61
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R709 1-216-025-11 RES-CHIP 100 5% 1/10W
R721 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R722 1-216-077-91 RES-CHIP 15K 5% 1/10W
R723 1-216-093-91 RES-CHIP 68K 5% 1/10W
0 R724 1-249-393-11 CARBON 10 5% 1/4W F
0 R725 1-249-393-11 CARBON 10 5% 1/4W F
R726 1-259-977-11 CARBON MELF 33 2% 1/8W
R727 1-240-855-91 CARBON 6.2K 5% 1/4W
R728 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R729 1-216-089-91 RES-CHIP 47K 5% 1/10W
0 R730 1-249-393-11 CARBON 10 5% 1/4W F
R743 1-216-081-00 METAL CHIP 22K 5% 1/10W
R751 1-259-995-11 CARBON MELF 1K 2% 1/8W
R752 1-208-571-11 RES-CHIP 68K 2% 1/8W
R753 1-249-494-11 CARBON 68K 5% 1/2W
R754 1-249-683-31 CARBON 2.7K 5% 1/2W
R759 1-216-025-11 RES-CHIP 100 5% 1/10W
R771 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R772 1-216-077-91 RES-CHIP 15K 5% 1/10W
R773 1-216-093-91 RES-CHIP 68K 5% 1/10W
0 R774 1-249-393-11 CARBON 10 5% 1/4W F
0 R775 1-249-393-11 CARBON 10 5% 1/4W F
R776 1-259-977-11 CARBON MELF 33 2% 1/8W
R777 1-240-855-91 CARBON 6.2K 5% 1/4W
R778 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R779 1-216-089-91 RES-CHIP 47K 5% 1/10W
0 R780 1-249-393-11 CARBON 10 5% 1/4W F
<VALIABLE RESISTOR>
RV501 1-238-598-11 RES, ADJ, CARBON 2.2K
(IDRING CURRENT FRONT L)
RV551 1-238-598-11 RES, ADJ, CARBON 2.2K
(IDRING CURRENT FRONT R)
RV601 1-238-598-11 RES, ADJ, CARBON 2.2K
(IDRING CURRENT CENTER)
RV651 1-238-598-11 RES, ADJ, CARBON 2.2K
(IDRING CURRENT SURR BACK)
RV701 1-238-598-11 RES, ADJ, CARBON 2.2K
(IDRING CURRENT SURR L)
RV751 1-238-598-11 RES, ADJ, CARBON 2.2K
(IDRING CURRENT SURR R)
<RELAY>
RY504 1-515-793-11 RELAY
******************************************************
A-4476-686-A C-VIDEO BOARD,COMPLETE
********************
<CAPACITOR>
C201 1-119-824-11 ELECT MELF 10uF 20% 50V
C202 1-119-824-11 ELECT MELF 10uF 20% 50V
C203 1-119-824-11 ELECT MELF 10uF 20% 50V
C204 1-119-824-11 ELECT MELF 10uF 20% 50V
C206 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C207 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C208 1-119-824-11 ELECT MELF 10uF 20% 50V
C209 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C210 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C211 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C212 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C213 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C214 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C238 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C240 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C253 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C255 1-128-834-11 ELECT 470uF 20% 10V
C278 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C280 1-119-824-11 ELECT MELF 10uF 20% 50V
C281 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C282 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C283 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C284 1-119-824-11 ELECT MELF 10uF 20% 50V
C285 1-119-824-11 ELECT MELF 10uF 20% 50V
C286 1-119-824-11 ELECT MELF 10uF 20% 50V
C287 1-119-824-11 ELECT MELF 10uF 20% 50V
C288 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C289 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C290 1-128-834-11 ELECT 470uF 20% 10V
C291 1-119-824-11 ELECT MELF 10uF 20% 50V
C292 1-119-824-11 ELECT MELF 10uF 20% 50V
C293 1-119-824-11 ELECT MELF 10uF 20% 50V
C294 1-119-824-11 ELECT MELF 10uF 20% 50V
C295 1-119-824-11 ELECT MELF 10uF 20% 50V
C296 1-119-824-11 ELECT MELF 10uF 20% 50V
C297 1-164-690-91 CERAMIC CHIP 0.0022uF 5% 50V
C298 1-128-834-11 ELECT 470uF 20% 10V
C299 1-128-834-11 ELECT 470uF 20% 10V
C2003 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2005 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C2009 1-164-690-91 CERAMIC CHIP 0.0022uF 5% 50V
C2014 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C2015 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C2016 1-163-089-00 CERAMIC CHIP 6PF 50V
C2017 1-163-089-00 CERAMIC CHIP 6PF 50V
C2018 1-163-089-00 CERAMIC CHIP 6PF 50V
C2019 1-128-830-11 ELECT 47uF 20% 10V
C2020 1-128-830-11 ELECT 47uF 20% 10V
C2021 1-128-830-11 ELECT 47uF 20% 10V
C2022 1-128-830-11 ELECT 47uF 20% 10V
C2023 1-165-319-11 CERAMIC CHIP 0.1uF 50V
<CONNECTOR>
CNS200 1-568-830-11 CONNECTOR, FFC 11P
CNS205 1-784-774-11 CONNECTOR, FFC 13P
<DIODE>
D202 8-719-801-78 DIODE 1SS184
<FERRITE BEAD>
FB201 1-216-296-11 SHORT 0
FB260 1-469-642-11 FILTER, EMI (SMD) (VA555ES)
FB261 1-469-642-11 FILTER, EMI (SMD) (VA555ES)
FB262 1-469-642-11 FILTER, EMI (SMD) (VA555ES)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
AMP
C-VIDEO
