption (during standby mode)
1 W
AC outlets 2 switched, 120 W/1A
Dimensions 430 X 174 X 465 mm
including projecting parts
and controls
Mass (Approx.)
STR-DA5ES: 20.0 kg
STR-DA3ES: 20.0 kg
FM wire antenna (1)
AM loop antenna (1)
Audio/video/control S cord (1)
Control S cord (mini jack) (1)
Remote commander RM-LJ305 (STR-DA5ES) (1)
Remote commander RM-US105 (STR-DA5ES) (1)
Remote commander RM-PP505L (STR-DA3ES) (1)
R6 (size-AA) batteries (2)
LR6 (size-AA) batteries (3) (STR-DA5ES only. For
RM-LJ305)
STR-VA555ES
AMPLIFIER SECTION
Models of area code E:
Rated Power Output at Stereo Mode
(8 ohms 20 Hz – 20 kHz, THD 0.05 %)
100 W + 100 W
1)
(4 ohms 20 Hz – 20 kHz, THD 0.09 %)
90 W + 90 W
1)
Reference Power Output
(8 ohms 20 Hz – 20 kHz, THD 0.05 %)
FRONT
3)
: 100 W + 100 W
CENTER
3)
: 100 W
SURR
3)
: 100 W + 100 W
SURR BACK
3)
: 100 W
(4 ohms 20 Hz – 20 kHz, THD 0.09 %)
FRONT
3)
: 90 W + 90 W
CENTER
3)
: 90 W
SURR
3)
: 90 W + 90 W
SURR BACK
3)
: 90 W
Models of area code CH, AEP:
Rated Power Output at Stereo Mode
(8 ohms 1 kHz, THD 0.7 %)
100 W + 100 W
1)
90 W + 90 W
2)
(4 ohms 1 kHz, THD 0.7 %)
90 W + 90 W
1)
80 W + 80 W
2)
Reference Power Output
2)
(8 ohms 1 kHz, THD 0.7 %)
FRONT
3)
: 100 W + 100 W
CENTER
3)
: 100 W
SURR
3)
: 100 W + 100 W
SURR BACK
3)
: 100 W
(4 ohms 1 kHz, THD 0.7 %)
FRONT
3)
: 90 W + 90 W
CENTER
3)
: 90 W
SURR
3)
: 90 W + 90 W
SURR BACK
3)
: 90 W
(8 ohms 20 Hz – 20 kHz, THD 0.05 %)
FRONT
3)
: 90 W + 90 W
CENTER
3)
: 90 W
SURR
3)
: 90 W + 90 W
SURR BACK
3)
: 90 W
(4 ohms 20 Hz – 20 kHz, THD 0.05 %)
FRONT
3)
: 80 W + 80 W
CENTER
3)
: 80 W
SURR
3)
: 80 W + 80 W
SURR BACK
3)
: 80 W
SPECIFICATIONS (CONTINUED)
1) Measured under the following conditions:
Area code Power requirements
E 240 V AC, 50 Hz
CH, AEP 230 V AC, 50 Hz
2) Measured under the following conditions:
Area code Power requirements
CH, KR 220 V AC, 50 Hz
3) Depending on the sound field settings and the
source, there may be no sound output.
Frequency response
PHONO RIAA equalization curve
±0.5 dB
CD/SACD, TAPE, 10 Hz – 100 kHz
MD/DAT, TV/SAT, +0.5/–2 dB (with sound
DVD/LD, VIDEO 1, 2, field, equalizer, and bass
3 boost bypassed)
Inputs (Analog)
PHONO Sensitivity: 2.5 mV
Impedance: 50 kilohms
S/N
4)
: 86 dB (A, 2.5 mV
5)
)
MULTI CHANNEL Sensitivity: 150 mV
INPUT 1, 2, CD/ Impedance: 50 kilohms
SACD, TAPE, MD/ S/N
4)
: 100 dB
DAT, DVD/LD, TV/ (A, 150 mV
5)
)
SAT, VIDEO 1, 2, 3
4) INPUT SHORT.
5) Weighted network, input level.
