Sony STR-DA3ES - Page 77

77
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S-VIDEO
R376 1-218-756-11 RES-CHIP 150K 2% 1/10W
(DA3ES,DA5ES)
R377 1-216-246-00 RES-CHIP 100K 2% 1/8W
(VA555ES)
R377 1-216-250-11 RES-CHIP 150K 2% 1/8W
(DA3ES,DA5ES)
R378 1-208-583-11 RES-CHIP 220K 2% 1/8W
R379 1-218-756-11 RES-CHIP 150K 2% 1/10W
(DA3ES,DA5ES)
R380 1-218-760-11 RES-CHIP 220K 2% 1/10W
(DA3ES,DA5ES)
R392 1-249-393-11 CARBON 10 5% 1/4W F
R393 1-216-073-91 RES-CHIP 10K 5% 1/10W
R394 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
<RELAY>
RY301 1-515-614-11 RELAY
******************************************************
1-681-472-11 LED BOARD
*********
<CAPACITOR>
C118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
<CONNECTOR>
* CN101 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
<DIODE>
D118 8-719-084-07 DIODE SEL5E20CTP15
(MULTI CHANNEL DECODING)
<RESISTOR>
R115 1-216-022-00 METAL CHIP 75 5% 1/10W
R116 1-216-037-00 METAL CHIP 330 5% 1/10W
******************************************************
A-4476-725-A M-BUS BOARD (DA3ES,DA5ES)
******************
C215 1-119-823-11 ELECT 4.7uF 20% 50V
C216 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C232 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C233 1-164-690-91 CERAMIC CHIP 0.0022uF 5% 50V
C235 1-164-690-91 CERAMIC CHIP 0.0022uF 5% 50V
<CONNECTOR>
CNS204 1-568-826-11 CONNECTOR, FFC 7P
<IC>
IC200 8-759-470-63 IC NJM2145M-TE2
<JACK>
J203 1-563-330-11 JACK (CONTROL S MONITOR IN)
J204 1-563-330-11 JACK (CONTROL S TV/SAT IN)
J205 1-563-330-11 JACK (CONTROL S DVD/LD OUT)
J206 1-563-330-11 JACK (CONTROL S VIDEO OUT)
<TRANSISTOR>
Q200 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q201 8-729-027-23 TRANSISTOR DTA114EKA-T146
<RESISTOR>
R2002 1-216-073-91 RES-CHIP 10K 5% 1/10W
R208 1-216-049-11 RES-CHIP 1K 5% 1/10W
R209 1-216-049-11 RES-CHIP 1K 5% 1/10W
R210 1-216-049-11 RES-CHIP 1K 5% 1/10W
R211 1-216-049-11 RES-CHIP 1K 5% 1/10W
******************************************************
1-681-468-11 M-VOL BOARD
***********
<CAPACITOR>
C117 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
<CONNECTOR>
CNP105 1-770-389-11 PIN, CONNECTOR (PC BOARD) 5P
<VALIABLE RESISTOR>
RV103 1-227-182-11 RES, VAR, CARBON 10K (MASTER VOLUME)
*****************************************************
A-4476-700-A S-VIDEO BOARD,COMPLETE (DA3ES,DA5ES)
A-4476-701-A S-VIDEO BOARD,COMPLETE (VA555ES)
*****************************
<CAPACITOR>
C128 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C217 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C218 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C219 1-119-824-11 ELECT MELF 10uF 20% 50V
C220 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C221 1-119-824-11 ELECT MELF 10uF 20% 50V
C222 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C223 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C224 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C225 1-119-824-11 ELECT MELF 10uF 20% 50V
C226 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C227 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C228 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C229 1-119-824-11 ELECT MELF 10uF 20% 50V
C230 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C231 1-128-834-11 ELECT 470uF 20% 10V
C234 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C236 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C237 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C239 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C241 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C242 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C243 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C244 1-119-824-11 ELECT MELF 10uF 20% 50V
C245 1-165-319-11 CERAMIC CHIP 0.1uF 50V (VA555ES)
C246 1-128-840-11 ELECT 47uF 20% 16V
(VA555ES)
C247 1-119-822-11 ELECT 3.3uF 20% 50V
(VA555ES)
LED M-VOLM-BUSINPUT
