78
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S-VIDEO
C248 1-119-824-11 ELECT MELF 10uF 20% 50V
C251 1-119-822-11 ELECT 3.3uF 20% 50V
(VA555ES)
C252 1-119-824-11 ELECT MELF 10uF 20% 50V
C254 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C262 1-119-824-11 ELECT MELF 10uF 20% 50V
C263 1-119-824-11 ELECT MELF 10uF 20% 50V
C264 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(DA3ES,DA5ES)
C265 1-163-091-00 CERAMIC CHIP 8PF 50V
(DA3ES,DA5ES)
C266 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C267 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C268 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C269 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C270 1-128-840-11 ELECT 47uF 20% 16V
C271 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C272 1-119-824-11 ELECT MELF 10uF 20% 50V
C274 1-119-824-11 ELECT MELF 10uF 20% 50V
C275 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C276 1-128-840-11 ELECT 47uF 20% 16V
C2001 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2002 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2004 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2006 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C2008 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2011 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2012 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2013 1-165-319-11 CERAMIC CHIP 0.1uF 50V
<CONNECTOR>
CNP201 1-770-594-11 CONNECTOR,BOARD TO BOARD 5P (VA555ES)
CNP202 1-784-774-11 CONNECTOR, FFC 13P
CNP204 1-564-708-11 PIN, CONNECTOR 6 P
CNS201 1-568-830-11 CONNECTOR, FFC 11 P
CNS203 1-568-826-11 CONNECTOR, FFC 7P (DA3ES,DA5ES)
<TRIMMER>
CT203 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (VCO)
(DA3ES,DA5ES)
CT204 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (VCO)
<DIODE>
D201 8-719-801-78 DIODE 1SS184
D206 8-719-988-61 DIODE 1SS355TE-17
<FERRITE BEAD>
FB202 1-469-152-11 FERRITE 0uH (VA555ES)
<IC>
IC202 8-759-536-24 IC NJM-2296M-TE2
IC203 6-700-050-01 IC NJM2596M(TE2)
IC204 8-759-822-05 IC LA7213 (VA555ES)
IC205 8-759-822-05 IC LA7213 (VA555ES)
IC209 6-700-367-01 IC MB90089PF-G-238-BND
IC210 8-759-682-76 IC BA7622F-E2-A
<JACK>
J207 1-563-330-11 JACK (CTRL A1 II )
J208 1-779-801-11 CONNECTOR (ROUND TYPE) (VIDEO 1)
J209 1-779-801-11 CONNECTOR (ROUND TYPE) (VIDEO 2)
J210 1-779-801-11 CONNECTOR (ROUND TYPE) (TV/SAT DVD/LD)
J211 1-779-800-11 TERMINAL, S (MONITOR)
<INDUCTOR>
L201 1-500-425-11 FERRITE 0uH (VA555ES)
L201 1-216-296-11 SHORT 0 (DA3ES,DA5ES)
L202 1-500-425-11 FERRITE 0uH (VA555ES)
L202 1-216-296-11 SHORT 0 (DA3ES,DA5ES)
L203 1-500-425-11 FERRITE 0uH (VA555ES)
L203 1-216-296-11 SHORT 0 (DA3ES,DA5ES)
L204 1-500-425-11 FERRITE 0uH (VA555ES)
L204 1-216-296-11 SHORT 0 (DA3ES,DA5ES)
L205 1-408-781-00 INDUCTOR 22uH
<TRANSISTOR>
Q202 8-729-230-49 TRANSISTOR 2SC2712-YG
Q203 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
R212 1-216-022-00 METAL CHIP 75 5% 1/10W
R213 1-216-022-00 METAL CHIP 75 5% 1/10W
R214 1-216-022-00 METAL CHIP 75 5% 1/10W
R215 1-216-022-00 METAL CHIP 75 5% 1/10W
R216 1-216-022-00 METAL CHIP 75 5% 1/10W
R217 1-216-022-00 METAL CHIP 75 5% 1/10W
R218 1-216-022-00 METAL CHIP 75 5% 1/10W
R219 1-216-022-00 METAL CHIP 75 5% 1/10W
R220 1-216-022-00 METAL CHIP 75 5% 1/10W
R221 1-216-022-00 METAL CHIP 75 5% 1/10W
R222 1-216-022-00 METAL CHIP 75 5% 1/10W
R223 1-216-022-00 METAL CHIP 75 5% 1/10W
R224 1-216-022-00 METAL CHIP 75 5% 1/10W
R225 1-216-022-00 METAL CHIP 75 5% 1/10W
R226 1-216-097-11 RES-CHIP 100K 5% 1/10W
R227 1-216-097-11 RES-CHIP 100K 5% 1/10W
R228 1-216-097-11 RES-CHIP 100K 5% 1/10W
R229 1-216-097-11 RES-CHIP 100K 5% 1/10W
R230 1-216-097-11 RES-CHIP 100K 5% 1/10W
R231 1-216-001-00 METAL CHIP 10 5% 1/10W
R232 1-216-001-00 METAL CHIP 10 5% 1/10W
R233 1-216-001-00 METAL CHIP 10 5% 1/10W
R235 1-216-105-91 RES-CHIP 220K 5% 1/10W
(VA555ES)
R236 1-216-105-91 RES-CHIP 220K 5% 1/10W
(VA555ES)
R237 1-216-037-00 METAL CHIP 330 5% 1/10W
(VA555ES)
R238 1-216-037-00 METAL CHIP 330 5% 1/10W
(VA555ES)
R239 1-216-097-11 RES-CHIP 100K 5% 1/10W
R245 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R246 1-216-089-91 RES-CHIP 47K 5% 1/10W
R247 1-216-089-91 RES-CHIP 47K 5% 1/10W
R248 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R249 1-216-089-91 RES-CHIP 47K 5% 1/10W
R250 1-216-089-91 RES-CHIP 47K 5% 1/10W
R251 1-216-035-00 METAL CHIP 270 5% 1/10W
(DA3WS,DA5ES)
R252 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R254 1-216-097-11 RES-CHIP 100K 5% 1/10W
