Sony STR-DA3ES - Page 70

70
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R2109 1-216-025-11 RES-CHIP 100 5% 1/10W
R2110 1-216-025-11 RES-CHIP 100 5% 1/10W
R2111 1-216-025-11 RES-CHIP 100 5% 1/10W
R2112 1-216-025-11 RES-CHIP 100 5% 1/10W
R2113 1-216-025-11 RES-CHIP 100 5% 1/10W
R2114 1-216-025-11 RES-CHIP 100 5% 1/10W
R2115 1-216-025-11 RES-CHIP 100 5% 1/10W
R2116 1-216-025-11 RES-CHIP 100 5% 1/10W
R2117 1-216-025-11 RES-CHIP 100 5% 1/10W
R2118 1-216-025-11 RES-CHIP 100 5% 1/10W
R2119 1-216-025-11 RES-CHIP 100 5% 1/10W
R2120 1-216-025-11 RES-CHIP 100 5% 1/10W
R2121 1-216-025-11 RES-CHIP 100 5% 1/10W
R2122 1-216-025-11 RES-CHIP 100 5% 1/10W
R2123 1-216-025-11 RES-CHIP 100 5% 1/10W
R2124 1-216-025-11 RES-CHIP 100 5% 1/10W
R2125 1-216-025-11 RES-CHIP 100 5% 1/10W
R2126 1-216-025-11 RES-CHIP 100 5% 1/10W
R2127 1-216-025-11 RES-CHIP 100 5% 1/10W
R2128 1-216-025-11 RES-CHIP 100 5% 1/10W
R2129 1-216-025-11 RES-CHIP 100 5% 1/10W
R2130 1-216-025-11 RES-CHIP 100 5% 1/10W
R2131 1-216-025-11 RES-CHIP 100 5% 1/10W
R2132 1-216-025-11 RES-CHIP 100 5% 1/10W
R2133 1-216-025-11 RES-CHIP 100 5% 1/10W
R2134 1-216-025-11 RES-CHIP 100 5% 1/10W
R2135 1-216-025-11 RES-CHIP 100 5% 1/10W
R2136 1-216-025-11 RES-CHIP 100 5% 1/10W
R2137 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2138 1-216-025-11 RES-CHIP 100 5% 1/10W
R2139 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2140 1-216-025-11 RES-CHIP 100 5% 1/10W
R2141 1-216-025-11 RES-CHIP 100 5% 1/10W
R2142 1-216-025-11 RES-CHIP 100 5% 1/10W
R2144 1-216-025-11 RES-CHIP 100 5% 1/10W
R2145 1-216-025-11 RES-CHIP 100 5% 1/10W
R2146 1-216-025-11 RES-CHIP 100 5% 1/10W
R2147 1-216-025-11 RES-CHIP 100 5% 1/10W
R2148 1-216-025-11 RES-CHIP 100 5% 1/10W
R2159 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2161 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2162 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2163 1-216-097-11 RES-CHIP 100K 5% 1/10W
R2164 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2165 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2166 1-216-073-91 RES-CHIP 10K 5% 1/10W
R2167 1-216-037-00 METAL CHIP 330 5% 1/10W
<VIBLATOR>
X1101 1-795-219-21 VIBRATOR, CRYSTAL (24.576MHz)
X1201 1-795-264-21 VIBRATOR, CERAMIC (13.5MHz)
X1401 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
X1501 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
X1901 1-767-938-21 VIBRATOR, CERAMIC (7.28MHz)
X2001 1-795-179-21 VIBRATOR, CERAMIC (16.5MHz)
X2101 1-781-536-11 VIBRATOR, CRYSTAL (4.33MHz)(VA555ES:AEP)
*****************************************************
A-4476-710-A DIGITAL INPUT BOARD, COMPLETE
**************************
<CAPACITOR>
C1001 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C1002 1-128-858-11 ELECT 22uF 20% 50V
C1003 1-128-858-11 ELECT 22uF 20% 50V
C1004 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C1005 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C1006 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C1007 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C1009 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1011 1-137-658-91 ELECT 1000uF 20% 6.3V
C1012 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1013 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1014 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1015 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1017 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1018 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1019 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1021 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C1022 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1023 1-128-840-11 ELECT 47uF 20% 16V
C1024 1-165-319-11 CERAMIC CHIP 0.1uF 50V
<CONNECTOR>
CN1001 1-784-925-11 PIN, CONNECTOR 10P
<DIODE>
D1001 8-719-988-61 DIODE 1SS355TE-17
D1002 8-719-801-78 DIODE 1SS184
D1003 8-719-988-61 DIODE 1SS355TE-17
<FERRITE BEAD>
FB1001 1-469-152-11 FERRITE 0uH
FB1002 1-469-152-11 FERRITE 0uH
<IC>
IC1001 6-600-000-01 IC GP1FA512RZB (DVD/LD OPTICAL IN)
IC1002 6-600-000-01 IC GP1FA512RZB (TV/SAT OPTICAL IN)
IC1003 6-600-000-01 IC GP1FA512RZB (MD/DAT OPTICAL IN)
IC1004 6-600-001-01 IC GP1FA512TZC (MD/DAT OPTICAL OUT)
IC1005 6-600-000-01 IC GP1FA512RZB (CD/SACD OPTICAL IN)
IC1006 8-759-233-64 IC TC74HCU04AF(EL)
IC1007 8-759-243-84 IC TC74ACT151F
IC1008 8-759-566-06 IC TC7WH08FU(TE12R)
<JACK>
J1002 1-794-434-11 JACK, PIN 2P (DIGITAL IN)
<RESISTOR>
R1001 1-216-022-00 METAL CHIP 75 5% 1/10W
R1002 1-216-022-00 METAL CHIP 75 5% 1/10W
R1003 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1004 1-216-049-11 RES-CHIP 1K 5% 1/10W
R1005 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1006 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1007 1-216-115-00 METAL CHIP 560K 5% 1/10W
DIGITAL DIGITAL INPUT
