4
STR-DA3ES/DA5ES/VA555ES
Inputs (Digital)
CD/SACD, DVD/LD Sensitivity: –
(Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
DVD/LD, TV/SAT, Sensitivity: –
MD/DAT (Optical) Impedance: –
S/N: 100 dB
(A, 20 kHz LPF)
Outputs
TAPE, MD/DAT Voltage: 150 mV
(REC OUT), VIDEO Impedance: 22 kilohms
1, 2 (AUDIO OUT)
FRONT L/R, Voltage: 2 V
CENTER, Impedance: 1 kilohms
SURROUND L/R,
SURROUND BACK,
SUB WOOFER
EQ
BASS: 99 Hz~1.0 kHz
(21 steps)
MID (FRONT L/R, CENTER only):
198 Hz~10 kHz
(36 steps)
TREBLE: 1.0 kHz~10 kHz
(23 steps)
Gain levels: ±10 dB, 1 dB step
AM TUNER SECTION
Tuning range
Models of area code E
With 10-kHz tuning scale: 530 – 1610 kHz
6)
With 9-kHz tuning scale: 531 – 1602 kHz
6)
Models of area code CH, AEP
With 9-kHz tuning scale: 531 – 1602 kHz
Antenna Loop antenna
Usable sensitivity 50 dB/m (at 1,000 kHz or
999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m,
400 Hz)
Selectivity
At 9 kHz: 35 dB
At 10 kHz: 40 dB
6) You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. Hold down TUNING + and press
X/1 . All preset stations will be erased when you
change the tuning scale. To reset the scale to
10 kHz (or 9 kHz), repeat the procedure.
VIDEO SECTION
Inputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
Outputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
REMOTE CONTROL
Remote control system
Infrared control
Power requirements 4.5 V DC with three LR6
(size-AA) alkaline
batteries
Dimensions 175 x 62 x 33 mm
Mass (approx.) 135 g excluding batteries
FM TUNER SECTION
Tuning range 87.5 – 108.0 MHz
Antenna terminals 75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
