Sony STR-DA3ES - Page 73

73
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C440 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C441 1-119-825-41 ELECT 22uF 20% 50V
C442 1-119-825-41 ELECT 22uF 20% 50V
C443 1-119-779-11 ELECT 220uF 20% 10V
C444 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C445 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C446 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C447 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C448 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C449 1-127-718-91 ELECT MELF 100uF 20% 16V
C450 1-119-825-41 ELECT 22uF 20% 50V
C451 1-119-825-41 ELECT 22uF 20% 50V
C452 1-119-825-41 ELECT 22uF 20% 50V
C453 1-119-779-11 ELECT 220uF 20% 10V
C454 1-119-825-41 ELECT 22uF 20% 50V
C455 1-119-825-41 ELECT 22uF 20% 50V
C456 1-119-825-41 ELECT 22uF 20% 50V
C457 1-119-825-41 ELECT 22uF 20% 50V
C458 1-119-825-41 ELECT 22uF 20% 50V
C459 1-119-825-41 ELECT 22uF 20% 50V
C460 1-119-825-41 ELECT 22uF 20% 50V
C461 1-119-825-41 ELECT 22uF 20% 50V
C462 1-119-825-41 ELECT 22uF 20% 50V
C463 1-119-779-11 ELECT 220uF 20% 10V
C466 1-137-505-11 MYLAR 220PF 5% 50V
C467 1-137-505-11 MYLAR 220PF 5% 50V
C468 1-137-505-11 MYLAR 220PF 5% 50V
C469 1-137-505-11 MYLAR 220PF 5% 50V
C470 1-137-505-11 MYLAR 220PF 5% 50V
C471 1-119-825-41 ELECT 22uF 20% 50V
C472 1-119-825-41 ELECT 22uF 20% 50V
C473 1-119-779-11 ELECT 220uF 20% 10V
C474 1-137-505-11 MYLAR 220PF 5% 50V
C475 1-137-505-11 MYLAR 220PF 5% 50V
C476 1-137-505-11 MYLAR 220PF 5% 50V
C477 1-119-827-11 ELECT 47uF 20% 50V
C478 1-119-827-11 ELECT 47uF 20% 50V
C481 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C482 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C483 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C484 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C485 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C486 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C487 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C488 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C490 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C491 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C493 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C494 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C496 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C497 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C498 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C499 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C500 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
<CONNECTOR>
CNP401 1-784-929-11 PIN, CONNECTOR 14P
CNP402 1-784-774-11 CONNECTOR, FFC 13P
CNP408 1-784-927-11 PIN, CONNECTOR 12P
<DIODE>
D401 8-719-988-61 DIODE 1SS355TE-17
D402 8-719-988-61 DIODE 1SS355TE-17
D403 8-719-988-61 DIODE 1SS355TE-17 (US,CND)
D404 8-719-988-61 DIODE 1SS355TE-17
D405 8-719-988-61 DIODE 1SS355TE-17
D406 8-719-988-61 DIODE 1SS355TE-17
D407 8-719-988-61 DIODE 1SS355TE-17
<FERRITE BEAD>
FB401 1-469-152-11 FERRITE 0uH
<IC>
IC401 8-759-663-90 IC ADM3222ARU-REEL
IC402 8-759-835-79 IC TC9274N-016
IC403 8-759-835-76 IC TC94A07 P
IC404 8-759-835-76 IC TC94A07 P
IC405 8-759-835-76 IC TC94A07 P
IC406 8-759-835-76 IC TC94A07 P
IC407 8-759-710-59 IC NJM4580D-D
IC408 8-759-710-59 IC NJM4580D-D
IC409 8-759-710-59 IC NJM4580D-D
IC410 8-759-710-59 IC NJM4580D-D
<JACK>
J401 1-793-345-21 JACK, PIN 6P (MULTI CHANNEL INPUT2)
J402 1-784-934-11 JACK, PIN 4P (MULTI CHANNEL INPUT1)
J403 1-815-520-11 JACK, PIN 4P (MULTI CHANNEL INPUT1)
J404 1-784-934-11 JACK, PIN 4P (PRE OUT)
J405 1-815-520-11 JACK, PIN 4P (PRE OUT)
J406 1-785-298-11 JACK, PIN 1P (PRE OUT)
J407 1-815-737-11 CONNECTOR, (D)SUB 9P (RS232C)
<TRANSISTOR>
Q401 8-729-230-49 TRANSISTOR 2SC2712-YG
Q402 8-729-230-49 TRANSISTOR 2SC2712-YG
Q403 8-729-230-49 TRANSISTOR 2SC2712-YG (US,CND)
Q404 8-729-230-49 TRANSISTOR 2SC2712-YG
Q405 8-729-230-49 TRANSISTOR 2SC2712-YG
Q406 8-729-230-49 TRANSISTOR 2SC2712-YG
Q407 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
R401 1-216-246-00 RES-CHIP 100K 2% 1/8W
R402 1-216-013-00 METAL CHIP 33 5% 1/10W
R403 1-216-013-00 METAL CHIP 33 5% 1/10W
R404 1-216-013-00 METAL CHIP 33 5% 1/10W
R405 1-216-013-00 METAL CHIP 33 5% 1/10W
R406 1-216-013-00 METAL CHIP 33 5% 1/10W
R407 1-216-013-00 METAL CHIP 33 5% 1/10W
R408 1-216-013-00 METAL CHIP 33 5% 1/10W
R409 1-216-013-00 METAL CHIP 33 5% 1/10W
R410 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R411 1-216-246-00 RES-CHIP 100K 2% 1/8W
E-VOL
