Sony STR-DA3ES - Page 72

72
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R144 1-216-073-91 RES-CHIP 10K 5% 1/10W
R145 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R146 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R147 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R148 1-216-049-11 RES-CHIP 1K 5% 1/10W
R149 1-216-089-91 RES-CHIP 47K 5% 1/10W
R150 1-216-081-00 METAL CHIP 22K 5% 1/10W
R151 1-216-073-91 RES-CHIP 10K 5% 1/10W
R152 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R153 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R154 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R155 1-216-049-11 RES-CHIP 1K 5% 1/10W
R156 1-216-089-91 RES-CHIP 47K 5% 1/10W
R157 1-216-081-00 METAL CHIP 22K 5% 1/10W
R158 1-216-073-91 RES-CHIP 10K 5% 1/10W
R159 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R160 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-049-11 RES-CHIP 1K 5% 1/10W
R163 1-216-073-91 RES-CHIP 10K 5% 1/10W
<VALIABLE RESISTER>
RV102 1-418-921-11 ENCODER, ROTARY
<SWITCH>
S101 1-771-349-21 SWITCH, KEYBOARD (`/1)
S102 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S103 1-771-349-21 SWITCH, KEYBOARD (DIMMER)
S104 1-771-349-21 SWITCH, KEYBOARD (NIGHT MODE)
S105 1-771-349-21 SWITCH, KEYBOARD (FM/AM)
S106 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING –)
S107 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING +)
S108 1-771-349-21 SWITCH, KEYBOARD (A.F.D)
S109 1-771-349-21 SWITCH, KEYBOARD (CINEMA STUDIO EX)
S110 1-771-349-21 SWITCH, KEYBOARD (DIGITAL CONCERT HALL)
S111 1-771-349-21 SWITCH, KEYBOARD (MODE –)
S112 1-771-349-21 SWITCH, KEYBOARD (MODE +)
S113 1-771-349-21 SWITCH, KEYBOARD (2CH)
S114 1-771-349-21 SWITCH, KEYBOARD
(MULTI 1/2CH ANALOG DIRECT)
S115 1-771-349-21 SWITCH, KEYBOARD (6.1 CH DECODING)
S116 1-771-349-21 SWITCH, KEYBOARD (TUNING –)
S117 1-771-349-21 SWITCH, KEYBOARD (TUNING +)
S118 1-771-349-21 SWITCH, KEYBOARD (2ND ROOM)
S119 1-771-349-21 SWITCH, KEYBOARD (ON SCREEN)
S120 1-771-349-21 SWITCH, KEYBOARD (SURROUND)
S121 1-771-349-21 SWITCH, KEYBOARD (LIVE)
S122 1-771-349-21 SWITCH, KEYBOARD (<)
S123 1-771-349-21 SWITCH, KEYBOARD (>)
S124 1-771-349-21 SWITCH, KEYBOARD (FM MODE)
S125 1-771-349-21 SWITCH, KEYBOARD (MEMORY)
S126 1-771-349-21 SWITCH, KEYBOARD (SLEEP)
S127 1-771-349-21 SWITCH, KEYBOARD (EQ BANK)
S128 1-771-349-21 SWITCH, KEYBOARD (NAME)
S129 1-771-349-21 SWITCH, KEYBOARD (EQ)
S130 1-771-349-21 SWITCH, KEYBOARD (ENTER)
S131 1-771-349-21 SWITCH, KEYBOARD (SET UP)
SW101 1-762-537-11 SWITCH, ROTARY (SPEAKERS) (DA3ES,DA5ES)
SW101 1-786-151-11 SWITCH, ROTARY (SPEAKERS) (VA555ES)
*****************************************************
A-4476-716-A E-VOL BOARD, COMPLETE (DA5ES)
A-4476-717-A E-VOL BOARD, COMPLETE (VA555ES)
A-4476-761-A E-VOL BOARD, COMPLETE (DA3ES)
***************************
4-228-836-01 HOLDER, FL TUBE
<CAPACITOR>
C401 1-119-825-41 ELECT 22uF 20% 50V
C402 1-119-825-41 ELECT 22uF 20% 50V
C403 1-119-779-11 ELECT 220uF 20% 10V
C404 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C405 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C406 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C407 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C408 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C409 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C410 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C411 1-119-825-41 ELECT 22uF 20% 50V
C412 1-119-825-41 ELECT 22uF 20% 50V
C413 1-119-779-11 ELECT 220uF 20% 10V
C414 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C415 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C416 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C417 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C418 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C419 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C420 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C421 1-119-825-41 ELECT 22uF 20% 50V
C422 1-119-825-41 ELECT 22uF 20% 50V
C423 1-119-779-11 ELECT 220uF 20% 10V
C424 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C425 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C426 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C427 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C428 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C429 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C430 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C431 1-119-825-41 ELECT 22uF 20% 50V
C432 1-119-825-41 ELECT 22uF 20% 50V
C433 1-119-779-11 ELECT 220uF 20% 10V
C434 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
DISPLAY
E-VOL
