62
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
<IC>
IC201 8-759-536-24 IC NJM-2296M-TE2
IC211 8-759-536-24 IC NJM-2296M-TE2
IC212 6-700-051-01 IC OPA2652
IC213 6-700-051-01 IC OPA2652
IC214 8-759-011-65 IC TC74HC4053AF(EL)
<JACK>
J200 1-794-435-11 JACK, PIN 2P (MONITOR,TV/SAT)
J201 1-770-337-21 JACK, PIN 3P (DVD/LD,VIDEO2)
J202 1-770-337-21 JACK, PIN 3P (VIDEO1,2ND ROOM)
J212 1-794-313-11 JACK, PIN (BLOCK) 9P (COMPONENT VIDEO)
<JUMPER RESISTOR>
JR260 1-216-296-00 CONDUCTOR, CHIP (3216) (DA3ES, DA5ES)
JR261 1-216-296-00 CONDUCTOR, CHIP (3216) (DA3ES, DA5ES)
JR263 1-216-296-00 CONDUCTOR, CHIP (3216) (DA3ES, DA5ES)
<COIL>
L206 1-410-482-31 INDUCTOR 100uH
L207 1-410-482-31 INDUCTOR 100uH
L208 1-410-482-31 INDUCTOR 100uH
L209 1-410-482-31 INDUCTOR 100uH
<TRANSISTOR>
Q204 8-729-230-49 TRANSISTOR 2SC2712-YG
Q205 8-729-230-49 TRANSISTOR 2SC2712-YG
Q206 8-729-230-49 TRANSISTOR 2SC2712-YG
Q207 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q208 8-729-027-43 TRANSISTOR DTC114EKA-T146
<RESISTOR>
R201 1-216-022-00 METAL CHIP 75 5% 1/10W
R202 1-216-022-00 METAL CHIP 75 5% 1/10W
R203 1-216-022-00 METAL CHIP 75 5% 1/10W
R204 1-216-022-00 METAL CHIP 75 5% 1/10W
R205 1-216-022-00 METAL CHIP 75 5% 1/10W
R206 1-216-022-00 METAL CHIP 75 5% 1/10W
R207 1-216-022-00 METAL CHIP 75 5% 1/10W
R234 1-216-073-91 RES-CHIP 10K 5% 1/10W
R240 1-216-097-11 RES-CHIP 100K 5% 1/10W
R241 1-216-073-91 RES-CHIP 10K 5% 1/10W
R253 1-216-022-00 METAL CHIP 75 5% 1/10W
R256 1-216-049-11 RES-CHIP 1K 5% 1/10W
R257 1-216-022-00 METAL CHIP 75 5% 1/10W
R258 1-216-022-00 METAL CHIP 75 5% 1/10W
R259 1-216-022-00 METAL CHIP 75 5% 1/10W
R260 1-216-022-00 METAL CHIP 75 5% 1/10W
R261 1-216-022-00 METAL CHIP 75 5% 1/10W
R262 1-216-022-00 METAL CHIP 75 5% 1/10W
R263 1-216-022-00 METAL CHIP 75 5% 1/10W
R264 1-216-022-00 METAL CHIP 75 5% 1/10W
R265 1-216-022-00 METAL CHIP 75 5% 1/10W
R266 1-216-049-11 RES-CHIP 1K 5% 1/10W
R267 1-216-049-11 RES-CHIP 1K 5% 1/10W
R268 1-216-049-11 RES-CHIP 1K 5% 1/10W
R271 1-216-022-00 METAL CHIP 75 5% 1/10W
R275 1-216-022-00 METAL CHIP 75 5% 1/10W
R280 1-216-022-00 METAL CHIP 75 5% 1/10W
R281 1-216-037-00 METAL CHIP 330 5% 1/10W
R282 1-216-037-00 METAL CHIP 330 5% 1/10W
R283 1-216-037-00 METAL CHIP 330 5% 1/10W
R284 1-216-037-00 METAL CHIP 330 5% 1/10W
R285 1-216-037-00 METAL CHIP 330 5% 1/10W
R286 1-216-037-00 METAL CHIP 330 5% 1/10W
R287 1-216-022-00 METAL CHIP 75 5% 1/10W
R288 1-216-022-00 METAL CHIP 75 5% 1/10W
R289 1-216-022-00 METAL CHIP 75 5% 1/10W
R291 1-216-295-91 SHORT 0
R292 1-216-295-91 SHORT 0
R293 1-216-295-91 SHORT 0
*****************************************************
A-4476-736-A CLOCK BOARD, COMPLETE (VA555ES)
****************************
<CAPACITOR>
C2010 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C256 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C257 1-163-091-00 CERAMIC CHIP 8PF 50V
C258 1-163-091-00 CERAMIC CHIP 8PF 50V
C259 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C260 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C261 1-128-840-11 ELECT 47uF 20% 16V
<CONNECTOR>
CNS202 1-770-593-41 CONNECTOR, BOARD TO BOARD 5P
<TRIMMER>
CT201 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (VCO)
CT202 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (VCO)
<FERRITE BEAD>
FB203 1-414-813-11 FERRITE 0uH
<IC>
IC207 8-759-242-70 IC TC7WU04F(TE12R)
IC208 8-759-032-01 IC TC74HC00AF(EL)
<RESISTOR>
R242 1-216-025-11 RES-CHIP 100 5% 1/10W
R243 1-216-035-00 METAL CHIP 270 5% 1/10W
R244 1-216-035-00 METAL CHIP 270 5% 1/10W
R269 1-216-025-11 RES-CHIP 100 5% 1/10W
R270 1-216-025-11 RES-CHIP 100 5% 1/10W
R276 1-216-121-11 RES-CHIP 1M 5% 1/10W
R277 1-216-121-11 RES-CHIP 1M 5% 1/10W
<VIBLATOR>
X200 1-781-820-21 VIBRATOR, CRYSTAL (17.34MHz)
X201 1-781-821-21 VIBRATOR, CRYSTAL (14.31MHz)
******************************************************
A-4476-674-A DC BOARD, COMPLETE(DA5ES,VA555ES)
A-4476-758-A DC BOARD, COMPLETE (DA3ES)
******************************
1-533-399-31 HOLDER, FUSE
< CAPACITOR >
C801 1-115-684-21 MYLAR 0.0047uF 5% 100V
C802 1-115-684-21 MYLAR 0.0047uF 5% 100V
C803 1-135-926-11 ELECT 15000uF 20% 71V
(EXCEPT DA3ES)
C-VIDEO
CLOCK DC
