71
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R1008 1-216-115-00 METAL CHIP 560K 5% 1/10W
R1009 1-216-025-11 RES-CHIP 100 5% 1/10W
R1010 1-216-025-11 RES-CHIP 100 5% 1/10W
R1011 1-216-025-11 RES-CHIP 100 5% 1/10W
R1012 1-216-025-11 RES-CHIP 100 5% 1/10W
R1013 1-216-025-11 RES-CHIP 100 5% 1/10W
R1014 1-216-025-11 RES-CHIP 100 5% 1/10W
R1015 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1016 1-216-073-91 RES-CHIP 10K 5% 1/10W
R1017 1-216-025-11 RES-CHIP 100 5% 1/10W
******************************************************
A-4476-692-A DISPLAY BOARD,COMPLETE (DA5ES)
A-4476-693-A DISPLAY BOARD,COMPLETE (VA555ES)
A-4476-760-A DISPLAY BOARD,COMPLETE (DA3ES)
*****************************
<CAPACITOR>
C101 1-126-947-11 ELECT 47uF 20% 16V
C102 1-126-964-11 ELECT 10uF 20% 50V
C103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C104 1-126-947-11 ELECT 47uF 20% 16V
C105 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C106 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C107 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C108 1-126-947-11 ELECT 47uF 20% 16V
C109 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(DA5ES,VA555ES)
C110 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(DA5ES,VA555ES)
C111 1-126-916-11 ELECT 1000uF 20% 6.3V
C112 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
<CONNECTOR>
CNS101 1-784-776-11 CONNECTOR, FFC 15 P
CNS102 1-568-838-11 CONNECTOR, FFC 21 P
CNS103 1-770-398-11 HOUSING, CONNECTOR(PC BOARD)5P
<DIODE>
D101 8-719-075-59 DIODE SELS5B23C-TP15 (DSC)
D102 8-719-075-59 DIODE SELS5B23C-TP15 (6.1CH)
D103 8-719-075-59 DIODE SELS5B23C-TP15 (NIGHT MODE)
D104 8-719-032-98 DIODE SEL5820A (DIMMER)
D105 8-719-032-98 DIODE SEL5820A (2ND/3RD ROOM)
D106 8-719-032-98 DIODE SEL5820A (SURROUND)
D107 8-719-032-98 DIODE SEL5820A (LEVEL)
D108 8-719-032-98 DIODE SEL5820A (NAME)
D109 8-719-032-98 DIODE SEL5820A (EQ)
D110 8-719-032-98 DIODE SEL5820A (SET UP)
D111 8-719-075-86 DIODE SID307BRTP19 (SERCS OUT)
(DA5ES/VA555ES)
D112 8-719-059-14 DIODE SID313BP-TP19 (SERCS OUT)
(DA5ES/VA555ES)
D113 8-719-075-86 DIODE SID307BRTP19 (SERCS OUT)
(DA5ES/VA555ES)
D114 8-719-988-61 DIODE 1SS355TE-17 (DA5ES/VA555ES)
D115 8-719-988-61 DIODE 1SS355TE-17 (DA5ES/VA555ES)
<FLUORESCENT INDICATOR TUBE>
FL101 1-518-747-11 INDICATOR TUBE,FLUORESCENT
<IC>
IC101 8-759-459-85 IC NJL63H400A
IC102 8-759-342-19 IC NJU3716M-T2
IC103 8-759-589-67 IC BA6208F-E2
IC104 8-759-242-70 IC TC7WU04F(TE1 2R) (DA5ES/VA555ES)
<JUMPER RESISTOR>
JR110 1-216-295-91 SHORT 0
JR112 1-216-295-91 SHORT 0
<TRANSISTOR>
Q101 8-729-801-93 TRANSISTOR 2SD1387-34-TP
(DA5ES/VA555ES)
Q102 8-729-801-93 TRANSISTOR 2SD1387-34-TP
(DA5ES/VA555ES)
<RESISTOR>
R101 1-216-025-11 RES-CHIP 100 5% 1/10W
R102 1-216-025-11 RES-CHIP 100 5% 1/10W
R103 1-216-073-91 RES-CHIP 10K 5% 1/10W
R104 1-216-025-11 RES-CHIP 100 5% 1/10W
R105 1-216-025-11 RES-CHIP 100 5% 1/10W
R106 1-216-025-11 RES-CHIP 100 5% 1/10W
R107 1-216-025-11 RES-CHIP 100 5% 1/10W
R108 1-216-025-11 RES-CHIP 100 5% 1/10W
R109 1-216-025-11 RES-CHIP 100 5% 1/10W
R110 1-216-025-11 RES-CHIP 100 5% 1/10W
R111 1-216-025-11 RES-CHIP 100 5% 1/10W
R112 1-216-025-11 RES-CHIP 100 5% 1/10W
R113 1-216-025-11 RES-CHIP 100 5% 1/10W
R117 1-216-073-91 RES-CHIP 10K 5% 1/10W
R118 1-216-001-00 METAL CHIP 10 5% 1/10W
0 R119 1-249-385-11 CARBON 2.2 5% 1/6W F
0 R120 1-249-385-11 CARBON 2.2 5% 1/6W F
R121 1-216-037-00 METAL CHIP 330 5% 1/10W
R122 1-216-037-00 METAL CHIP 330 5% 1/10W
R123 1-216-089-91 RES-CHIP 47K 5% 1/10W
R124 1-216-049-11 RES-CHIP 1K 5% 1/10W
R125 1-216-049-11 RES-CHIP 1K 5% 1/10W
R126 1-216-037-00 METAL CHIP 330 5% 1/10W
R127 1-216-029-00 METAL CHIP 150 5% 1/10W
R128 1-216-029-00 METAL CHIP 150 5% 1/10W
R129 1-216-037-00 METAL CHIP 330 5% 1/10W
R130 1-216-049-11 RES-CHIP 1K 5% 1/10W
R131 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DA5ES,VA555ES)
R132 1-216-298-00 METAL CHIP 2.2 5% 1/10W
(DA5ES,VA555ES)
R133 1-216-073-91 RES-CHIP 10K 5% 1/10W
R134 1-216-073-91 RES-CHIP 10K 5% 1/10W
R135 1-216-089-91 RES-CHIP 47K 5% 1/10W
R136 1-216-089-91 RES-CHIP 47K 5% 1/10W
R137 1-216-089-91 RES-CHIP 47K 5% 1/10W
R138 1-216-081-00 METAL CHIP 22K 5% 1/10W
R139 1-216-073-91 RES-CHIP 10K 5% 1/10W
R140 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R141 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R142 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R143 1-216-049-11 RES-CHIP 1K 5% 1/10W
DISPLAY
The components identified by
mark 0 Er dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
