STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
DIGITAL
C803 1-137-666-12 ELECT 15000uF 20% 71V
(DA3ES)
C804 1-125-900-12 ELECT 15000uF 20% 71V
(EXCEPT DA3ES)
C804 1-137-666-12 ELECT 15000uF 20% 71V
(DA3ES)
C805 1-126-860-11 ELECT 47uF 20% 50V
C808 1-119-815-21 ELECT 2200uF 20% 35V
C809 1-119-815-21 ELECT 2200uF 20% 35V
C812 1-128-860-11 ELECT 47uF 20% 50V
C815 1-128-873-91 ELECT 220uF 20% 63V
C816 1-128-860-11 ELECT 47uF 20% 50V
C822 1-106-377-00 MYLAR 0.027uF 99% 200V
C823 1-126-939-11 ELECT 10000uF 20% 16V
C824 1-127-721-11 ELECT 1000uF 20% 16V
< CONNECTOR >
CN801 1-564-104-11 PIN, CONNECTOR 3P
CNP801 1-784-925-11 PIN, CONNECTOR 10P
CNP802 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CNP803 1-785-102-11 PIN, CONNECTOR 4P
CNP804 1-691-769-11 PLUG (MICRO CONNECTOR) 7P
< DIODE >
D801 8-719-083-47 DIODE KCH30A5
D802 8-719-083-48 DIODE KRH30A5
D803 8-719-083-89 DIODE 11ES2N-TB5
D804 8-719-083-89 DIODE 11ES2N-TB5
D805 8-719-083-89 DIODE 11ES2N-TB5
D806 8-719-083-89 DIODE 11ES2N-TB5
D807 8-719-510-53 DIODE D4SB60L
D811 8-719-057-00 DIODE UDZ-TE-17-36B
D812 8-719-083-89 DIODE 11ES2N-TB5
D813 8-719-083-89 DIODE 11ES2N-TB5
D814 8-719-056-77 DIODE UDZ-TE-17-3.9B
D816 8-719-070-30 DIODE PTZ-TE25-5.6A
< FUSE >
0 F801 1-533-312-11 FUSE, GLASS CYLINDRICAL(DIA.5) 10A/125V
0 F802 1-533-312-11 FUSE, GLASS CYLINDRICAL(DIA.5) 10A/125V
0 F805 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5) 4A/125V
(DA3ES,DA5ES,VA555ES:E)
0 F805 1-532-464-51 FUSE T2.5AL/250V (VA555ES:AEP,CH,KR)
0 F806 1-533-419-11 FUSE, GLASS CYLINDRICAL(DIA.5) 4A/125V
(DA3ES,DA5ES,VA555ES:E)
0 F806 1-532-464-51 FUSE T2.5AL/250V (VA555ES:AEP,CH,KR)
< TRANSISTOR >
Q801 8-729-140-96 TRANSISTOR 2SD774-T-34
< RESISTOR >
R801 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
0 R802 1-249-401-11 CARBON 47 5% 1/4W F
R803 1-216-081-00 METAL CHIP 22K 5% 1/10W
0 R804 1-216-349-00 METAL OXIDE 1 5% 1W F
0 R805 1-216-349-00 METAL OXIDE 1 5% 1W
0 R806 1-249-381-11 CARBON 1 5% 1/4W F
0 R807 1-249-381-11 CARBON 1 5% 1/4W F
0 R808 1-249-416-91 CARBON 820 5% 1/4W F
******************************************************
A-4476-738-A DIGITAL BOARD,COMPLETE (DA5ES)
A-4476-739-A DIGITAL BOARD,COMPLETE (VA555ES:AEP)
A-4476-740-A DIGITAL BOARD,COMPLETE (VA555ES:E)
A-4476-741-A DIGITAL BOARD,COMPLETE (VA555ES:CH,KR)
A-4476-765-A DIGITAL BOARD,COMPLETE (DA3ES)
*********************************
*
3-309-144-21 HEAT SINK
7-685-646-79 SCREW +BVTP3X8 TYPE2 IT-3
<CAPACITOR>
C1101 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C1102 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1103 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1104 1-128-858-91 ELECT 22uF 20% 25V
C1105 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1107 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C1108 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C1109 1-128-840-11 ELECT 47uF 20% 16V
C1110 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1112 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1113 1-128-846-11 ELECT 330uF 20% 16V
C1114 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1115 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1117 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1119 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1120 1-163-005-91 CERAMIC CHIP 470PF 10% 50V
C1201 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1202 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1203 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1204 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1205 1-127-719-91 ELECT MELF 220uF 20% 16V
C1206 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1207 1-127-719-91 ELECT MELF 220uF 20% 16V
C1208 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1209 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1210 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1211 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1212 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1213 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1214 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1215 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1216 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1217 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1218 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1219 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1301 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA5ES,VA555ES)
C1302 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA5ES,VA555ES)
C1303 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA5ES,VA555ES)
C1401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1402 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1403 1-165-319-11 CERAMIC CHIP 0.1uF 50V
DC
